• WyreStorm APO-210-UC Apollo Series Conference Speakerphone & Switcher with HDBaseT Out

  The APO-210-UC is the premium solution in the Apollo series of unified communication products. The APO-210 is a conference speakerphone and presentation switcher wrapped into one package. With a broad range of connectivity options, transmit video via local USB-C or HDMI, wirelessly with Miracast or AirPlay. Multiview capability allows up to two devices to share content simultaneously, promoting improved collaboration. An integrated USB 3.0 device port allows easy connection of peripheral equipment such as PTZ cameras. The APO-210 adds a HDBaseT output in addition to the HDMI out to support dual-screen meeting spaces.


  SPEAKERPHONE
  All Apollo series products feature a premium 360° omni-directional microphone array with echo cancellation, ensuring you can be heard loud and clear in every meeting. The powerful 10-watt speaker provides crystal clear audio delivery, even in the largest rooms.


  MULTIVIEW
  Two separate video devices can be transmitted at the same time in a split screen view using a combination of wired or wirelessly connected laptops, tablets, or smart phones.


  WIRED & WIRELESS
  Loaded with connectivity, the APO-200 & 210 support local connection via USB-C and HDMI, wireless casting via Miracast and AirPlay or casting from our APO-DG1 wireless dongle.


  CAPACITIVE TOUCH
  Intuitive capacitive touch buttons provide volume control, mic mute, and video mute for your meeting. An LED ring on the top of the speakerphone provides real-time feedback of volume level and mute status.

  In the Box
  1x Apollo Speakerphone
  1x 24V DC 5A PSU (US/UK/EU/AU)
  1x 1.5m USB-C cable (with USB-A adapter)
  1x 2m Mini USB-B 2.0 cable
  1x Quickstart Guide

• Category	Specification
  AUDIO & VIDEO
  Inputs	1x USB-C, 1x HDMI
  Outputs	1x HDMI, 1x HDBaseT
  Video Resolution (Max)	Display Link: 1920x1080p @30Hz, USB-C: 3840x2160p @30hz 8bit 4:4:4, 1920x1080p @60hz
  Maximum Pixel Clock	300 MHz
  SPEAKERPHONE
  Microphone	360° 4 x Mic Array
  Speaker	10 watts, 78 dB @ 1.5m/4.9ft, Sample Rate: 24bit 48KHz
  Control	Capacitive touch volume +/- and microphone mute buttons, Telnet API
  COMMUNICATION & CONTROL
  HDMI	HDMI 1.4
  HDBaseT	EDID
  USB	1x USB-C: USB 3.2 Gen 2×1
  LAN	1 x 8-pin RJ45
  RS-232	Passthrough over HDBaseT (requires compatible HDBaseT receiver)
  POWER
  Power Supply	24V DC 5A
  Max Power Consumption	Max with USB-C charging (60w): 80W
  Features
  Microphone Array	360° omni-directional with echo cancellation, AGC, and noise suppression
  Speaker Power	10-watt powerful speaker with clear audio delivery
  Control Buttons	Capacitive touch volume and mic control, including mute and USB host switching
  LED Feedback Ring	For volume level and mute status
  Mic Direction Indication	Real-time LED indication of mic pick-up direction
  Plug and Play	Simple plug-and-play design with a single USB connection
  USB-C Charging	Native USB-C for up to 60w device charging
  Content Support	Supports up to 4K 30 4:4:4 8bit content over HDMI and USB-C
  Wireless Casting	Supports Miracast (Windows/Android) and Apple AirPlay up to 1080p
  USB 3.0 Port	For additional USB device connection (e.g., CAM-200-PTZ, FOCUS Webcams)
  Multiview	Two laptops/tablets can share content simultaneously
  Conference Compatibility	Compatible with Microsoft Teams, Zoom, Skype, WebEx, etc.
  Output Flexibility	HDMI and HDBaseT output support long-distance transmissions and dual-screen setups
