Vivolink 4K In-Line HDMI EDID Emulator & Controller – VLHDMICTL1-MME

• Description
• Specifications
• Downloads

• Vivolink 4K In-Line HDMI EDID Emulator & Controller – VLHDMICTL1-MME

  4K in-line HDMI EDID emulator & controller. MME: Meetings Made Easy
  Automated meeting room control Control from room sensor or HDMI connection, CEC, RS-232 and IR, Relay control

  Enter meeting room or connect cable to your computer and all starts up automatically for you.

  When you leave room all switch off for you.

  True automated simple operation supporting 4K resolution.

  In detail:
  Projector/monitor will turn on
  Screen will go down
  When you leave room
  Projector/monitor will turn off
  Screen will go up again

  18G In-line HDMI EDID Emulator

  Designed for automatic system control in small meeting rooms and huddle spaces.

  Supports up to 4K x 2K/60Hz 4:4:4 HDR10 and Dolby Vision, HDCP 2.2 compliant.

  HDCP pass through or converted to HDCP 1.4 for better compatibility

  Supports 4K to1080p down-scaling.

  Comprehensive EDID management with 8 EDID Options (Including Auto & HDR) for various application.

  Automation display control via CEC, RS-232 and IR.

  Contact Closure input for connections with a variety of devices, such as sensor and switch.

  Relay control for device like projection screen

  Built-in signal equalizer, provides capability to use longer range HDMI cable.

• Category	Specification
  Design
  Housing colour	Black
  Legal Information
  EU ECCN Code	N/A
  US ECCN Code	EAR99
  Package dimensions (verified)
  Depth Verified	15.3 cm
  Gross Weight Verified	0.618 kg
  Height Verified	8 cm
  Width Verified	22.2 cm
  Power
  AC input voltage	110 – 230 V
  Product dimensions
  Net Weight (Product, kg)	0.5 kg
  Product Depth	15.3 cm
  Product Height	8 cm
  Product Width	22.2 cm
  Vendor information
  Brand Name	Vivolink
  Warranty	3 Year(s)

• VLHDMICTL1-MME : Product Datasheet
