• ViewSonic TD2465

  24″ Frameless PCAP Touch Screen Monitor

  OVERVIEW
  The ViewSonic’s TD2465 is the ideal solution for commercial and industrial spaces. Designed for wet hands touch, glove touch, and for any conductive stylus’ tip touch including pencil. The TD2465 delivers an intuitive 10-point PCAP touch technology for maximum interactivity. Featuring ViewSonic Touch Controller software, allowing you to control the device intuitively. Connection options include HDMI and DisplayPort inputs for effortless sharing capabilities. Equipped with VESA mounting design for any surface and Kiosk, the touch screen is the perfect display for various.

  Designed For Versatile Installation Options
  The 24″ touch monitor is your one-stop solution for industrial, retail, and commercial applications. Whether a self-ordering kiosk or industrial automation control unit, the TD2465 delivers versatile installation options and an intuitive 10-point touch response technology.

  Intuitive and Responsive Touch
  Experience a smooth, and responsive touchscreen with the high-sensitive Projective Capacitive (PCAP) Touch Technology. With up to 10 touch point simultaneous input, each touch response is read with accuracy and precision.
  *Single point touch option is also available, as well as Pen Touch Mode, Glove Touch Mode, and Water-Resistant Touch Mode.
  10-Point PCAP Touch

  Made for tough conditions
  The TD2465 is able to register fingerprints even when your hands are wet. Ideal for those situations where you often get your hands wet, and you need your equipment to keep up.
  Wet Hand Touch

  Glove Touch Mode
  Different tasks require different accessories, and gloves are no exception. Glove touch successfully eliminates the hassle of removing your gloves every time you need to perform an action onscreen.
  *If gloves do not meet material design specifications this may not apply.
  *Water-Resistant Touch and Pen Touch modes cannot be used at the same time as Glove Touch.
  *Glove Touch Mode does not support palm rejection.
  *With up to 5 points touch points. Even single point touch option is also available, as well as Pen Touch Mode, Glove Touch Mode, and Water-Resistant Touch Mode.
  Functional with Multiple Glove Types

  Water Tolerant Surface
  Designed to work when you need it. Work in humid conditions without an issue with the TD2465’s Water-Resistant Touch mode.
  *Panels are not designed for environments exposed to full sun or rain.
  *Glove Touch and Pen Touch Modes cannot be used at the same time as Water-Resistant Touch.
  *Water-resistant touch mode does not support Palm Rejection.*With up to 5 points touch points. Even single point touch option is also available, as well as Pen Touch Mode, Glove Touch Mode, and Water-Resistant Touch Mode.
  Water-Resistant Touch

  Stylus Compatibility
  The TD2465 is equipped with palm rejection and full support for multiple types of pen. Passive, active pen can be used without the hassle of installing drivers. Click functions are even enabled for pencils.
  *TD2465 does not support pressure sensitivity and tilt functions for pen writing.
  *When hand and pen are in contact with the screen simultaneously, only the pen’s signal will register.
  *Water-Resistant Touch and Glove Touch Modes cannot be used at the same time as Pen Touch.
  Pen Compatibility & Palm Rejection

  Advanced Ergonomics
  The TD2465 comes complete with two types of monitor stands to ensure you have the setup you need no matter the situation. The book stand is designed with an advanced hinge, allowing the display to be tilted and adjusted between 15 ° ~70°, making it great for diverse applications. The classic stand is perfect for more conventional uses, with a tilt angle of up to 20°.

  Book Stand & Standard Stand

  Easy Kiosk Integration
  The 4-sides frameless design of the TD2465 display allows for seamless and secure attachment to your preferred kiosk design, allowing it to be installed and integrated to best suit any application you require.
  4-Sides Frameless

  Touch Controller Software
  Intuitive interface design offers shortcuts for an easy way to adjust volume, brightness, contrast, and touch modes.
  *The software is compatible with Windows, Linux Fedora 37 and Ubuntu 20.04 platform. Download the software in the download section.
  *Please keep screen surface clean from water droplets and oil stains when switching between different touch modes or touch disable.
  *During the Touch Controller SW update process, if the network disconnects the Touch Controller SW will not be able to launch. Users will need to uninstall, then reinstall the software.

  Dimension & I/O Ports


• Display
  Display Size (in.)	24
  Viewable Area (in.)	23.8
  Panel Type	VA Technology
  Resolution	1920 x 1080
  Resolution Type	FHD (Full HD)
  Static Contrast Ratio	3,000:1 (typ)
  Dynamic Contrast Ratio	20M:1
  Light Source	LED
  Brightness	250 cd/m² (typ)
  Colors	16.7M
  Color Space Support	8 bit (6 bit + Hi-FRC)
  Aspect Ratio	16:9
  Response Time (Typical GTG)	7ms
  Response Time (GTG w/OD)	6.969ms
  Response Time (Typical Tr+Tf)	16ms
  Viewing Angles	178º horizontal, 178º vertical
  Backlight Life (Hours)	30000 Hrs (Min)
  Curvature	Flat
  Refresh Rate (Hz)	60
  Blue Light Filter	Yes
  Flicker-Free	Yes
  Color Gamut	NTSC: 72% size (Typ), sRGB: 102% size (Typ)
  Pixel Size	0.275 mm (H) x 0.275 mm (V)

  Touch Screen
  Touch Screen	Projected Capacitive, 10-point multi-touch
  Surface Treatment	Glossy, Hard Coating (7H)
  Cover Glass Thickness	1.2mm

  Compatibility
  PC Resolution (max)	1920×1080
  Mac® Resolution (max)	1920×1080
  PC Operating System	Windows 10/11 certified; macOS tested
  Mac® Resolution (min)	1920×1080

  Connector
  VGA	1
  USB 3.2 Type A Down Stream	2
  USB 3.2 Type B Up Stream	1
  3.5mm Audio In	1
  3.5mm Audio Out	1
  HDMI 1.4	1
  DisplayPort	1
  Power in	3-pin Socket (IEC C14 / CEE22)

  Audio
  Internal Speakers	2 Watts x 2

  Power
  Eco Mode (Conserve)	20W
  Eco Mode (optimized)	22W
  Consumption (typical)	24W
  Consumption (max)	26W
  Voltage	AC 100-240V
  Stand-by	0.5W
  Power Supply	Internal Power Supply

  Additional Hardware
  Kensington Lock Slot	1
  Cable Organization	Yes

  Controls
  Physical Controls	1, 2, Up, Down, Power
  On Screen Display	Auto Image Adjust, Contrast/Brightness, Input Select, Audio Adjust, Color Adjust, Information, Manual Image Adjust, Setup Menu, Memory Recall

  Operating Conditions
  Temperature	32°F to 104°F (0°C to 40°C)
  Humidity (non-condensing)	20% to 90%

  Wall Mount
  VESA Compatible	100 x 100 mm

  Input Signal
  Frequency Horizontal	RGB Analog: 24 ~ 82KHz, HDMI (v1.4): 15 ~ 82KHz, DisplayPort (v1.2): 15 ~ 82KHz
  Frequency Vertical	RGB Analog: 50 ~ 75Hz, HDMI (v1.4): 24 ~ 75Hz, DisplayPort (v1.2): 24 ~ 75Hz

  Video Input
  Digital Sync	TMDS – HDMI (v1.4), PCI-E – DisplayPort (v1.2)
  Analog Sync	Separate/Composite/SOG – RGB Analog

  Ergonomics
  Tilt (Forward/Back)	-5º / 20º

  Weight (imperial)
  Net (lbs)	12.5
  Net Without Stand (lbs)	10.4
  Gross (lbs)	15.8

  Weight (metric)
  Net (kg)	5.7
  Net Without Stand (kg)	4.7
  Gross (kg)	7.2

  Dimensions (imperial) (wxhxd)
  Packaging (in.)	25.5 x 16.8 x 5.4
  Physical (in.)	21.6 x 15.8 x 7.8
  Physical Without Stand (in.)	21.6 x 12.8 x 1.9

  Dimensions (metric) (wxhxd)
  Packaging (mm)	647 x 426 x 138
  Physical (mm)	550 x 401 x 198
  Physical Without Stand (mm)	550 x 326 x 49

  General
  Regulations	cTUVus, FCC-B, ICES003, Energy Star, EPEAT, CEC, NOM, Mexico Energy, CE, CE EMC, CB, RoHS, ErP, REACH, WEEE, EAC, UkrSEPRO, UKCA, BSMI, RCM
  PACKAGE CONTENTS	TD2465 x1, 3-pin Plug (IEC C13 / CEE22) x1, HDMI Cable (v1.4; Male-Male) x1, USB A/B Cable (v3.2; Male-Male) x1, Quick Start Guide x1
  Recycle/Disposal	Please dispose of in accordance with local, state or federal laws.
  Warranty	*Warranty offered may differ from market to market
  Power Management	Energy Star standards, EPEAT
