• TP-Link EAP610/AX1800 Ceiling Mount WiFi 6 Access Point


  Easily Upgrade to Business WiFi 6 Network
  AX1800 Ceiling Mount WiFi 6 Access Point

  Upgrade to WiFi 6, Power up Your Business

  Seamless Integration into Omada SDN Platform
  The Omada Software Defined Networking (SDN) platform integrates network devices including access points, switches, and routers to provide 100% centralized cloud management and create a highly scalable network—all controlled from a single interface.

  Easy Deployment & Higher Performance by Omada Mesh**
  Easy Pairing, Less Wiring
  With Mesh technology, Omada EAPs save you from extra wires by wirelessly extending your WiFi signal further and more flexibly to hard-to-wire areas.

  Optimized Network Performance
  Intelligent self-organization optimizes the best path between EAPs while self-healing ensures you stay online even when one AP is disrupted.

  Always Stay Smooth with Fast Roaming
  Ensures customers to enjoy uninterrupted streaming when moving around by switching clients automatically to the access points with the optimal signal.

  Easy to Mount with Refined Industrial Design

  Boosted Network Security and Efficiency


• HARDWARE FEATURES
  Interface	1× Gigabit Ethernet (RJ-45) Port
  Button	Reset
  Power Supply	– 802.3at PoE<br> – 12 V / 1 A DC
  Power Consumption	– EU: 12.8 W (For PoE); 10.8 W (for DC)<br> – US: 13.9W (For PoE); 11.8 W (for DC)
  Dimensions (W x D x H)	9.6 × 9.6 × 2.5 in (243 × 243 × 64 mm)
  Antenna Type	Internal Omni
  	– 2.4 GHz: 2× 4 dBi
  	– 5 GHz: 2× 5 dBi
  Mounting	Ceiling/Wall Mounting (Kits included)

  WIRELESS FEATURES
  Wireless Standards	IEEE 802.11ax/ac/n/g/b/a
  Frequency	2.4 GHz and 5 GHz
  Signal Rate	– 5 GHz: Up to 1201 Mbps
  	– 2.4 GHz: Up to 574 Mbps
  Wireless Functions	– 1024-QAM<br> – 4× Longer OFDM Symbol<br> – OFDMA<br> – Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
  	– Enable/Disable Wireless Radio<br> – Automatic Channel Assignment<br> – Transmit Power Control (Adjust Transmit Power on dBm)
  	– QoS(WMM)<br> – MU-MIMO<br> – Seamless Roaming §<br> – Omada Mesh§<br> – Band Steering<br> – Load Balance
  	– Airtime Fairness<br> – Beamforming<br> – Rate Limit<br> – Reboot Schedule<br> – Wireless Schedule
  	– Wireless Statistics based on SSID/AP/Client
  Wireless Security	– Captive Portal Authentication§<br> – Access Control<br> – Wireless Mac Address Filtering<br> – Wireless Isolation Between Clients
  	– SSID to VLAN Mapping<br> – Rogue AP Detection<br> – 802.1X Support<br> – WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise
  Transmission Power	– CE: <20 dBm(2.4 GHz, EIRP)<br> – FCC: <25 dBm (2.4 GHz)<br> – FCC: <25 dBm (5 GHz)

  MANAGEMENT
  Omada App	Yes
  Centralized Management	– Omada Hardware Controller (OC300)<br> – Omada Hardware Controller (OC200)
  	– Omada Software Controller
  Cloud Access	Yes (Through OC300, OC200, or Omada Software Controller)
  Email Alerts	Yes
  LED ON/OFF Control	Yes
  Management MAC Access Control	Yes
  SNMP	v1, v2c, v3
  System Logging	Local/Remote Syslog
  SSH	Yes
  Web-based Management	HTTP/HTTPS
  L3 Management	Yes
  Multi-site Management	Yes
  Management VLAN	Yes
  Zero-Touch Provisioning	Yes. Requiring the use of Omada Cloud-Based Controller (Supported by EAP610 V1, V2, V2.2 and above, while is not supported by EAP610 V3)

  OTHERS
  Certification	CE, FCC, RoHS
  Package Contents	– EAP610<br> – Power Adapter<br> – Ceiling/Wall Mounting Kits<br> – Installation Guide
  System Requirements	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
  Environment	– Operating Temperature: 0–40 ℃ (32–104 ℉)<br> – Storage Temperature: -40–70 ℃ (-40–158 ℉)
  	– Operating Humidity: 10–90% RH non-condensing<br> – Storage Humidity: 5–90% RH non-condensing
