Vestel EL32G Series 32″ Full HD Android Digital Signage Display – (Open Box)
Vestel EL32G-2H / EL + Series
32″ Digital Signage Display
(Open Box)
Free Wall Mounted Included
- Description
- Specifications
- Warranty
- Downloads
-
Vestel EL32G 32″ Commercial Display can be use Portrait or Landscape orientation.
Usb Security
This series lets your USB and your content to be secured within the back cover of the display. The cover is protected with a screw not allowing any outside intervention.External Device Connections
You may want to connect your teleconference system, screen sharing system, set-top box or external PCs via HDMI port. For this purposes, our monitors help you to maximize user experience with HDMI CEC (Consumer Electronics Control) and HDMI Hotplug capabilities.Open Platform Support
Our SoC supports API (Application Programming Interface) for solution providers/integrators to develop and integrate any HTML5-based to be installed and used on our displays.Pixel Shifting
Pixel Shifting is designed to be activated inside the SoC in order to prevent for potential risk of image sticking, caused by constant content. With this feature turned on, pixels on the screen will move in an interval while causing no interference of visual experience.SoC Content Management
With quad core SoC (System on Chip), this Series displays are the digital signage monitors for both offline designed content and cloud-based managed content. This helps your digital content to be displayed in the displays by content management systems.Signal Failover
Our SoC Software has a protection for “No Signal” scenario. If the USB is unplugged after your content is set to be displayed with USB, the display will either show your customized banner or search for any other signal from other sources (HDMI, Display Port, etc.). This failover protection is constructed for higher user experience.Scheduler
Digital Signage Monitor Software allows many important features such as Scheduler. Scheduler sets your display turn on/off time easily and lets you not to worry about the status of your displays in any time.Subtle Design
This series’ displays exhibit ultra narrow bezel design eliminating the visual superfluities, directing audience focus on your advertised content. This series is found to be desirable for digital signage specific design: internal usb cover, detachable power plug, carrying handles and IR extender.Usb Auto-Play
You will be able to show photo and video content automatically with USB Auto-play feature. SoC software gives you a choice to turn on USB auto-play function making it easy for end-users to show any media on the screen and not worry about anything else.Display Control
Digital Signage Display SoC enables the users to control our displays using RS232 commands in a Local Area Network. Together with the full RS232 command list you can change/set volume, turn on/off the monitor, set a schedule for content display, set a webpage link to be displayed and give a wide range of commands in real-time. -
Panel Screen Size 32″ Panel Technology VA Backlight Type DLED Brightness (typical) 450 cd/m² Native Resolution 1920 x 1080 (16:9) – FHD Contrast Ratio (typical) 3000:1 (typ.) Dynamic Contrast Ratio 35000:1 Panel Life Time (Min.) 50000 Hrs Response Time (typical) 9.5 ms Active Area (H x V) 698.40 x 392.8 mm Viewing Angle 178° Vert., 178° Hor. (89U/89D/89L/89R) @ CR>10 Color Value 16.7M Color Gamut 68% NTSC Haze Level 3% Refresh Rate 60 Hz Orientation Landscape / Portrait Operation Hours 24/7 Area of Usage Indoor Built-in System Mainboard Model 17MB450VS Operating System Custom OS (built on Android AOSP) Memory 2 GB DDR4 Storage 16 GB eMMC CPU Quad-Core ARM Cortex-A55 GPU ARM Mali-G31 MP2 Wired 10/100 Mbps Ethernet WiFi WiFi 5 (802.11 a/b/g/n/ac) HTML5 Browser Vewd Monitor Connectivity Video Input 2xHDMI2.0, 1xUSB-A 3.0, 1xUSB-A 2.0 Video Output 1xHDMI2.0 External Control RS232 (3.5mm jack green), Fast Ethernet (RJ45), Service (RJ12) Mechanical Product Dimensions (WxDxH) 734 x 78 x 435 mm Package Dimensions (WxDxH) 795 x 128 x 530 mm Product Weight 4.5 kg Package Weight 6 kg Vesa Mounting 75 x 75 mm M4 Bezel Width B:21, T/ L/R:14 mm Environmental Conditions Operating Temperature 0-40°C Operating Humidity 10-90% Power Power Supply 170 VAC – 240 VAC – 50/60 Hz Power Consumption Typical: 32 W Maximum: 65 W Deep Standby: ≤0.5 W Features Main Features HTML5 CMS Launcher, Android CMS Launcher, Open Content Management Support, Scheduler, USB-Autoplay, Auto-Launch, HDMI-CEC, HDMI-Wakeup, Auto-switch on Failover, Panel Lock, OSD and UI Rotation, Video Rotation, NoSignalPowerOff, Pixel shift, Scheduler, Videowall support, Remote control via LAN, Real Time Clock, SNMP Mechanical Features Joystick, Fixed IR lens, Rocker Switch, Detachable Power Cable Speaker 2×6 W Accessory Standard QSG, IB, Power cord, Remote control unit, RC battery, Mounting kit, IR extender cable Certification Safety Yes EMC Yes CE Yes -
Warranty Period: 3-year on-site swap out
UK Mainland De-Install/Re-Install Warranty.Vestel Digital Signage Displays offer a large range of large format displays for use in commercial applications from reception, and conference rooms to classrooms backed by a 3 Year On-Site UK Mainland Warranty.
They have displays operating from 16 hours per day to non-stop usage displays ideal for the transport industry.
If you need to discuss your warranty period, please contact us.
-
Document Type Download Link Specification Sheet Downloads Commercial Datasheet Downloads Model Drawing Downloads Wall Mount Drawing Downloads
