• V7 PRO 75″ 4K Android 13 EDLA Certified Education Interactive Touchscreen Display


  V7 Interactive 4K Pro Model Displays allow users to easily collaborate, save and share ideas interactively and digitally in meeting rooms and classrooms. The system uses a powerful Octa-Core processor and graphics chipset with increased memory. The EDLA certification with the included Google Play Store gives users access to a vast library of downloadable apps for including productivity, collaboration, entertainment, education, and gaming. It is optimal for multi-window multitasking applications for leading classrooms or meetings including whiteboard, note taking, web browser, screen sharing and recording, and more. With Bytello Share, you can share and receive content between the Interactive Display and Windows, Mac OS, Chrome OS, Android, and iOS Devices using the included application or using Miracast, ChromeCast or AirPlay (up to 9 devices split screen at one time). Connect to a variety of resources and provide a great interactive multimedia environment with 50 point touch with palm rejection, 2 x 18 watt + 2 x 8 watt front facing speakers and a microphone array, 2 USB-C ports with Power Delivery (1 x 100 watt, 1 x 15 watt) for your devices, and many other ports including USB, Video, and Network to connect with other devices.

  Key Features
  Fast Android 13 system with powerful Octacore CPU, 16 GB ROM and 256 GB RAM optimized for multiwindow multitasking
  Google Play Store included for downloading applications
  4K Interactive Display with 50 point touch and palm rejection
  Multitasking with easy to use built in applications for leading classrooms and meetings interactively with the audience
  Wired and Wireless Networking included with Internet access and screen sharing to and from almost any device
  USB-C PD 100w Device Charging, USB-C 4K video out, and plenty of USB, video, network, and wireless connectivity
  2 x 18W + 2 x 8W Front Facing Speakers, 8 Microphone Array, and Bluetooth wireless Connectivity
  Bytello DMS with 5 year subscription included unified Bulk Remote Management with status monitoring, time & channel, switching, volume control and information broadcasting
  Includes heavy duty wall mount for fast deployment, 2 Anti-Microbial Pens and TUV Rheinland Eye Comfort certification reduces blue light emission for less eye fatigue

  OCTA-CORE CPU
  Made for Multi-tasking

  ANDROID 13
  Improve Security and Performance

  100W USB-C POWER DELIVERY
  Charge & Screen share with one cable.

  USB-C & HDMI OUT
  Easily add a new display to your IFP

  SCREENSHARE WITH EASE
  Share screens to and from almost any device.

  YOU’RE IN CONTROL
  Bulk upload apps, wallpaper and way more.

• Category	Specification
  TECHNICAL
  Aspect Ratio	16:9
  Dynamic Contrast Ratio	4000:1
  Input Port	Audio 35mm, USB, USB-C, VGA, HDMI
  Power Input	AC 100V-240V 50-60Hz
  Pixel Pitch (H/V)	429.75 x 429.75
  Power Consumption	Maximum 530W, Energy Star 137.45W, Standby ≤0.5W
  Speaker	2 x 8W + 2 x 18W
  Operating Humidity	10% – 90%RH
  Operating Temperature	0℃- 40℃
  Package Type	One Color
  Brightness	450 nits
  Viewable Screen Size	75 in
  Panel Type	VA
  Response Time	6.5 ms
  Speaker Output Power	2 x 8W + 2 x 18W
  Contrast Ratio	1200:1
  Storage Humidity	10% – 90%RH
  Storage Temperature	-20℃ – 60℃
  VESA Mount	800 x 400 mm
  Viewing Angle	178°H / 178°V
  Power Delivery	Front 100W PD, Rear 15W PD
  DESIGN
  Color	Black
  GENERAL INFO
  Compliance	CE, Energy Star, FCC, RoHS, UL, TUV, WEEE
  Country Of Origin	China
  EAN	0662919121605
  Model	IFP7503-V7PROM
  Package Includes	Interactive Display, 3 m Power Cord, USB-C cable, HDMI cable, 2 Writing Pens, 1 Remote Control with 2 AAA batteries, Quick Start Guide, Heavy Duty Wall Mount, Wireless Module
  Warranty	5 years
  PACKAGE DIMENSIONS
  Package Dimensions (L/W/H)	73.35 x 8.86 x 45.2 in (1863 x 225 x 1148 mm)
  Package Weight	133.93 lbs (60.75 kg)
  PRODUCT DIMENSIONS
  Product Dimensions (L/W/H)	67.3 x 3.37 x 40.59 in (1709.4 x 85.7 x 1031 mm)
  Product Weight	113.45 lbs (51.46 kg)
  ANDROID SYSTEM
  Android Version	Android 13.0 4K UI
  CPU	A76×4 + A55×4
  GPU	Mali-G610 MP4
  RAM	16 GB
  ROM	256 GB
  SPECIFICATIONS
  Surface Treatment	Haze 5%; Anti-glare treatment
  Light Sensor	Automatic brightness adjustment
  Backlight Unit	D-LED
  Connectors
  HDMI Input	x 4
  HDMI Output	x 1
  DisplayPort Input	x 1
  USB 2.0	x 1 (for Software update only)
  USB 3.0	x 4 (2 front with passthrough in/out, 2 rear)
  USB-C	x 2 (Front 100W PD pass through, Rear 15W PD)
  USB-C Out (DP Alt Mode)	Max resolution 7680 x 4320@60Hz
  Touch out	USB 2.0 x 2
  Audio in/out	3.5mm x 1
  SPDIF	x 1
  WIFI	802.11ac (2T2R) Wi-Fi Module Included with Hotspot
  LAN (RJ45)	10/100/1000Mbps LAN both in & out auto switch
  RS232	DB9 x 1
  OPS Slot	80 Pins
  Bluetooth	5.2
  TOUCH SYSTEM SOFTWARE
  Sensing Type	Infrared Recognition
  OS Compatibility	Windows, Linux, Mac OS, Android, Chrome
  Bonding	0 Gap
  Touch Tool	Finger, Passive infrared pen
  Touch Accuracy	±1mm 90% area
  Touch Point	50 Touch
  Touch Height	≤1mm
  Touch Drive	Free drive
  Simultaneous Writing	Yes, with two different colors
  Response Time	≤2.5ms
  Writing Height	≤1mm
  Glass Type	G1S Anti-Glare
  Glass Thickness	3 mm
  Glass Hardness	9H
  Interpolation Resolution	32767 x 32767
  SOFTWARE OVERVIEW
  Google Play Store	Access to a vast library of apps available, covering a wide range of categories including productivity, entertainment, education, and gaming.
  Interactive Multimedia	Built-in advanced interactive multimedia presenting platform offering note-taking, whiteboard, add shapes, multiple colors, and more.
  Screenshare Pro	Share and receive content from Windows, Mac, Chrome OS, Android, iOS using app or Miracast, ChromeCast, or AirPlay (up to 6 devices split screen at a time)
  Finder & Cloud Drive	For local storage and cloud file management including Google Drive and One Drive
  WPS Office	Create, Display, and Edit Office Files
  Mark	Write on any screen you want for creating notes on web pages, lessons, and more
  Web Browser	Chromium-based secure browser with bookmarks and advanced features
  Screen Recording	Screen Recording for recording and sharing lessons
  Air Class	Allows presenter to create polls, questionnaires, voting, and responses for users with any device that has a web browser
  Crop	Capture and Save a portion of the screen
  Timer	Start a countdown timer
  Spotlight	Highlight a portion of the screen to help the audience focus
  Stopwatch	Start and Stop Time Tracking
  Freeze	Capture the screen, Zoom in & out
  Screenlock	Secure the screen with a Password
  Palette	For painting and drawing
  Keeper	Simple memory and system management with one click
  Software Update OTA	Over the Air and USB
  REMOTE	(Optional) Unified Bulk Remote Management across the network including status monitoring, time and channel switching, volume control and information broadcasting
