Ubiquiti UniFi Dream Machine Special Edition – UDM-SE-EU
- Description
- Specifications
-
Ubiquiti UniFi Dream Machine Special Edition
Ubiquiti UniFi Dream Machine Special Edition (UDM-SE)
The Ubiquiti UniFi Dream Machine Special Edition (UDM-SE) is an enterprise-grade UniFi OS Console capable of helping home and business owners alike seamlessly scale and manage their networks with high-speed, dual-WAN connectivity (10G SFP+ and 2.5GbE RJ45 ports), a Gigabit, PoE switch, and a network video recorder (NVR) with 128 GB of internal storage.UDM-SE Key Features
Includes full UniFi application suite for device management
3.5+ Gbps routing with IDS/IPS
Integrated 8-port PoE/PoE+ switch
(1) 10G SFP+*, (8) GbE RJ45 LAN ports including (2) PoE+, and (6) PoE
(1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
1.3″ touchscreen
128 GB SSD & 3.5″ NVR HDD bay
Experience unparalleled control over your UniFi devices with the UDM-SE, powered by UniFi OS. Manage access points, Protect cameras, Talk phones, and Access readers effortlessly. Future-proof your network with this console, equipped to seamlessly run all forthcoming UniFi OS applications. Designed for simplicity from start to finish, the UDM SE boasts an integrated Bluetooth radio, simplifying setup and configuration. With the UniFi Network application (available on web or mobile), you can complete the entire process in just minutes.The UDM-SE is a powerhouse, featuring a robust quad-core ARM Cortex-A57 processor clocked at 1.7 GHz, accompanied by 4 GB of DDR4 system memory and 16 GB of eMMC on-board storage. Additionally, it includes an integrated 128 GB SSD for enhanced performance. Connectivity is versatile with eight LAN GbE RJ45 ports, a 2.5 GbE WAN RJ45 port, and 10G SFP+ interfaces for both LAN and WAN connections. PoE capabilities are extensive, supporting a total of six PoE and two PoE+ interfaces. With an IDS/IPS throughput of 3.5 Gbps, security is paramount. Operating temperature ranges from -10 to 40°C ensure reliability in various environments. Furthermore, it features a 1.3″ touchscreen LCM display and robust ESD/EMP protection, making the UDM SE a top choice for network solutions.
-
Technical Specifications Mechanical Dimensions 442.4 x 43.7 x 285.6 mm (17.4 x 1.7 x 11.2″) Weight 5 kg (10.9 lb) Enclosure material Aluminium CNC, SGCC steel Mount material SGCC steel Hardware Processor Quad-core ARM® Cortex®-A57 at 1.7 GHz System memory 4 GB DDR4 On-board storage 16 GB eMMC Integrated 128 GB SSD Management interface Ethernet, Bluetooth Networking interface LAN: (8) GbE RJ45 ports (1) 10G SFP+ port WAN: (1) 2.5 GbE RJ45 port (1) 10G SFP+ port PoE interface (6) PoE (Pair A 1, 2+; 3, 6-) (2) PoE+ (Pair A 1, 2+; 3, 6-) IDS/IPS throughput 3.5 Gbps* (Measured with iPerf3 on a DHCP network) *Performance may be reduced with PPPoE depending on ISP implementation. Power method (1) Universal AC input, 100—240V AC, 4.4A Max., 50/60 Hz (1) USP-RPS DC input, 52V DC, 3.94A Power supply AC/DC, internal, 240W Supported voltage range 100—240V AC Max. power consumption 50W (Excluding PoE output) PoE budget 180W Max. PoE wattage per port by PSE PoE: 15.4W PoE+: 30W Voltage range PoE mode PoE: 44—57V PoE+: 50—57V ESD/EMP protection Air: ± 15kV, contact: ± 8kV LCM display (1) 1.3″ touchscreen Button Factory reset Ambient operating temperature -10 to 40° C (14 to 104° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Gateway Features Performance Redundant WAN with failover and load balancing WiFi QoS with UniFi APs Application, domain, and country-based QoS Application and device type identification Additional internet failover with LTE Backup Internet quality and outage reporting Next-generation security Application-aware firewall rules Signature-based IPS/IDS threat detection Content, country, domain, and ad filtering VLAN/subnet-based traffic segmentation Full stateful firewall Advanced networking License-free SD-WAN WireGuard, L2TP and OpenVPN server OpenVPN client OpenVPN and IPsec site-to-site VPN One-click Teleport and Identity VPN Policy-based WAN and VPN routing DHCP relay Customizable DHCP server IGMP proxy IPv6 ISP support LEDs Ethernet White: link/activity SFP+ White: link/activity HDD White: disk activity, Amber: disk error RPS Blue: ready
