• Zyxel LTE7240-M403 LTE Cellular Network Outdoor Router


  The Zyxel LTE7240-M403 4G LTE Outdoor Router comes with what the critical feature, “the second WAN”, needs – flexible routing mode with both bridge and router functions, high-gain antenna for better signal and performance as well as robust IP56 outdoor hardware designed for harsh environments. No matter you have a router device or not, the LTE7240-M403 can be easily deployed and integrated into your existing environment. You can set LTE as your main connection or use LTE as a backup when performance of the main connection drops. The LTE7240-M403 is good for any venue like suburban areas, public locations, homes and offices. Enjoy LTE technology with minimum effort with the LTE7240-M403.

  As mobile devices such as smart phones and tablets consume more wireless broadband, the crowded bandwidths have become a big issue to operators. Mobile broadband is a better solution than fixed-line broadband for its lower investment and faster deployment. However, since fixed lines have been the major broadband infrastructure in most places of the world for a long time, people are already using fixed lines for broadband Internet connection in most cases. Migrating from fixed lines to mobile broadband may need extensive evaluation, however adding mobile broadband as a backup for better performance or stability could be an easier decision.

  Embedded bridge/router mode adapts to all kinds of devices/gateways
  For better network integration, Zyxel embeds both bridge and router modes into the LTE7240-M403. While users can take advantage of the built-in routing functions in all typical applications, the bridge mode is designed to work with users’ existing or preferred devices such as high-end Wi-Fi Access Points, Small Business Gateways or Enterprise Gateways. With the two built-in modes, the LTE7240-M403 can be easily integrated with all kinds of devices/gateways.

  Built-In multi-band antenna
  Zyxel’s LTE7240-M403 4G LTE Outdoor Router provides multi-band embedded antennas of up to 7 dBi that work effectively in outdoor environments. The outdoor-friendly design makes it possible to work in near non-line-of-sight conditions where desirable signal strength was difficult to achieve.

  Non-stop connectivity with LTE 2nd WAN for fail-over
  Multi-WAN fail-over relieves the risk of network outage caused by dependence on single-WAN technology. Even better, LTE is wireless so you can get the second WAN without an additional cabling plan. As long as the gateway supports “multi-WAN fail-over”, you can just connect the Zyxel LTE7240-M403 to the existing gateway and set LTE as the fail-over WAN.

  Software upgrades over-the-air
  Through the LTE radio interface, the Zyxel LTE7240-M403 supports TR-069 has full over-the-air configuration and software upgrade capability through events triggered by the operators.

  Application Diagram

• System Specifications
  IP Networking
  Support IPv4/IPv6 dual stack (NDP IPv6)	Yes
  DHCP server	Yes
  ICMP supported	Yes
  VPN pass through	Yes
  Support NAT/NAPT/NAT disabling	Yes
  Support DMZ	Yes
  Support port forwarding/triggering	Yes
  Support ALG	Yes
  Routing
  Support Bridge/Router mode	Yes
  Support Dynamic DNS for first APN	Yes
  Static/dynamic route setting for RIP v1/v2	Yes
  Support Remote Management under Bridge Mode	Yes
  Address Resolution Protocol	Yes
  IP Firewall
  Firewall can be enabled or disabled via GUI	Yes
  DoS Attack Prevention	Yes
  Support SPI	Yes
  Application-Level Firewall	Yes
  Filters LAN MAC address	Yes
  Filters LAN IP address	Yes
  Filters URLs	Yes
  Management
  Support Local/Remote device management	Yes
  Firmware upgrade via TR-069 and Web GUI	Yes
  SMS management	Yes
  APN management	Yes
  PIN/PUK management	Yes
  Network selection	Yes
  Network preference	Yes
  Operating frequency band selection	Yes
  CLI/SSH (Local and remote SSH access)	Yes
  Support UPNP IGD	Yes
  Support SSH with key access	Yes
  Support Bandwidth/Quota management	Yes
  Support Web server API to support APPs	Yes
  Hardware Specifications
  LTE Interface
  Standard compliant: 3GPP UE Category 4	Yes
  Supported frequency: Band 1/3/5/7/8/20/38/40/41	Yes
  FDD LTE peak data rate:	150 Mbps DL / 50 Mbps UL
  TDD LTE peak data rate:	112 Mbps DL / 10 Mbps UL
  UMTS/EDGE/GPRS/GSM Air Interface
  Standard compliant: WCDMA Rel’99 and Rel’10	Yes
  Supported frequency:	UMTS band 1/5/8
  EDGE/GPRS/GSM band 3/8
  DC-HSPA+ downlink data rate up to 42 Mbps	Yes
  HSUPA uplink data rate up to 5.76 Mbps	Yes
  UMTS data rate up to 384 kbps	Yes
  EDGE data rate up to 236.8 kbps	Yes
  GPRS data rate up to 85.6 kbps	Yes
  LTE/UMTS/GPRS Antennas
  2 embedded antennas of up to 7 dBi	Yes
  Power Specifications
  Passive power over Ethernet	Yes
  Power consumption at jack: < 10W	Yes
  WiFi AP Features
  802.11 n/g/b, 2.4 GHz, N300	Yes
  Hidden SSID	Yes
  MAC Address Filtering	For local management purpose only
  Hardware Interface
  One 10/100/1000 Mbps Ethernet RJ-45 LAN port	Yes
  LEDs:
  Power & signal and quality	Yes
  Internet status/SMS	Yes
  WiFi status	Yes
  LAN status	Yes
  One 3FF format mini SIM card slot	Yes
  One WLAN button	Yes
  One reset to default button	Yes
  Power Consumption
  15V/1A Power over Ethernet (PoE)	Yes
  Physical Specifications
  Dimensions (WxDxH):	140 x 60 x 200 mm (5.51″ x 2.36″ x 7.87″)
  Weight:	800g (1.76 lb.)
  Environmental Specifications
  Ingress Protection Rating	IP56 enclosures
  Operating Environment
  Temperature: -20°C to 60°C (-4°F to 140°F)	Yes
  Humidity: 5% to 95% (Non-condensing)	Yes
  Storage Environment
  Temperature: -30°C to 70°C (-22°F to 158°F)	Yes
  Humidity: 5% to 95% (Non-condensing)	Yes
  Certification	CE/Safety
