Toshiba MG Series 3.5″ 22 TB Serial ATA Internal Hard Drive – MG10AFA22TE
- Description
- Specifications
- Downloads
-
Toshiba MG Series 3.5″ 22 TB Serial ATA Internal Hard Drive
Robust design
The helium sealed-drive design not only enhances the durability of the Toshiba MG10F Series but also ensures a quieter operation with a sound emission of just 20 dBA, making it an excellent choice for noise-sensitive environments.High capacity storage
With a massive 22 TB capacity and a data transfer rate of 6 Gbit/s, this hard drive meets the demands of extensive storage requirements, ensuring your data is always accessible when you need it.Reliable performance
Equipped with a 512 MB buffer size and a spindle speed of 7200 rpm, the MG10AFA22TE model delivers efficient and reliable performance for both heavy-duty workloads up to 550 TB per year and Online Transaction Processing (OLTP).Energy efficient
The drive’s power consumption is optimized for efficiency, with an active idle mode consuming only 4.5 W and an active typical mode at 8.38 W, reducing operational costs.Enhanced durability
Designed to withstand the rigors of continuous operation, this hard drive boasts a MTBF of 2,500,000 hours, along with advanced shock and vibration tolerance, ensuring long-term reliability. -
General Device Type Hard drive – internal Capacity 22 TB Form Factor 3.5″ Buffer Size 512 MB Features OLTP, advanced format 512e, CMR, Helium Sealed-Drive Design, workload up to 550 TB per year Width 10.185 cm Depth 14.7 mm Height 2.61 mm Weight 720 g Performance Drive Transfer Rate 6 Gbit/s (external) Internal Data Rate 271 MBps Spindle Speed 7200 rpm Reliability MTBF 2,500,000 hours 24×7 Operation Yes Non-Recoverable Errors 10 per 10^16 Load / Unload Cycles 600,000 Expansion & Connectivity Interfaces 1 x SATA 6 Gb/s Compatible Bay 3.5″ Power Power Consumption 4.5 Watt (active idle), 8.38 Watt (active (typical)) Environmental Parameters Min Operating Temperature 5 °C Max Operating Temperature 55 °C Min Storage Temperature -40 °C Max Storage Temperature 70 °C Humidity Range Operating 5 – 90% RH (non-condensing) Shock Tolerance (operating) 5 g @ 2 ms Shock Tolerance (non-operating) 200 g @ 2 ms Vibration Tolerance (operating) 0.75 g @ 5-300 Hz Vibration Tolerance (non-operating) 3 g @ 5-500 Hz Sound Emission 20 dBA - Toshiba MG Series 3.5″ 22 TB Serial ATA Internal Hard Drive DataSheet Downloads
