• TP-Link TL-SL2428P JetStream 24-Port 10/100Mbps + 4-Port Gigabit Smart Switch with 24-Port PoE+

  Realize More Possibilities with Omada
  JetStream 24-Port 10/100Mbps + 4-Port Gigabit Smart PoE+ Switch
  TL-SL2428P


  Centralized Cloud Management
  Omada SDN Platform Integration

  Advanced L2+ Features
  L2/L3/L4 QoS, ACL, Static Routing and More

  Abundant Security Strategies
  LAN Area Investment Protection

  PoE+ Output
  24 PoE+ Ports with Total 250 W Power Budget

  Dedicated 24 PoE+ Ports (250 W Budget) for Numerous Applications
  Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 250 W PoE power budget* for the 24× 10/100Mbps PoE+ ports makes it has a wide range of applications, such as surveillance, offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, etc.


  Software Defined Networking (SDN) with Cloud Access
  Omada’s Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network—all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.

• Hardware Features
  Standards and Protocols	IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3z, IEEE 802.3ad, IEEE 802.3x, IEEE 802.3az, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1x, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at
  Interface	24 10/100Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX), 2 10/100/1000Mbps RJ45 Ports (Auto Negotiation/Auto MDI/MDIX), 2 Combo Gigabit Uplink RJ45/SFP Ports
  Network Media	10BASE-T: UTP category 3, 4, 5 cable (maximum 100m); 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m); 1000BASE-X: MMF, SMF
  Fan Quantity	2
  Physical Security Lock	Yes
  PoE Budget	250 W
  Dimensions (W x D x H)	17.3 x 7.1 x 1.7 in. (440 x 180 x 44 mm)
  Mounting	Rack Mountable
  Max Power Consumption	18.8 W (220 V / 50 Hz with no PD connected); 286.7 W (220 V / 50 Hz with 250 W PD connected)
  Max Heat Dissipation	64.1 BTU/h (with no PD connected); 977.6 BTU/h (220 V / 50 Hz with 250 W PD connected)

  Performance
  Switching Capacity	12.8 Gbps
  Packet Forwarding Rate	9.5 Mpps
  MAC Address Table	8K
  Jumbo Frame	9216 Bytes

  Software Features
  Quality of Service	802.1p CoS/ DSCP priority; 8 priority queues; Priority Schedule Mode – SP (Strict Priority), WRR (Weighted Round Robin); Queue Weight Config; Bandwidth Control – Port/Flow based Rating Limit; Smoother Performance; Actions for flows – Mirror(to supported interface), Redirect(to supported interface), Rate Limit, QoS Remark; Storm Control – Multiple Control Modes(kbps/ratio/pps), Broadcast/Multicast/Unknown-Unicast Control
  L3 Features	16 IPv4/IPv6 Interfaces; Static Routing – 48 static routes; Static ARP – 128 static entries; 316 ARP Entries; Proxy ARP; Gratuitous ARP; DHCP Server; DHCP Relay – DHCP interface relay, DHCP VLAN relay; DHCP L2 Relay
  L2 Features	Link Aggregation – Static link aggregation, Up to 8 aggregation groups and up to 8 ports per group, 802.3ad LACP; Spanning Tree Protocol – 802.1D STP, 802.1w RSTP, 802.1s MSTP, STP Security: Loop back detection, TC Protect, BPDU Filter/Protect, Root Protect; Loopback Detection – Port based, VLAN based; Flow Control – 802.3x Flow Control, HOL Blocking Prevention; Mirroring – Port Mirroring, One-to-One, Many-to-One, Tx/Rx/Both, CPU Mirroring
  L2 Multicast	Supports 511 (IPv4, IPv6) IGMP groups; IGMP Snooping – IGMP v1/v2/v3 Snooping, Fast Leave, IGMP Snooping Querier, IGMP Authentication; MVR; MLD Snooping – MLD v1/v2 Snooping, Fast Leave, MLD Snooping Querier, Static Group Config, Limited IP Multicast; Multicast Filtering: 256 profiles and 16 entries per profile
  Advanced Features	Automatic Device Discovery; Batch Configuration; Batch Firmware Upgrading; Intelligent Network Monitoring; Abnormal Event Warnings; Unified Configuration; Reboot Schedule

• TL-SL2428P : Datasheet
