• Vivolink 70m HDMI Extender Slim 4K With IR + RS-232 Control, Transmitter – VL120016T

  HDMI Extender slim 4K with IR + RS-232 control, Transmitter, 70m
  VL120016T is a mini-size HDBaseT Extender transmitter, supporting 1080P/ 4K signal transmission up to 131ft (40m), 1080P signal up to 230ft (70m) over single CAT5e/6 cable. VL120016 supports CEC, bidirectional RS232 & IR control, and one way-directional PoH function.

  Support up to 4K@60Hz 4:2:0 video signal transmission

  Max transmission distance is 4K 131ft (40m) and 1080P 230ft (70m) over single CAT5e/CAT6 cable

  High Bandwidth: 10.2Gbps

  Compliant with HDMI & HDCP1.4

  Use HDBaseT technology for extended capability and reliability

  Support ARC

  Bi-directional IR pass-through

• Category	Detail
  Features
  3D	Yes
  Bandwidth	10.2 Gbit/s
  Cable types supported	Cat5e/Cat6
  CEC pass-through	Yes
  Consumer Electronics Control (CEC) support	Yes
  HDBaseT certified	Yes
  HDCP	Yes
  HDCP & EDID bypass	Yes
  HDCP pass-through	Yes
  HDCP version	2.2
  IR pass-through	Yes
  LED indicators	Yes
  Maximum resolution	4096×2160 Pixels
  Maximum transfer distance	70 m
  Product colour	Black
  Remote control type	IR
  RS-232 pass-through	Yes
  Supported video modes	1080p
  Type	AV transmitter
  Wall mountable	Yes
  Legal Information
  EU ECCN Code	N/A
  US ECCN Code	5A992
  Operational conditions
  Operating relative humidity (H-H)	10 – 90 %
  Operating temperature (T-T)	0 – 50 °C
  Package dimensions (verified)
  Depth Verified	16 cm
  Gross Weight Verified	0.6 kg
  Height Verified	14.3 cm
  Width Verified	16.2 cm
  Packaging content
  AC adapter included	Yes
  Included power plug types	EU/GB
  IR blaster included	No
  IR receiver included	No
  Mounting brackets included	Yes
  Ports & interfaces
  3.5 mm (1/8-inch) in	Yes
  3.5 mm (1/8-inch) out	Yes
  Connectivity technology	Wired
  DC-in jack	Yes
  HDMI in	1
  HDMI version	1.4
  Number of HDMI outputs	1
  Remote (IR) input	1
  Remote (IR) output	1
  RJ-45 output ports	1
  RS-232 input ports	1
  RS-232 output ports	1
  Serial interface type	RS-232
  Serial ports quantity	2
  Video in	1
  Video out	1
  Power
  AC input frequency	50 / 60 Hz
  AC input voltage	100 – 240 V
  External power adapter	Yes
  Operating voltage	24 V
  Output current	1.25 A
  Power consumption (transmitter) (max)	11 Watt
  Power over Ethernet (PoE)	Yes
  Product dimensions
  Net Weight (Product, kg)	0.5 kg
  Product Depth	8.4 cm
  Product Height	1.62 cm
  Product Width	11.5 cm
  Technical details
  Audio support	Yes
  Vendor information
  Brand Name	Vivolink
  Warranty	3 Year(s)

• VL120016T : Product Datasheet
