• DataVideo SDI to HDMI Converter


  Convert SDI to HDMI with Audio De-Embedding Options
  The DAC-8PA allows you to convert an SDI signal (up to 1080p60) to HDMI. It includes the option to de-embed audio to a stereo RCA output.

  Supports 1080p 50/60
  Automatic input signal detection and HDMI support for High Color (Deep Color).


  Supports stereo audio output
  One SDI loopthrough output and one HDMI output.

  Aluminum alloy and robust design
  Very robust and durable. The DAC series has a robust metal housing that can withstand even the most extreme conditions. Low heat loss, ideal for use for several hours in a normally ventilated environment.

• Feature	Details
  Model Number	DAC-8PA
  Conversion	3G/HD/SD-SDI to HDMI
  Video Inputs	1x 3G/HD/SD-SDI
  Loop Through	1
  Video Outputs	1x HDMI
  Audio Inputs	2x SDI Audio embedded
  Audio Outputs	2x RCA (stereo)
  Audio Format Selection	—-
  Audio Gain	—-
  Supported Video Input Formats	1080p, 1080i, 720p, 625i (PAL), 525i (NTSC)
  Output Resolutions	Automatically combines SD, HD, 3G SDI
  Equalizer	Yes
  Reclock	Yes
  SDI Cable Drive	Yes
  Updates and Configuration	Mini USB x 1
  Dimension (LxWxH)	112 x 85 x 45 mm
  Weight	0.4 kg
  Operating Temp. Range	0~40 °C
  Power	DC 12V, 4W
  What’s in the Box	1 x DAC-8PA, 1 x AD Switch DC 12V

• Description	Downloads
  DataVideo SDI to HDMI Converter | DAC-8PA Instruction Manual	Downloads
