Zyxel LTE3301-M209 LTE 2.4GHz 4G Indoor Router

• Description
• Specifications

• Zyxel LTE3301-M209 LTE 2.4GHz 4G Indoor Router


  Mobile technology creates opportunities for new operators to enter networking business with lower investment comparing to building fixed-line infrastructures. To fixed-line operators, mobile network is more important as a backup to offload congested bandwidth for higher customer satisfaction. Mobile network is the trend that operators can never resist. Zyxel, as a global leader of broadband networking, always stay ahead of the trend to offer the market with innovative designs.

  The LTE3301-M209 employs LTE — the latest mobile broadband technology with high popularity — to deliver the best possible data rates of up to 150/50 Mbps (DL/UL). With bridge and router modes embedded, the LTE3301-M209 is adaptive to all kinds of devices/gateways for seamless integration with your CPE (Customer Premise Equipment) on-hand in a simple yet complete way to meet your needs.

  Maximum freedom of mobility
  As LTE markets expand quickly, base station coverage is yet to be completed. The LTE3301-M209 supports single- (LTE) and multi-mode (LTE/3G/2G) so you can stay connected even of there is only 3G or 2G services. Besides, the multi-band support also relieves the concern from varied LTE/3G frequencies in different countries. The flexibility of LTE3301-M209 keeps you online around the world with the maximum freedom of mobility.

  Embedded bridge/router mode for all devices/gateways
  For network integration, Zyxel embeds both bridge and router modes into the LTE3301-M209. Users can take advantage of the built-in routing functions in all typical applications, while the bridge mode is designed to work with users’ existing or preferred device such as high-end WiFi Access Points, Small Business Gateways or Enterprise Gateways. With the two built-in modes, the LTE3301-M209 can be easily integrated with all kinds of devices/gateways.

  State-of-the-art technology
  The LTE3301-M209 employs 3GPP release 9, category 4 — the best practice of LTE technology with 150/50 Mbps (DL/UL) data rates. It also supports 3G/2G networks with the up-to-date “Dual Carrier HSPA+ (DC-HSPA+) technology” of 42/5.76 Mbps (DL/UL) data rates. You can enjoy ultra-fast, flexible wireless connection anywhere within LTE/3G/2G signal coverage.

  High-speed WiFi of up to 300 Mbps
  The LTE3301-M209 comes with 802.11n WiFi compatibility, so you can enjoy high-speed WiFi of up to 300 Mbps without additional devices. With the true wireless connection provided by the LTE3301-M209 of indoor router, there’s no cabling needed for either LTE WAN or wireless LAN.

  Application Diagram

• System Specifications
  IP Networking
  Support IPv4/IPv6 dual stack	Yes
  DHCP dynamic and fixed IP address assignment on LAN	Yes
  VPN pass-through firewall	Yes
  NAT/NAPT	Yes
  Port forwarding DMZ	Yes
  DNS/DDNS	Yes
  Support NAT router mode	Yes
  Support bridge mode (IP pass-through)	Yes
  WiFi Security
  WEP: 64/128-bit	Yes
  WPA/WPA2	Yes
  Support WPA2 primarily, automatic fallback to WPA	Yes
  WPA/WPA2-PSK	Yes
  MAC address filter with 32 addresses supported	Yes
  Management
  APN management	Yes
  SIM PIN management	Yes
  SMS management	Yes
  Secure remote management via WebGUI/SSH	Yes
  Over-the-Air (PTA) firmware upgrade: TR-069/WebGUI	Yes
  Hardware Specifications
  LTE Air Interface
  Standard compliant: 3GPP release 9 category 4	Yes
  Peak data rates:	150 Mbps DL / 50 Mbps UL
  LTE Bands:	1/3/7/8/20/28/38/40
  WiFi Air Interface
  IEEE 802.11 b/g/n 2.4 GHz, data rates up to 300 Mbps	Yes
  WiFi enabled device#: up to 32	Yes
  WiFi antenna: 2 internal antennas up to 3 dBi	Yes
  UMTS/GSM Air Interface
  Standard compliant: UMTS/HSPA Band 1/8	Yes
  GSM/GPRS/EDGE Band 3/8	Yes
  DC-HSPA+ downlink data rate up to 42 Mbps	Yes
  HSUPA uplink data rate up to 5.76 Mbps	Yes
  UMTS/WCDMA data rate up to 384 Kbps	Yes
  GPRS data rate up to 85.6 Kbps	Yes
  Hardware Interface
  Four 10/100 Mbps Ethernet RJ-45 LAN ports	Yes
  One 2FF mini SIM card socket	Yes
  One reset to default button	Yes
  One power on/off button	Yes
  One WiFi on/off button	Yes
  One DC power jack	Yes
  One WPS button	Yes
  Two external LTE antennas (up to 3 dBi)	Yes
  LED Indicators
  Power status	Yes
  Internet status	Yes
  LTE signal strength	Yes
  WiFi status	Yes
  LAN status	Yes
  Power Consumption	12W
  Physical Specifications
  Item dimensions (WxDxH)	186 x 120 x 30 mm (7.3″ x 4.7″ x 1.2″)
  Item weight	350g (0.77 lb.)
  Packing dimensions (WxDxH)	271 x 192 x 113 mm (10.67″ x 7.56″ x 4.45″)
  Packing weight	778g (1.72 lb.)
  Environmental Specifications
  Operating Environment
  Temperature: 0°C to 40°C (32°F to 104°F)	Yes
  Humidity: 10% to 90% RH (Non-condensing)	Yes
  Storage Environment
  Temperature: -10°C to 70°C (14°F to 158°F)	Yes
  Humidity: 0% to 95% RH (Non-condensing)	Yes
  Package Contents
  LTE indoor router	Included
  LTE antenna x 2	Included
  Power adapter	Included
  Ethernet cable	Included
  Quick start guide	Included
  Warranty card	Included

  Model	Band	LTE Frequency
  LTE3301-M209	Band 1	FDD UL: 1920 – 1980 MHz; DL: 2110 – 2170 MHz
  	Band 3	FDD UL: 1710 – 1785 MHz; DL: 1805 – 1880 MHz
  	Band 7	FDD UL: 2500 – 2570 MHz; DL: 2620 – 2690 MHz
  	Band 8	FDD UL: 880 – 915 MHz; DL: 925 – 960 MHz
  	Band 20	FDD UL: 832 – 862 MHz; DL: 791 – 821 MHz
  	Band 28	FDD UL: 703 – 748 MHz; DL: 758 – 803 MHz
  	Band 38	TDD UL/DL: 2570 – 2620 MHz
  	Band 40	TDD UL/DL: 2300 – 2400 MHz
