Zyxel VMG8825-T50K Dual-Band Wireless AC/N VDSL2 Combo WAN Gigabit IAD
The Zyxel VMG8825-T50K Dual-Band Wireless AC/N VDSL2 Combo WAN Gigabit IAD provides high-speed VDSL Internet access to meet the worldwide market requirements for triple-play services.
While the built-in 4×4 802.11ac WLAN function eliminates troublesome wirings, the VMG8825-T50K offers extreme coverage for great WiFi user experience. Moreover, the user-oriented design allows the VMG8825-T50K to meet every customer’s own style while providing functions that are both powerful and practical.
VDSL2 supports super vectoring up to profile 35b
Remote management via TR-069 and TR-181 i2
NAT, firewall with SPI and DoS for better security
VoIP SIP protocol with 3-way conference calls
Zyxel-developed OPAL for superior flexibility and faster time-to-market
Carrier-class WiFi for seamless mobility
Rated as AC2400, the Zyxel VMG8825-T50K delivers speeds of up to 1.7 Gbps* over 5 GHz and 600 Mbps* over 2.4 GHz. For elevated user enjoyment, the VMG8825-T50K offers dual-band WiFi with performance-boosting features such as Multi-User MIMO (MU-MIMO) and Beamforming for simultaneous, lag-free streaming and gaming experiences. In addition, it’s ability to create multiple WiFi networks with up to 4 SSIDs helps operators to easily create individual WLAN networks for video, data and guests.The triple-play powerhouse
The Zyxel VMG8825-T50K is built with sophisticated QoS and multicast traffic shaping features like IGMP v1/2/3 snooping and VLAN capabilities for premium video delivery services. To wireless IPTV operators, its built-in 4×4, 802.11ac chip is the top choice.Remote management through TR-069 and TR-181 issue-2
The VMG8825-T50K supports TR-069 that simplifies remote configuration, upgrade, and management and therefore improves cost effectiveness and customer satisfaction. The additional support to the latest TR-181 issue-2 data model also enhances service providers’ visibility on subscriber LAN networks for improved customer assistance.Zyxel OPAL firmware achieves superior flexibility and faster time-to-market
Compliant with the same OPAL firmware trunk applied in all Zyxel CPEs, the VMG8825-T50K inherits a rich, field-proven feature set. Service providers can ensure the same user experience, after migrating to new devices.Whole-home network security solution in one device
With embedded Zyxel Home Cybersecurity, the VMG8825-T50K allows service providers to create a stable and future-proof internet infrastructure with cutting-edge technologies and mechanisms such as a cloud-based AI and machine learning, without an impact on the system performance. Developed through a longstanding partnership with F-Secure, Zyxel Home Cybersecurity enables service providers to reinforce competitiveness by providing full aspect protection to secure subscribers’ home networks.Application diagram
-
System Specifications Wireless Standard 802.11 b/g/n/ac 2.4 GHz, data rate 600 Mbps 802.11 a/n/ac 5 GHz, data rate 1733 Mbps VDSL and ADSL Compliance VDSL: G.993.1 VDSL G.993.2 VDSL2, Band 997, 998, Over POTS Support VDSL profiles: 8a/b/c/d, 12a/b, 17a, and 35b G.vector ADSL: ANSI T1.413 compliant G.992.1 (G.dmt) G.992.2 (Splitterless, G.lite) G.992.3 (ADSL2) G.992.5 (ADSL2+) G.INP support Router/Bridge Features IEEE 801D transparent bridge & basic spanning tree PPPoE (RFC 2516) PPPoA (RFC 2364) MAC encapsulation routing/IPoE Network Address Translation (NAT) NAT virtual server (port forwarding) DHCP client/server/relay with DHCP option 43/60/61/125 DNS proxy/dynamic DNS Static/Policy route IGMP v1, v2, v3 IPv4/IPv6 Wireless Wireless Protected Setup (WPS) WMM WPA2/WPA2-PSK with TKIP & AES security type MU-MIMO support Multi SSID: up to 4 VLAN/QoS 802.1Q VLAN tagging/un-tagging Support flexible traffic classification Firewall & Security Generic packet filter DoS attack prevention Parental control USB File sharing 3G/4G dongle (By USB dongle) Management Web/HTTP: 3 level log-in via SSH or Telnet Firmware upgrade via Web/TFTP/FTP/TR-069 RPC method Text-based configuration Configuration backup/update/restore default via Web Configurable access control for remote management (interface and/port number) DSL forum TR-069, TR-098 TR-111 and TR-181 i2 SNMP v1, v2 Rom-D support UPnP port forwarding rules on page VoIP SIP (Section Initiating Protocol, RFC 3261) Codec: G.711 a/μ (64K), G.726 (24/32K), G.722 G.168 echo cancellation Fax/modem detection and pass-through Voice Active Detector (VAD) Comfort Noise Generator (CNG) Dynamic jitter buffer DTMF detection and generation DTMF relay by in-band and out-of-band (RFC 2833, SIP INFO) SIP account (URL type included) On hook, off hook and flash detection Caller ID Call forwarding (No condition, busy, no answer) Call transferring Call hold/Call retrieve Three-way conference Call waiting DNS SRV Hardware Specifications WAN port: One 10/100/1000 Mbps Ethernet port RJ-45 DSL port: One RJ-11 Ethernet port: Four 10/100/1000 Mbps Ethernet ports RJ-45 (8P8C) Wireless Three internal antennas (2.4 GHz) Four internal antennas (5 GHz) VoIP: 2 FXS ports USB: One USB 3.0 host One USB 2.0 port Button: One power on/off button One reset button One WPS on/off push button One WLAN on/off button Status LEDs indicators: Power/System WAN Internet WLAN-2.4G WLAN-5G WPS LAN Phone Power consumption: 12 V DC, 2.5 A Physical Specifications Item dimensions (WxDxH): 220 x 75 x 200 mm (8.66″ x 2.95″ x 7.87″) Item weight: 549 g (1.21 lb.) Environmental Specifications Operating Environment Temperature: 0ºC to 40ºC (32ºF to 104ºF) Humidity: 10% to 90% RH (Non-condensing) Storage Environment Temperature: -30ºC to 70ºC (-22ºF to 158ºF) Humidity: 10% to 95% RH (Non-condensing) Certification CE Package Contents Wireless IAD Power adapter Ethernet cable Phone cable Quick start guide Safety warning card -
