Ubiquiti UFiber Loco Gateway & Controller 10, 100, 1000 Mbit/s
Introducing the Ubiquiti N-SW NanoSwitch Outdoor 4-Port PoE Passthrough Switch, an unmanaged switch with four Gigabit Ethernet ports. For its total non-blocking line rate, the NanoSwitch supports up to 4 Gbps. Featuring a durable, weatherproof form factor, the Ubiquiti Outdoor NanoSwitch is ideal for outdoor deployment. For quick installation, the compact NanoSwitch can be easily mounted on a pole or wall.
Key Features
One (1) Gigabit 24V Passive PoE In Port.
Three (3) Gigabit 24V Passive PoE Out Ports.
Outdoor, Weather-Resistant Enclosure.
Can be easily mounted on a pole or wall.
LEDs for Speed, Link and Activity.Low-Cost GPON Optical Network Unit
Sporting a sleek industrial design, the U Fiber loco is a robust, high‑performance GPON CPE that features extremely low power consumption and two power options.Status LEDs
The easy-to-read LEDs provide status information: Ethernet connection, signal strength, and power.Versatile Power
The UFiber loco can be powered by a Micro-USB Power Adapter (included) or 24V passive PoE.Designed for Integration
Up to 128 UFiber loco devices can be connected to a single GPON port. Supporting GPON links of up to 20 km, the UFiber loco integrates with the UFiber OLT and third-party OLT devices -
Feature Specification Dimensions 76.5 x 76.5 x 26.4 mm (3 x 3 x 1″) Weight 77 g (2.7 oz) Material Polycarbonate Networking * WAN (1) SC/APC, ITU-G.984 GPON * LAN (1) GbE RJ45 Management Ethernet In-Band/PON Power * Method Micro-USB: 5V, 1A / 24V Passive PoE * Supply Micro-USB Adapter* (included in single-pack) Voltage Range 4.7–5.3V Max. Power Consumption 3.5W Line Rate * Downstream 2.488 Gbps * Upstream 1.244 Gbps LEDs * PON Status (3) signal LEDs * Ethernet Steady white (link up), Blinking white (activity), OFF (link down) * Power White (ONS) Software ONU/ONT layer 2/3 Ethernet switch Services Web server, telnet, NAT, bridging/routing, firewall, application passthrough Temperature -10 to 45° C (14 to 113° F) Humidity 10 to 90% noncondensing Fiber * Wavelength TX: 1310 nm, RX: 1490 nm * Line Code Scrambled NRZ * Bit Rate Downstream: 2488.32 Mbit/s, Upstream: 1244.16 Mbit/s * Reach 20 km Security GEM Port Encryption
