Hanwha 2MP AI IR Vandal Dome Camera | XNV-6083R

• Description
• Specifications
• Downloads

• Hanwha 2MP AI IR Vandal Dome Camera | XNV-6083R

  2MP resolution
  2.8~12mm (4.3x) motorised varifocal
  Colour: 0.01Lux(F1.4, 1/30sec, 30IRE), 0 Lux (IR LED on)
  Maximum 120 fps (H.265/H.264)
  WiseIR: IR viewable length 50 m (164.04 ft)
  Day & Night (ICR), extremeWDR (150 dB)
  Hard-coated dome bubble
  WiseNRⅡ (Based on AI engine), WiseStreamⅢ (Based on AI engine)
  Analytics events based on AI engine (NPU) : Object detection (Person/Face/Vehicle – car, truck, bus, bicycle, motorcycle/Licence plate), IVA (Virtual line/Area, Enter/Exit, Loitering, Direction, Intrusion)
  Analytics events : Defocus detection, Motion detection, Tampering, Fog detection Audio detection, Sound classification, Shock detection, Appear/Disappear
  IP66/IP67/IP6K9K, NEMA4X, IK10+

• Category	Property	Value
  Camera	Lens viewing angle, diagonal	142.1 °
  	Lens viewing angle, horizontal	119.5 °
  	Lens viewing angle, vertical	62.8 °
  	Pan range	0 – 360 °
  	Tilt angle range	-45 – 75 °
  	Viewing angle, diagonal	142.1 °
  	Viewing angle, horizontal	119.5 °
  	Viewing angle, vertical	62.8 °
  	White balance	ATW/AWC/Indoor/Manual/Outdoor
  Design	Form factor	Dome
  	IK code	IK10
  	International Protection (IP) code	IP66, IP67
  	Mounting type	Ceiling
  	Product colour	White
  	Protection features	Dust resistant/Vandal proof/Water resistant
  Features	NDAA Compliance	Yes
  Image sensor	Optical sensor size	1/2.8 “
  	Progressive scan	Yes
  	Sensor type	CMOS
  Legal Information	EU ECCN Code	N/A
  	UNSPSC Code	46171610
  	US ECCN Code	EAR99
  Lens system	Focal length range	2.8 – 12 mm
  	Number of lenses	1
  	Zoom capability	Yes
  Network	Bluetooth	No
  	Ethernet LAN	Yes
  	Streaming method	Multicast/Unicast
  	Wi-Fi	No
  Night vision	LED type	IR
  	Night vision	Yes
  	Night vision distance	50 m
  Operational conditions	Operating temperature (T-T)	-50 – 55 °C
  	Storage temperature (T-T)	-50 – 60 °C
  Package dimensions	Depth (package, cm)	45.6 cm
  	Gross Weight (Package, kg)	1.4 kg
  	Height (package, cm)	21.6 cm
  	Width (package, cm)	58.6 cm
  Packaging content	Number of cameras	1
  Performance	Connectivity technology	Wired
  	Day/night mode	Yes
  	Dynamic range	150 dB
  	Placement supported	Indoor & outdoor
  	Type	IP security camera
  	Wide Dynamic Range (WDR)	Yes
  Ports & interfaces	Ethernet LAN (RJ-45) ports	1
  Power	DC output voltage	12
  	Power consumption (max)	20 Watt
  	Power consumption (Power over Ethernet (PoE))	22.5 Watt
  	Power consumption (typical)	15.6 Watt
  	Power source type	DC/PoE
  Product dimensions	Net Weight (Product, kg)	1.9 kg
  	Product Depth	18 cm
  	Product Height	12.5 cm
  	Product Width	18 cm
  Security	Anti-flicker	Yes
  	IP address filtering	Yes
  	Security algorithms	EAP-LEAP/EAP-PEAP/EAP-TLS/HTTPS
  Storage	Built-in HDD	No
  	Card reader integrated	Yes
  	Compatible memory cards	MicroSD (TransFlash)/MicroSDHC/MicroSDXC
  	Flash memory	512 MB
  	Internal memory	2000 MB
  	Maximum memory card size	512 GB
  Vendor information	Brand Name	Hanwha
  	Warranty	5 Year(s)
  Video	Frame rate	120 fps
  	Image stabilizer	Yes
  	Maximum resolution	1920 x 1080 Pixels
  	Noise reduction	Yes
  	Total megapixels	2 MP
  	Video recording	Yes
  	Video streaming	Yes
  Weight & dimensions	Diameter	18 cm
