Ubiquiti U7-PRO UniFi Tri-Band WiFi 7 Access Point
- Description
- Specifications
-
Ubiquiti U7-PRO UniFi Tri-Band WiFi 7 Access Point
Ubiquiti UniFi U7 Pro WiFi 7 Access Point
The UniFi U7-Pro is a Ceiling-mount WiFi 7 AP with 6 GHz support, 2.5 GbE uplink, and 9.3 Gbps over-the-air speed.Key Features
WiFi 7 with 6 GHz support
140 m² (1,500 ft²) coverage
300+ connected devices
Powered using PoE+
2.5 GbE uplink
The Ubiquiti UniFi U7 Pro WiFi 7 Access Point is a ceiling-mounted device designed for large-scale, demanding environments. It supports WiFi 7 with a tri-radio system, including 6 GHz for reduced interference.The UniFi U7 Pro offers 6 spatial streams, which handle over 300 connected devices. The U7 Pro features a 2.5 GbE uplink and offers advanced throughput rates and antenna gains across different frequency bands. It’s built with robust hardware and software, ensuring high performance and security standards.
-
Technical Specifications Details Mechanical Dimensions Ø206 x 46 mm (Ø8.1 x 1.8″) Weight 680 g (1.5 lb) Enclosure material Polycarbonate, metal Mount material Stainless steel (SUS304), galvanized steel (SGCC) Hardware Networking interface (1) 1/2.5 GbE RJ45 port Management interface Ethernet Power method PoE+ Power supply UniFi PoE switch Supported voltage range 44—57V DC Max. power consumption 21W Max. TX power 2.4 GHz 22 dBm 5 GHz 26 dBm 6 GHz 23 dBm MIMO 2.4 GHz 2 x 2 5 GHz 2 x 2 6 GHz 2 x 2 Throughput rate 2.4 GHz 688 Mbps 5 GHz 2882 Mbps 6 GHz 5765 Mbps Antenna gain 2.4 GHz 4 dBi 5 GHz 6 dBi 6 GHz 5.8 dBi LEDs White/blue Button Factory reset Mounting Wall/ceiling (Included) Ambient operating temperature -30 to 60° C (-22 to 140° F) Ambient operating humidity 5 to 95% noncondensing Certifications CE, FCC, IC Software WiFi standards 802.11a/b/g/n/ac/ax/be Wireless security WPA-PSK, WPA-Enterprise (WPA/WPA2/WPA3/PPSK) BSSID 8 per radio VLAN 802.1Q Advanced QoS Per-user rate limiting Guest traffic isolation Supported Concurrent clients 300+ Supported Data Rates 802.11a 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11b 1, 2, 5.5, 11 Mbps 802.11g 6, 9, 12, 18, 24, 36, 48, 54 Mbps 802.11n 6.5 Mbps to 300 Mbps (MCS0 – MCS15, HT 20/40) 802.11ac (WiFi 5) 6.5 Mbps to 1.7 Gbps (MCS0 – MCS9 NSS1/2, VHT 20/40/80/160) 802.11ax (WiFi 6/6E) 7.3 Mbps to 2.4 Gbps (MCS0 – MCS11 NSS1/2, HE 20/40/80/160) 802.11be (WiFi 7) 7.3 Mbps to 5.7 Gbps (MCS0 – MCS13 NSS1/2, EHT 20/40/80/160/240/320) Application Requirements UniFi Network Version 8.0.26 and later UniFi OS Version 3.2 and later
