• Vivolink 2×8 4K HDMI Splitter Switcher


  HDMI splitter switcher 2×8, 4K
  2 source selection 8 out HDMI 2.0 HDCP 2.2, volume control and turn on/off display

  Typical installations:
  In store for signal distribution to many screen.

  Shop front demo of TV´s

  Function:
  HDMI 8 outputs splitter with 2 sources selection.
  Support HDMI 2.0, HDCP 2.2 compliant.
  Digital Toslink and Analog L+R for audio de-embedding.
  Built-in signal equalizer, provides capability to use longer range HDMI cable.
  Comprehensive EDID management, lowest/highest resolution can be chosen on the front panel while having 14 in-built preset EDIDs for various application.
  Turn ON/OFF displays and adjust displays & analog audio output’s volume via CEC commands by front panel buttons.

• Category	Detail
  Features
  3D	Yes
  Easy to install	Yes
  HD type	4K Ultra HD
  HDCP	Yes
  Housing material	Metal
  LED indicators	Yes
  Maximum refresh rate	60 Hz
  Maximum resolution	3840 x 2160 Pixels
  Number of displays supported	8
  Plug and Play	Yes
  Power LED	Yes
  Product colour	Black
  Supported video modes	3840p
  Legal Information
  EU ECCN Code	N/A
  UNSPSC Code	52161556
  US ECCN Code	EAR99
  Operational conditions
  Operating temperature (T-T)	0 – 50 °C
  Package dimensions (verified)
  Depth Verified	16 cm
  Gross Weight Verified	1.156 kg
  Height Verified	10.3 cm
  Width Verified	37.8 cm
  Packaging content
  AC adapter included	Yes
  User guide	Yes
  Packaging data
  Quantity per box	1 pc(s)
  Ports & interfaces
  DC-in jack	Yes
  Ethernet LAN	No
  HDMI version	1.4/2.0
  Video out	8x HDMI
  Video port type	HDMI
  Video ports quantity	8
  Power
  Input voltage	110v – 230v V
  Product dimensions
  Net Weight (Product, kg)	0.9 kg
  Product Depth	10 cm
  Product Height	2 cm
  Product Width	32.4 cm
  Technical details
  Cascadable	Yes
  Connector type	HDMI
  Maximum cable length	100 m
  Vendor information
  Brand Name	Vivolink
  Warranty	3 Year(s)

• VLHDMISP2X8 : Product Sheet
