  The Yealink UVC86 is a 4K dual-eye tracking camera for medium and large rooms with a perfect display in everyone and every detail.

  With a built-in dual 4K camera and a range of AI-driven features, including Auto Framing, Speaker Tracking and Presenter Tracking, the UVC86 empowers your meeting space by reproducing every moment and detail precisely. Covering a wide field of view of 90° with a mechanical pan, the UVC86 tilt up and down easily via remote control or Yealink camera control plug-in software, bringing more efficient collaboration.

  Dual 4K Camera Pro-Grade Video Experience
  The Yealink UVC86 is a built-in dual-eye 4K camera with a panoramic camera to detect participants in real-time and a PTZ camera to capture the best picture of everyone in the room. Enjoy an accurate and smooth tracking experience wherever and whenever meeting participants are present. With 12X optical zoom and 90° field of view, the UVC86 captures every person in the room as well as ensures high-definition picture quality when zoomed in.

  Auto Framing automatically recognizes the number and the positions of attendees. It frames the first meeting participant and then continually adjusts as more participants enter the space, eliminating manual setups.

  Speaker Tracking frames a real-time close-up of the speaker, bringing a vivid face-to-face meeting experience and ensuring attendees are well-engaged.

  Presenter Tracking ensures the camera follows the presenters around the room when they are presenting, making them always in the center of the view of the camera. Remote participants could experience as good as they are in the room.

  Multiple Installations for Any Space
  Revolutionized new ID design and multiple installation options (on a conference table, on the top of a TV, on the wall, on the ceiling, onto a TV stand or a tripod) enable UVC86 to flexibly fix any professional meeting space according to your needs. Easy set-up and USB plug and play, UVC86 is right for your meeting from the first minute you start.

• Overview
  Operating System	Windows 7, Windows 10, Mac OS 10.10 or higher
  Protocol	UVC 1.0

  Camera Features
  Lens & Sensor	8MP, Sony Sensor
  Maximum Frame Rate	30FPS
  Zoom	20x HD zoom (12x optical + 1.7x digital)
  Field of View	90°
  Lens Cap	Electric lens cap
  Presets	√

  Audio Features
  Microphone	Support VCM34 array microphone
  Extension Mic	Support CPW90 wireless microphone
  Yealink Noise Proof Technology	–
  Beamforming Microphone Technology	–
  Full-duplex	–
  Echo Cancellation	–
  Speaker	–

  AI Features
  Auto Framing	√
  Speaker Tracking	√
  AI Face Enhancement	–

  Physical Connections
  USB Port	1x USB 3.0 Type-B, 1x USB 2.0 Type-A
  Audio Port	1x Yealink microphone port (RJ-45), 1x 3.5mm line-in
  Built-in Wi-Fi	–
  Power Adapter	AC 100~240V input, DC 48V/0.7A Output

  Configuration & Management
  Yealink Device Management Platform/Cloud Service	–
  Yealink RoomConnect
