Ubiquiti Dream Wall Gateways & Controller 1000 Mbit/s | UDW-EU

Ubiquiti Dream Wall Gateways & Controller 1000 Mbit/s | UDW-EU

• Description
• Specifications

• Ubiquiti Dream Wall Gateways & Controller 1000 Mbit/s


  The Ubiquiti UniFi Dream Wall is a wall-mounted UniFi OS Console with a security gateway, high-speed access point, network video recorder, and a PoE switch with a versatile networking interface.

  Ubiquiti UniFi Dream Wall Key Features
  Built-in WiFi 6 AP
  Includes full UniFi application suite for device management
  3.5+ Gbps routing with IDS/IPS
  (1) 10G SFP+*, (17) GbE RJ45 LAN ports including (4) PoE++, (4) PoE+, and (4) PoE ports
  (1) 10G SFP+*, (1) 2.5 GbE RJ45 WAN ports
  4.7″ touchscreen for management

  Integrated 128 GB SSD & pre-installed 512 GB microSD card
  The Dream Wall is wall-mounted UniFi OS Console that serves as a standalone, space-saving deployment hosting solution. Each of these feature-rich, next-gen consoles are equipped with a variety of multi-gigabit WAN/LAN ports to support high-speed connectivity, along with a wealth of GbE RJ45 ports that deliver PoE, PoE+, and PoE++ output.

  More UDW Features
  Dedicated Bluetooth management radio for streamlined configuration
  1.3″ LCM colour touchscreen
  Includes a wall mount, screw kits, and a power cord
  128 GB integrated storage for full UniFi OS Application experience
  Micro SD memory card expansion slot (card needs min 128 GB of storage)
  Supports redundant power resources



• Category	Details
  Design
  Certification	CE, FCC, IC
  Enclosure material	Aluminum
  LED indicators	LAN
  Mounting type	Wall mounting
  Product colour	White
  Features
  Antenna gain level	6 dBi
  Card reader integrated	Yes
  Compatible memory cards	MicroSD (TransFlash)
  Legal Information
  UNSPSC Code	43222605
  Management features
  Quality of Service (QoS) support	Yes
  Reset button	Yes
  Network
  Ethernet LAN data rates	1000 Mbit/s
  Networking standards	IEEE 802.11a/IEEE 802.11ac/IEEE 802.11ax/IEEE 802.11d/IEEE 802.11g/IEEE 802.11n/IEEE 802.1Q
  Wi-Fi	Yes
  WLAN data transfer rates supported	1/11/12/1732/1733/1734/1750/18/2/24/2402/300/36/48/5.5/54/6/9 Mbit/s
  Operational conditions
  Operating relative humidity (H-H)	5 – 95 %
  Operating temperature (T-T)	-10 – 40 °C
  Package dimensions	Gross Weight (Package, kg)
  Packaging content	Quick installation guide
  Performance
  Built-in processor	Yes
  Control display unit	Yes
  Flash memory	16384 MB
  Internal memory	4096 MB
  Internal memory type	DDR4
  Number of processors installed	1
  Processor frequency	1700 MHz
  Processor manufacturer	ARM
  Processor model	Cortex-A57
  SSD capacity	128 GB
  Ports & interfaces	Ethernet LAN (RJ-45) ports
  WAN connection	Ethernet (RJ-45)
  Power
  Input current	7 A
  Input frequency	50/60 Hz
  Input voltage	100 – 240 V
  Power consumption (max)	532 Watt
  Power over Ethernet (PoE)	Yes
  Product dimensions	Net Weight (Product, kg)
  Product Depth	54.9 cm
  Product Height	6.2 cm
  Product Width	34.2 cm
  Protocols	DHCP server
  Security
  Security algorithms	WEP/WPA/WPA-Enterprise/WPA-PSK/WPA2/WPA3
  VLAN support	Yes
  Vendor information	Brand Name
  Warranty	2 Year(s)
  Categories
  Main category	Network
  Subcategory	Firewalls & Gateways
  Subcategory	Gateways/Controllers
