ViewSonic PG707X Business/Education Projector – 4000 Lumens, 4:3 XGA

ViewSonic PG707X Business/Education Projector

4000 Lumens, 4:3 XGA

• Description
• Specifications
• Downloads

• OVERVIEW
  ViewSonic PG707X is a practical 4,000 ANSI Lumens XGA business/education projector. With a throw ratio match for mainstream installation conditions and 1.3x optical zoom, it serves as a hassle-free upgrade choice for users to easily get bright and large images with low cost-per-inch in small-to-medium meeting/training rooms. Adding on to that are the energy-efficient 20,000 hours long lamp life and comprehensive LAN control compatibility, making it even more favorable to cost-effective and efficient management.

  Bright Images in Business/Education Environments
  Packed with 4,000 ANSI Lumens and a 22,000:1 contrast ratio, this projector can deliver bright and detailed images.
  4,000 ANSI Lumens

  Larger Screen Size with Lower Cost-per-inch
  The projector allows for an up-to-300” image size, which is much larger and also easier to install than commercial displays.

  Hassle-free Equipment Upgrade
  With a throw ratio matching mainstream installation conditions, the projector can be fitted to an existing ceiling mount and projection screen without changing the setup completely.
  1.51-1.97 throw ratio

  Adaptable to Any Environment
  Equipped with a 1.3x optical zoom lens, the projector empowers users to choose the most ideal set-up location within a wider throw distance range that doesn’t interfere with existing interior design while still getting the desired image size.
  1.3x Optical Zoom

  Reliable Long-term Performance
  The latest SuperEco+ mode technology greatly extends the lamp life of the projector from 15,000 hours to 20,000 hours – meaning 4 hours a day for more than 13 years – saving you maintenance cost and effort.

  Centralized Control for Management Efficiency
  This projector is compatible with Crestron, AMX, PJ Link, ATEN and Extron systems and comes equipped with ViewSonic vController, an easy-to-use network management tool.

  Easy Image Adjustment
  Horizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.

  A Simpler Way to Update Projector Software
  ViewSonic Projector Software Update is available online and enables you to keep your projector firmware up to date easily and conveniently; no need to take your projector in to a service center for software updates.

  *The latest projector software update can be found in the download section at the bottom of the page when available.

  SuperColor™ Accuracy
  ViewSonic’s proprietary SuperColor™ Technology displays a wide color range, ensuring that users enjoy a true-to-life color performance in both bright and dark environments without sacrificing image quality.

  Satisfying Audio Performance
  The projector is embedded with a 10W speaker to deliver satisfying audio performance right out of the box.

  Sufficient Connectivity
  The projector provides dual HDMI ports to connect to your multimedia devices, ready for expanding your audiovisual experience.

  USB Type-A Power Supply
  A built-in USB power output (5V/1.5A) can be used to supply power to HDMI dongles, eliminating the need for separate power adapters for connected dongles.

  Exterior & Rear I/O Connectors

• Specification	Value
  Projection System	0.55″ XGA
  Native Resolution	1024×768
  Brightness	4000 (ANSI Lumens)
  Contrast Ratio (SuperEco Mode)	22000:1
  Display Color	1.07 Billion Colors
  Light Source Type	Lamp
  Light Source Life (Normal)	6000 hours
  Light Source Life (SuperEco)	20000 hours
  Lamp Watt	203W
  Lens	F=2.59-2.87, f=16.88-21.88mm
  Projection Offset	115%+/-5%
  Throw Ratio	1.51-1.97
  Optical Zoom	1.3x
  Digital Zoom	0.8x-2.0x
  Image Size	30″-300″
  Throw Distance	0.9m-12m, (100″@3.1m)
  Keystone	H:+/-40°, V:+/-40°
  Audible Noise (Normal)	32dB
  Audible Noise (Eco)	28dB
  Input Lag	16ms
  Resolution Support	VGA(640 x 480) to FullHD(1920 x 1080)
  HDTV Compatibility	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
  Video Compatibility	NTSC, PAL, SECAM
  Horizontal Frequency	15K-102KHz
  Vertical Scan Rate	23-120Hz
  Input
  Computer in (share with component)	1
  Composite	1
  HDMI	2 (HDMI 1.4/ HDCP 1.4)
  Audio-in (3.5mm)	1
  Output
  Monitor out	1
  Audio out (3.5mm)	1
  Speaker	10W
  USB Type A (Power)	1 (5V/1.5A)
  Control
  RS232 (DB 9-pin male)	1
  RJ45 (LAN control)	1
  Others
  Power Supply Voltage	100-240V+/- 10%, 50/60Hz, (AC in)
  Power Consumption	Normal: 280W, Standby: <0.5W
  Operating Temperature	0~40℃
  Net Weight	2.35kg
  Dimensions (WxDxH) with Adjustment Foot	294x218x110mm
  OSD Language	English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, India, Arabic, Vietnamese, Greek, Total 23 languages
  Standard Accessory
  Power Cord	1
  VGA Cable	1
  Remote Control	1 (w/ laser pointer)
  QSG	1

• Category	Download
  Datasheets	Download
  User Guides	Download
  Quick Start Guide	Download
  Driver & Software	Download
  Technical Document	Download
