ViewSonic VA2215-H 22″ Full HD Monitor

ViewSonic VA2215-H

22″ Full HD Monitor

• Description
• Specifications
• Warranty
• Downloads

• OVERVIEW
  The ViewSonic VA2215-H is a 22” Full HD monitor with HDMI and VGA input for business or home usage. Delivering a stunning image quality with low power consumption, this monitor provides six ViewMode presets that deliver optimized screen performance based on your needs. FreeSync means no tearing or stuttering even when gaming. The eye care technology that comes standard with all VA monitors helps to eliminate eyestrain from extended viewing periods. A VESA-compatible mount makes this monitor is easy to setup on the wall or with a wide range of industry-standard mounts.

  Viewing Clarity from Wide Angles
  Enjoy superb performance and better viewing quality from horizontal to vertical angles. With SuperClear® Vertical Alignment panel technology, the monitor remains clear and in good contrast color from 178° all around, whether you are looking at the screen from above, below, the front, or the side.
  SuperClear® 178°/178°

  Smooth Visuals With 100Hz Refresh Rate
  With a fast 100Hz screen refresh rate, you can experience a truly fluid visual display. This results in improved viewing clarity, reduced screen stutter during fast-moving action scenes, and benefits work-related tasks, reducing eye strain and increasing productivity.
  100Hz Refresh Rate

  React Instantly
  Experience better performance and smooth pixel transitions with a fast 1ms (MPRT) response time. React faster and work with precision.
  1ms Response Time

  Full HD 1080p
  Full HD 1920×1080 resolution creates unbelievably clear pixel-by-pixel image performance. Experience amazing clarity and detail while working, gaming, or enjoying the latest entertainment.
  Full HD 1080P

  AMD FreeSync™ Delivers Smooth, Continuous Visuals
  With AMD FreeSync™ technology, it eliminates screen tearing and choppy frame rates to provide seamless, flawlessly smooth visuals in every scene.
  100Hz FreeSync

  Comfortable Viewing
  Flicker-Free technology and a Blue Light Filter help to eliminate eye strain from extended viewing periods.
  Flicker Free

  Blue Light Filter

  Color Rendering Options
  ViewSonic’sViewMode feature offers “Game”, “Movie”, “Web”, “Text”, and “Mono” presets. These presets enhance gamma curve, color temperature, contrast, and brightness to deliver an optimized viewing experience for different uses.
  ViewMode: Game/Movie/Web/Text/Mono/Mac

  Low Energy Consumption
  Designed for energy efficiency in mind, ViewSonic’s Eco Mode results in a smaller carbon footprint and reduced office overhead costs.
  Eco Mode

  I/O ports

• Display
  Display Size (in.):	22
  Viewable Area (in.):	21.5
  Panel Type:	VA Technology
  Resolution:	1920 x 1080
  Resolution Type:	FHD (Full HD)
  Static Contrast Ratio:	3,000:1 (typ)
  Dynamic Contrast Ratio:	50M:1
  Light Source:	LED
  Brightness:	250 cd/m² (typ)
  Colors:	16.7M
  Color Space Support:	8 bit true
  Aspect Ratio:	16:9
  Response Time (MPRT):	1ms
  Viewing Angles:	178º horizontal, 178º vertical
  Backlight Life (Hours):	30000 Hrs (Min)
  Curvature:	Flat
  Refresh Rate (Hz):	100
  Variable Refresh Rate Technology:	FreeSync
  Blue Light Filter:	Yes
  Flicker-Free:	Yes
  Color Gamut:	NTSC: 72% size (Typ)
  sRGB:	104% size (Typ)
  Pixel Size:	0.249 mm (H) x 0.241 mm (V)
  Surface Treatment:	Anti-Glare, Hard Coating (3H)

  Compatibility
  PC Resolution (max):	1920×1080
  Mac® Resolution (max):	1920×1080
  PC Operating System:	Windows 10/11 certified; macOS tested
  Mac® Resolution (min):	1920×1080

  Connector
  VGA:	1
  3.5mm Audio Out:	1
  HDMI 1.4:	1
  Power in:	DC Socket (Center Positive)

  Power
  Eco Mode (Conserve):	13W
  Eco Mode (optimized):	15W
  Consumption (typical):	17W
  Consumption (max):	22W
  Voltage:	AC 100-240V
  Stand-by:	0.5W
  Power Supply:	External Power Adaptor

  Additional Hardware
  Kensington Lock Slot:	1

  Controls
  Physical Controls:	U, R, D, L, EN (power)
  On Screen Display:	Input Select, Audio Adjust, ViewMode, Color Adjust, Manual Image Adjust, Setup Menu

  Operating Conditions
  Temperature:	32°F to 104°F (0°C to 40°C)
  Humidity (non-condensing):	20% to 90%

  Wall Mount
  VESA Compatible:	75 x 75 mm

  Input Signal
  Frequency Horizontal:	RGB Analog: 24 ~ 86KHz, HDMI (v1.4): 30 ~ 125KHz
  Frequency Vertical:	RGB Analog: 48 ~ 75Hz, HDMI (v1.4): 48 ~ 100Hz

  Video Input
  Digital Sync:	TMDS – HDMI (v1.4)
  Analog Sync:	Separate – RGB Analog

  Ergonomics
  Tilt (Forward/Back):	-5º / 20º

  Weight (imperial)
  Net (lbs):	5.3
  Net Without Stand (lbs):	4.4
  Gross (lbs):	7.7

  Weight (metric)
  Net (kg):	2.4
  Net Without Stand (kg):	2
  Gross (kg):	3.5

  Dimensions (imperial) (wxhxd)
  Packaging (in.):	22.4 x 15.1 x 4.6
  Physical (in.):	19.4 x 14.8 x 7.4
  Physical Without Stand (in.):	19.4 x 11.1 x 1.5

  Dimensions (metric) (wxhxd)
  Packaging (mm):	570 x 383 x 118
  Physical (mm):	492 x 377 x 188
  Physical Without Stand (mm):	492 x 282 x 38

  General
  Regulations:	cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, IQC-ST, NOM, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, UKCA, BSMI, TGM, BIS
  PACKAGE CONTENTS:	VA2215-H x1, HDMI Cable (v1.4; Male-Male) x1, AC/DC Adapter x1, Quick Start Guide x1
  Recycle/Disposal:	Please dispose of in accordance with local, state or federal laws.
  Warranty:	*Warranty offered may differ from market to market
  Power Management:	Energy Star standards, EPEAT

• ViewSonic Warranty page – United Kingdom

  ViewSonic Product Family	UK
  Monitors [VA / VX Series]	2 Year Pickup, Repair and Return
  Monitors [VG, VP ,TD and XG Series]	3 Year Pickup, Repair and Return
  Projector [PA5, PA7, PJD5 Series – except short throw models]	2 Year Pickup, Repair and Return [Lamp 1 Year or 1,000 hours]
  Projector [PJD5 Series short throw models, PJD6, PJD7, PJD8, Pro, PX, PS and PG Series]	3 Year Pickup, Repair and Return [Lamp 1 Year or 1,000 hours]
  Projector [Pro8 series]	3 Year Pickup, Repair and Return [Lamp 3 Years or 2,000 hours]
  Projector [PA503XB & PS501X+]	5 Year Swap [Light source 5 Years or 5,000 hours]
  Projector [M]	2 Year Pickup, Repair and Return [Light source 2 Years or 20,000 hours]
  Projector [X / LS5 / LS60&61 Series]	5 Year Pickup, Repair and Return [Light source 5 Years or 20,000 hours]
  Projector [Laser Series]	5 Year Swap [Light source 5 Years or 20,000 hours]
  Smart Display [VSD] / NMP	2 Year Pickup, Repair and Return
  Digital Pen WhiteBoard	2 Year Swap
  Included Accessories [Battery, Power Supplies, Cables, Remotes, 3D Glasses etc]	Same as Product Warranty
  Peripherals [LFD/IFP stands, Projector Screens/Mounts/Cases etc.]	1 Year Swap
  Peripherals [Wifi Modules, VB-Series and all other electronic peripherals]	2 Year Swap
  Large Format Display [Up to and including 55”]	3 Year Pickup, Repair and Return
  Large Format Display [Larger than 55”]	3 Year Onsite Repair
  Interactive Flat Panel [<55”]	3 Year Pickup, Repair and Return
  LED Display / Interactive Flat Panel [55” and above]	5 Year Onsite Repair or Replacement
  ePosters [10”]	2 Year Pickup, Repair and Return
  ePosters [Up to and including 55”]	3 Year Pickup, Repair and Return
  Slot-In PC (for LFD and IFP)	3 Year Pickup, Repair and Return
  All product groups	14 Days DOA Replacement




  Customer Service For All Countries – Please click here to find the correct contact details of your respective Call Desk or Service Centre.

  ViewSonic^® Limited Warranty

  ViewSonic warrants its products to be free from defects in material and workmanship during the warranty period. If a product proves to be defective in material or workmanship during the warranty period, ViewSonic will, at its sole option, repair or replace the product with a similar product. Replacement Product or parts may include remanufactured or refurbished parts or components.

  For more terms and conditions and on what the warranty does not cover please refer to our Standard Limited Warranty Summary.

  How to get service:

  • For information on obtaining warranty service, call your ViewSonic dealer or ViewSonic Call Desk / Service Provider or ViewSonic; refer to the Contact Us page located in each country’s corresponding web site:
  • To obtain warranty service, you will be required to provide.
    1. The original dated sales slip. (Invoice or Proof of purchase)
    2. Your name.
    3. Your address.
    4. The serial number, IMEI number and the model number of the product.
    5. A description of the problem.
    6. Mobile and wireless products and All-in-One, customers should provide the user name and the password in order to access the device and perform warranty service.
  • For DOA cases apart from above the followings are also required.
    1. A photo showing the defect symptom.
    2. A photo of the unit serial number with the bar code.
    3. A photo showing the condition of the original container.
  • For additional information or the name of the nearest ViewSonic service centre, contact your ViewSonic dealer or ViewSonic.

  If the warranty on your product has already expired:

  In case your product is no longer within its warranty period, but you’d like to have it repaired, you can still contact our Call Desk or Repair Center in your country of residence, but you will be charged directly by our Repair Center on the service.

  Accessories:

  For enquiries on accessories/spare parts please either contact your local dealer or contact us directly at [email protected]
  Lamp warranty is based either on the lamp usage hour or on the age of the projector unit, and depending on which ever one that expires first.


  Pixel Policy:

  At ViewSonic we offer some of the most competitive pixel policy in the market.



• DATASHEETS	Download
  VA2215-H Datasheet (short version)	Download

  USER GUIDE	Download
  TD3207 User Guide (English)	Download

  QUICK START GUIDE	Download
  VA2215-H Quick Start Guide	Download
