Ubiquiti EdgeRouter Wired Router Gigabit Ethernet Black | ER-12
- Description
- Specifications
-
Ubiquiti EdgeRouter Wired Router Gigabit Ethernet Black
Price/Performance Breakthrough
The EdgeRouter™ 12 offers next-generation price/performance value: up to 3.4 million packets per second processing with a line rate of up to 6.8 Gbps. Ten Copper Gigabit ports and two independent SFP ports allows for deployment flexibility. The EdgeRouter 12 supports Layer-2 switching.Versatile Design
The EdgeRouter 12 can be rack-mounted with the use of the EdgeRouter Rack Mount Kit, model ER-RMKIT (sold separately).Centralized Management
The EdgeRouter 12 is supported and managed by UNMS™ (Ubiquiti® Network Management System), a comprehensive controller with an intuitive UI. A single control plane manages registered EdgeMAX® devices across multiple sites. -
Feature Detail Dimensions 268.1 x 136.5 x 31.1 mm (10.6 x 5.4 x 1.2″) Weight 700 g (1.5 lb) Hardware Processor 4-Core 1 GHz MIPS64 Memory 1 GB DDR3 RAM Storage 4 GB eMMC, 8 MB SPI NOR Networking Gigabit Ethernet Ports 10 SFP Ports 2 (1 Gbps) Management 1 x RJ45 Serial Port Power Power Method External AC/DC Adapter (Included) Power Supply 24V Passive PoE Voltage Range 9-30V DC Max Power Consumption 20W (Excluding PoE output) ESD/EMP Protection Air: ± 24 kV, Contact: ± 24 kV Buttons Factory Reset LEDs System: Power, Data Ports: Speed/Link/Activity, PoE, SFP Data Port: Link/Activity Operating Temperature -10 to 50° C (14 to 122° F) Operating Humidity 10 to 90% noncondensing Certifications CE, FCC, IC
