Universal Secure KVM Switch, 4-Port Dual Head No CAC | F1DN204KVM-UNN4
- Description
- Specifications
-
Universal Secure KVM Switch, 4-Port Dual Head No CAC
It serves as a computer switching device, controlling four computers and equipped with USB keyboard and mouse connections. It supports dual monitors with HDMI and DisplayPort video connections, offering high-quality video playback in 4K Ultra HD resolution. The product features a sturdy and durable design with a black aluminum and metal body. It holds various certifications and operates with an AC power source. With its portable size and weight, it’s easily transportable and storable within wide operating ranges. The package includes AC cables for easy setup.
-
Category Description Ports & Interfaces Number of computers controlled 4 Keyboard port type USB Mouse port type USB Video port type HDMI/DisplayPort HDMI ports quantity 2 HDMI version 2.0 DisplayPorts quantity 2 DisplayPort version 1.2 Console ports 3.5mm headphone, DisplayPort, HDMI, RJ–45, USB A USB connector type USB Type-B Audio connections Cables used to connect audio inputs or audio outputs to another device DC-in jack The socket/plug where the DC electricity supply connects to the device Performance HD type 4K Ultra HD Maximum resolution 3840 x 2160 pixels Video bandwidth 60 Hz Design Rack mounting The type of mounting that can position devices in a shelving system (rack) Product colour Black Housing material Aluminium, Metal Certification FCC Class B UL CE RoHS ICES RCM Power Power source AC Input voltage 100 – 240, 12 V Input current 2.5 A External power adapter Operational conditions Operating temperature (T-T) 0 – 40 °C Storage temperature (T-T) -20 – 60 °C Storage relative humidity (H-H) 0 – 80% Weight & dimensions Width 317.5 mm Depth 162.6 mm Height 91.4 mm Weight 2.2 kg Packaging content Cables included AC Manual AC adapter included Logistics data Harmonized System (HS) code 85176200
