• Aten 60m HDMI Over Cat5e/6 Audio/Video Extender – VE800A-AT-E

  The VE800A HDMI Extender extends your HDMI display up to 60 m away from your HDMI source using one Cat 5e cable. ATEN’s VE800A incorporates new technology that allows the A/V signals to be transmitted over a single Cat 5e cable. DDC port is provided for the ability to use the display’s EDID by simply connecting another Cat 5e cable. The VE800A supports HDMI features such as 3D and Deep Color to give you the picture perfect viewing experience you desire.
  1x VE800AT HDMI Extender

  1x VE800AR HDMI Extender

  2x 0AD6-1705-10EG Power Adapters

  1x Mounting Kit

  1x User Instructions

  Uses Cat 5e cable to extends the distance between HDMI source and HDMI display

  Extend 1080p by 40 m; extend 1080i (HDTV) by 60 m

  HDMI (3D, Deep Color); HDCP Compatible

  8 segment equalization adjustment switch optimizes display quality

• Features	Details
  Bandwidth	6.75 Gbit/s
  Bandwidth	225 MHz
  Cable types supported	Cat5/Cat6/Cat6a
  HDCP	Yes
  Impedance	100 Ω
  LED indicators	Yes
  Material	Metal
  Maximum resolution	1920 x 1080 Pixels
  Maximum transfer distance	3 m
  Product colour	Black
  Supported video modes	1080p
  Type	AV transmitter & receiver
  Operational conditions
  Operating relative humidity (H-H)	0 – 80 %
  Operating temperature (T-T)	0 – 50 °C
  Storage temperature (T-T)	-20 – 60 °C
  Package dimensions
  Depth (package, cm)	23.9 cm
  Gross Weight (Package, kg)	0.65 kg
  Height (package, cm)	16 cm
  Width (package, cm)	5.9 cm
  Packaging content
  AC adapter included	Yes
  Packaging data
  Quantity per pack	2 pc(s)
  Ports & interfaces
  Connectivity technology	Wired
  DC-in jack	Yes
  Ethernet LAN	Yes
  HDMI in	1
  Number of HDMI outputs	1
  RJ-45 input ports	2
  RJ-45 output ports	2
  Power
  Power consumption (receiver) (max)	0.61 Watt
  Power consumption (transmitter) (max)	0.9 Watt
  Product dimensions
  Net Weight (Product, kg)	0.6 kg
  Vendor information
  Brand Name	Aten
  Warranty	2 Year(s)
  Weight & dimensions
  Receiver dimensions (WxDxH)	55 x 90 x 22 mm
  Receiver weight	160 g
  Transmitter dimensions (WxDxH)	55 x 90 x 22 mm
  Transmitter weight	160 g
