Viewsonic 1080p 5000 Lumens Laser Installation Projector | LS740HD

• Description
• Specifications
• Downloads

• Viewsonic 1080p 5000 Lumens Laser Installation Projector

  The LS740HD belongs to ViewSonic’s Luminous Superior series, a lamp-free high-brightness projector line up designed for commercial and educational spaces. With its adoption of the 3rd generation laser phosphor technology, it delivers 5,000 ANSI Lumens for up to 30,000 hours, ensuring bright and vivid images without lamp replacement. The lamp-free design offers an eco-friendly and cost-effective solution, while the projector‘s light weight and compact design reduces transportation costs. With up to 300“ projection in 1080p Full HD with high native contrast, it is well-suited for boardrooms, lecture halls, and public spaces. This projector features a1.3x optical zoom, H/V keystone, 4 corner adjustment, 360° projection, and a portrait modefor easy setup and versatile applications.

  Bright, Compact, Durable
  The LS740HD incorporates advanced 3rd-gen laser phosphor technology, enhancing brightness by 20% and achieving better luminous efficiency, all while being 32% more compact and more accessible than the previous generation. Its lamp-free light source offers instant power on/off and a lifespan of up to 30,000 hours without maintenance, ensuring consistent image quality even during extended periods ofuse.
  3rd Generation Laser Phosphor Technology


  Bright Images for Large Venues
  Delivering 5,000 ANSI Lumens, the LS740HD provides vibrant and sharp projection in 1080p FHD in all lighting conditions for auditoriums, boardrooms, public venues, and other expansive spaces.
  5,000 ANSI Lumens

  Unmatched Contrasts, Enhanced Visibility
  The projector’s high native contrast ratio, achieved through its Texas Instruments 0.65″DMD chip, enables deeper blacks and brighter whites. As a result, it delivers more visual depth, clearer images, and enhanced legibility.
  High Native Contrast Ratio


  Ultra-large Screen with Lower Cost-per-inch​
  This easy-to-install projector allows for an image size of up to 300”, offering a lower cost-per-inch compared to other types of commercial displays.​
  Up to 300”

  Easy and Cost-effective Installation
  The LS740HD is 35% lighter in weight and 35% smaller in size compared to its predecessor and even most competing projectors in the market, greatly reducing the cost of transportation and increasing the ease of installation.​
  Lighter Weight, Compact Size


  Save on Costs and Energy
  With its advanced lamp-free light source, the LS740HD offers a highly energy-efficient and cost-saving display solution by consuming up to 51% less power than competing projectors.
  Less Power Consumption

  Enhanced Installation Flexibility
  Equipped with a 1.3x optical zoom, the projector allows users to choose the most ideal set-up location with in a range, getting the desired image size without needing to change the existing interior design. ​
  1.3x Optical Zoom

  Get ​​Perfectly-shaped Images Effortlessly
  Horizontal and Vertical Keystone correction along with 4 corner adjustment features eliminate crooked or distorted images for a perfectly proportioned picture every time.
  H/V Keystone Correction, 4 Corner Adjustment

  Versatile Creative Application​s
  The projector can rotate vertically at any angle, enabling projection onto ceilings, walls, or floors, and its portrait mode further expands its capabilities for projection mapping, staging, and creative advertising applications.
  360° Projection, 90° Portrait Mode

  Present the Best with Vibrant Colors​
  Impress any audience with ViewSonic’s exclusive color technology, elevating your present ation with a true-to-life color experience.

  Non-stop 24/7 Operation
  The projector’s advanced cooling design enables 24/7 operation without any degradation in image quality or performance. This makes it the go-to solution for applications that require continuous projection in retail stores, malls, museums, airports, and other public spaces.

  A Simpler Way to Update Projector Software​
  Skip trips to the service center by keeping software up to date easily via USB cable connection with your own laptop.

  Directly Power Wireless HDMI Dongle
  The built-in 5V/1.5A USB-A output conveniently delivers power to a wireless HDMI dongle, eliminating the need for separate power adapters when streaming multi media content.
  USB-A Power Supply​​​

  Enhanced Dust Resistance
  Maintain crystal-clear image quality and product longevity with an advanced IP6X sealed engine design that prevents dust from entering and affecting internal components.​
  IP6X

  Dimensions & I/O Ports

  1 Front IR
  2 Lens
  3 Focus Ring
  4 HDMI x2
  5 RS232
  6 USB-A (5V/1.5A, Service)
  7 Audio Out
  8 DC In
  9 Zoom Ring
  10 Power Button
  11 Keypad
  12 Top IR



• Specification	Details
  Projection System	0.65″ 1080P
  Native Resolution	1920×1080
  Brightness	5000 (ANSI Lumens)
  Brightness (Center Lumens)	5500
  Contrast Ratio	3000000:1
  Display Color	1.07 Billion Colors
  Light Source Type	Laser Phosphor
  Light Source Life (Normal Mode)	20,000 hours
  Light Source Life (SuperEco Mode)	30,000 hours (Eco)
  Lens	F=2.43-2.78, f=16.90-21.61mm
  Projection Offset	132%+/-10%
  Throw Ratio	1.13-1.47
  Optical Zoom	1.3X
  Digital Zoom	0.8x-2.0x
  Image Size	30″-300″
  Throw Distance	0.75-9.76m (100″@2.50m)
  Keystone	H:+/-30° , V:+/-30°
  Audible Noise (Normal)	30dB
  Audible Noise (Eco)	24dB
  Input Lag	49.5ms
  Resolution Support	VGA(640 x 480) to WUXGA RB(1920 x 1200) *RB-Reduced Blanking
  HDTV Compatibility	480i, 480p, 576i, 576p, 720p, 1080i, 1080p
  Horizontal Frequency	15K-102KHz
  Vertical Scan Rate	24-120Hz
  Input	HDMI: 2 (HDMI 1.4/ HDCP 1.4)
  Output	Audio-out (3.5mm): 1
  Speaker	15W
  USB Type A (Power)	1 (5V/1.5A)
  Control	RS232 (DB 9-pin male): 1
  USB Type A (Services)	1 (share with USB A Output)
  Power Supply Voltage	Input: 100~240V
  Power Consumption	Normal: 210W
  Standby	<0.5W
  Operating Temperature	0~40℃
  Carton	Brown
  Net Weight	3.00kg
  Gross Weight	4.70kg
  Dimensions (WxDxH)	286x216x129mm
  Packing Dimensions	400x280x155mm
  OSD Language	English, French, Spanish, Thai, Korean, German, Italian, Russian, Swedish, Dutch, Polish, Czech, T-Chinese, S-Chinese, Japanese, Turkish, Portuguese, Finnish, Indonesian, Arabic, Vietnamese, Hungarian, Norsk (total 23 languages)
  User Guide Language	English, S-Chinese, T-Chinese, Indonesian, Finish, French, German, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Swedish, Turkish, Arabic, Czech, Thai, Vietnamese (total 20 languages)
  Standard Accessory	Power Cord: 1, Remote Control: 1, QSG: Yes, Warranty Card: Yes (CN Only)
  Optional Accessory	Wall/Ceiling Mount: PJ-WMK-007, Carry Bag: PJ-CASE-008
