ViewSonic IFP8662 – 86″ 4K Touch Enabled ViewBoard Smart Display

ViewSonic IFP8662

86″ 4K Touch Enabled ViewBoard Smart Display

ULTRA HD RESOLUTION: 86 Inch 4K Ultra HD (3840x2160p) with a bezel-less Interactive Display

TOUCH PRECISION: 20-point PCAP touch technology lets multiple users write on the screen with their fingers and active styluses

ONE CABLE SOLUTION: Convenient USB-C for connected devices

BE HEARD: Built-in Microphone Array with echo cancellation and noise reduction technology

• Description
• Specifications
• Warranty

• Product Overview
  From executive boardrooms to interactive huddle spaces, the ViewSonic® ViewBoard® IFP8662 enables limitless collaboration and endless innovation. Designed to help teams connect, collaborate, and create, this next-generation digital whiteboard delivers exactly what you need to move your ideas forward. A premium, state-of-the-art design features a bezel-less PCAP (projected capacitive) touchscreen with incredible 4K Ultra HD resolution. This highly accurate interactive screen provides for an incredibly natural and responsive handwriting experience. Using fingers, styluses, or both, multiple users can simultaneously write or draw on the huge 86” ViewBoard panel. What’s more, meetings and presentations start fast thanks to convenient one-wire USB-C connectivity.

  Built-in Microphone Array
  An integrated microphone array with echo cancellation and noise reduction technology delivers clear speech and sound during video conferences. The microphone can also pick up sound from up to 26 feet away.

  Optional Slot-in PC
  Based on your specific collaboration needs, you can choose an optional ViewSonic slot-in PC to provide additional computing power and advanced features. Options include Intel Core i5 and i7 processors, as well as Windows 10 Pro and Zoom Room systems.

• Parameter	Specification
  UPC	766907012088
  Display Type	LCD
  Screen Size	86
  Viewable Area (in.)	85.6
  Light Source	LED
  Display Resolution	3840 x 2160
  Aspect Ratio	16:9
  Static Contrast Ratio	1,200:1
  Backlight Life (Hours)	50,000
  Brightness	350 cd/m2
  Response Time (Typical GTG)	8ms
  Viewing Angles	178º horizontal, 178º vertical
  Panel Surface	Anti-glare 9H tempered glass
  Ethernet LAN	(10/100/1000M) (USB Type-C & Android 10/100, PC 10/100/1000)
  OS	Android 8.0
  CPU	ARM Quad Core Cortex A73
  CPU Processor Speed	1.2GHz
  Memory	3GB
  Storage	32GB
  Internal Speakers	12W (x2)
  Subwoofer	15W (x1)
  HDMI 2.0 In	4
  HDMI 4K Out	1
  3.5mm Audio Out	1
  SPDIF Audio Out	1
  USB 3.0	5
  USB 2.0	1
  USB 3.1 Type C	1
  Slot-in PC Slot	1
  USB B Touch Port	2
  RS232	1
  Ethernet LAN (RJ45)	2
  WIFI Module Slot	1
  Intel® OPS Slot In (80-pin)	1
  Voltage	100-240 VAC
  Consumption (max)	580W
  Consumption (typical)	160W
  Stand-by	<0.5W
  Temperature	32-104º F (0 – 40º C)
  Humidity (non-condensing)	10-90%
  Touch Technology	Projective Capacitive
  Touch Points	Windows: 20, Android: 20
  Tip Detection	Finger or Active Pen
  Net (lbs)	140.4
  Gross (lbs)	185.7
  Net (kg)	63.7
  Gross (kg)	84.3
  Packaging (in.)	83.2 x 50.8 x 10.6
  Physical (in.)	77.2 x 46.1 x 3.1
  Packaging (mm)	2113.0 x 1290.0 x 270.0
  Physical (mm)	1960.0 x 1171.0 x 80.0
  VESA Compatible	800 x 600 mm
  Warranty	3-year limited warranty on parts, labor and backlight, onsite warranty
  Recycle/Disposal	Please dispose of in accordance with local, state or federal laws.
  Package Contents	IFP8662 display, power cable, HDMI cable, USB cable Type C, USB Cable for Touch, Passive Stylus x 2, RS232 Adapter, Clamp x 5, remote control with batteries, Camera plate, screw x 8, Quick Start Guide
  Regulations	CTUVus, FCC, Energy 8.0, EPEAT, Mexico, CE, CB, ErP, REACH, UKCA

• Warranty

  ViewSonic provides customers with the security of a manufacturer’s warranty against defected products. We are keen to provide our customers with great peace of mind and confidence in our product. With that in mind, we are now providing 3 years limited warranty on selected*
  ViewSonic Interactive ViewBoards.
