• V7 Green Cat6 Shielded (STP) Cable RJ45 Male to RJ45 Male 3m 10ft – V7CAT6STP-03M-GRN-1E

  Featuring more stringent specifications for reducing crosstalk and system noise, V7 CAT6 snagless molded patch cables maximize your Local Area Network (LAN) speed and are perfect for higher bandwidth applications, such as Voice over IP (VoIP) or video applications. V7 CAT6 patch cables provide clean, clear transmissions with lower return loss, resulting in reliable and practical Gigabit-Ethernet performance. The cables feature snagless molded connector boots to provide strain relief and ensure a durable and solid connection. V7 Cat6 cables are available in a wide range of colors and lengths.

  Shielded Twisted Pairs (STP) minimizes noise and interference (EMI/RFI)
  Pure copper conductors for optimal signal transfer and durability
  Soft thread and short connectors for versatile compatibility
  Snagless design with strain relief and locking latch
  Gold-plated contacts provide exceptional conductivity

• CATEGORY	DETAILS
  COLOR	Green
  GENERAL INFO
  Model	V7CAT6STP-03M-GRN-1E
  EAN	662919100228
  Warranty	Lifetime
  Compliance	CE, RoHS, TIA/EIA-568-B.2-1, ISO/IEC 11801, WEEE
  Country Of Origin	Vietnam
  PACKAGE DIMENSIONS
  Package Weight	0.21 kg (0.46 lbs)
  Package Dimensions	7.48 x 9.45 x 0 in (190 x 240 x 0.1 mm)
  PRODUCT DIMENSIONS
  Product Dim	190 x 240 x 0.1 mm (7.48 x 9.45 x 0 in)
  Product Weight	0.13 kg (0.29 lbs)
  TECHNICAL
  Conductor	High Purity Bare Copper
  Conductor Size	26AWG
  Connector 1	RJ45 Male
  Connector 2	RJ45 Male
  Connectors	RJ45
  Cable diameter	6.0mm
  Shielding	Shielded Twisted Pair (STP)
  Frequency	250mhz
  Cable Jacket	PVC
  Standard	Cat6
  Fire Rating	CM
  Cable Length	3m/10ft
  Data Transfer Rate	10/100/1000 Mbps

• V7CAT6STP-03M-GRN-1E : Datasheet
