Hanwha 4MP IR Bullet Camera | ANO-L7022R
4MP resolution, Up to 30fps(H.265/H.264)
Color : 0.1Lux (F1.6, 1/30sec), B/W : 0Lux (IR LED On)
4mm lens w/ 78.2° HFoV
IR viewable length: 25m
Day & Night (ICR), WDR (120dB)
H.265, H.264, MJPEG, Multiple streaming supported
Defocus detection, Directional detection, Motion detection, Enter/Exit, Tampering
Hallway view (90⁰/270⁰), LDC support, WiseStream II
Micro SD/SDHC/SDXC memory slot (Max. 128GB)
IP66 -
Property Description Property Value Video Imaging Device 1/3″ CMOS Resolution 2560 x 1440, 1920 x 1080, 1280 x 960, 1280 x 720, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 Max. Framerate H.265/H.264: Max. 30fps/25fps (60Hz/50Hz) MJPEG: Max. 15fps (@4MP Max. 2fps) Min. Illumination Color: 0.13Lux (F1.6, 1/30sec) BW: 0Lux (IR LED On) Lens Focal Length (Zoom Ratio) 4mm fixed focal Max. Aperture Ratio F1.6 Angular Field of View H: 79° / V: 43° / D: 92° Min. Object Distance 1.7m (5.6ft) Focus Control Fixed Pan / Tilt / Rotate Pan / Tilt / Rotate Range 0°~360° / 0°~100° / 0°~360° Operational Camera Title Displayed up to 85 characters Day & Night Auto (ICR) Backlight Compensation BLC, WDR, SSDR Wide Dynamic Range 120dB Digital Noise Reduction SSNR Motion Detection 4ea, polygonal zones Privacy Masking 6ea, rectangular zones Gain Control Low / Middle / High White Balance ATW / AWC / Manual / Indoor / Outdoor LDC Support Electronic Shutter Speed Minimum/Maximum/Anti flicker (1/5~1/12,000sec) Video Rotation Flip, Mirror, Hallway view (90°/270°) Analytics Motion detection, Tampering, Defocus detection, Virtual area (Intrusion/Enter/Exit), Virtual line (Crossing/Direction) Alarm Triggers Analytics, Network disconnect Alarm Events When alarm trigger occurred – File upload (image): e-mail/FTP – Notification: e-mail – Recording: SD/SDHC/SDXC or NAS recording at event triggers – Handover (PTZ preset) Light Type IR LED (850nm) Light Viewable Length 25m (82.02ft) Network Ethernet RJ-45 (10/100BASE-T) Video Compression H.265/H.264: Main/High, MJPEG Smart Codec Manual (5ea area), WiseStreamⅡ Video Quality Adjustment H.265/H.264: Target bitrate level control MJPEG: Quality level control Bitrate Control H.264/H.265: CBR or VBR MJPEG: VBR Streaming Unicast (6 users) / Multicast Multiple streaming (Up to 3 profiles) Protocol IPv4, IPv6, TCP/IP, UDP/IP, RTP (UDP), RTP (TCP), RTCP, RTSP, NTP, HTTP, HTTPS, SSL/TLS, DHCP, PPPoE, FTP, SMTP, ICMP, IGMP, SNMPv1/v2c/v3 (MIB-2), ARP, DNS, DDNS, QoS, PIM-SM, UPnP, Bonjour, LLDP Application Programming Interface ONVIF Profile S/G/T, SUNAPI (HTTP API) Security OS / Firmware Protect Firmware encryption User authentication Digest Authentication, Prevent brute-force attack Network authentication 802.1X Authentication (EAP-TLS, EAP-LEAP, EAP-PEAP MSCHAPv2) Secure Communication HTTPS, SRTP, WSS (Websocket secure) Access Control Access control based on IP address Data Protect Authentication information encryption, ZIP compression encryption Audit User Access/System/Event log management Device ID Device Certificate (Hanwha Private Root CA) Secure Storage SD card partition encrypt General Webpage Language English, Korean, Chinese, French, Italian, Spanish, German, Japanese, Russian, Portuguese, Czech, Polish, Turkish, Dutch, Hungarian, Greek Edge Storage Micro SD/SDHC/SDXC 1slot 128GB Memory 512MB RAM, 256MB Flash Environmental & Electrical Operating Temperature / Humidity -30°C~+55°C (-22°F ~ +131°F) / 0~95% RH Storage Temperature / Humidity -30°C ~ +55°C (-22°F ~ +131°F) / 0~95% RH Certification IP66 Input Voltage PoE (IEEE802.3af, Class3) Power Consumption Max 7.5W, typical 5.7W Mechanical Color / Material White / Plastic RAL Code RAL9003 Product Dimensions / Weight ø78.0×262.0mm (ø3.07×10.31”), 390g (0.86lb) DORI (EN62676-4 standard) Detect (25PPM/ 8PPF) 62.9m (206.33ft) Observe (63PPM/ 19PPF) 25.2m (82.53ft) -
