  High-speed scalable storage server
  Synology RS3618xs is a reliable, superior-performance network-attached storage solution for large-scale enterprises with demanding business applications. It simplifies data management, optimizes virtualization environments, and rapidly expands storage capacity with minimal time investment in setup and maintenance.

  Ready for 10GbE and beyond
  PCIe 3.0 slots allow for faster networking options as you expand your infrastructure. Together with the built-in quad Gigabit ports, RS3618xs offers comprehensive connectivity options for link aggregation and failover configurations.


  Ultimate Backup Solution
  RS3618xs integrates various backup applications to safeguard your important data on any device with an intuitive user interface and durable storage technologies.

  Active Backup for Server
  An agentless backup solution protects data from Windows and Linux servers through SMB and Rsync to minimize deployment and management costs.

  Hyper Backup
  Comprehensively back up your data to a local shared folder, an external device, another Synology NAS, an rsync server, or a public cloud to ensure data safety.

  Desktop Backup
  Safeguard your PC with Cloud Station Backup. Effortlessly back up data stored on macOS to Synology NAS with Time Machine.

  Active Backup for Office 365/ G Suite
  On-premise backup solution with a centralized dashboard. Optimize storage efficiency with single instancing and block-level deduplication technology.

  Fully certified storage virtualization solutions
  Synology iSCSI storage fully supports most virtualization solutions to enhance work efficiency with easy management interface. VMware vSphere 6 and VAAI integration helps offload storage operations and optimizes computation efficiency. Windows Offloaded Data Transfer (ODX) speeds up data transfer and migration rate. OpenStack Cinder support turns your Synology NAS into a block-based storage component.


  Next-generation file system for better data protection
  The Btrfs file system introduces advanced storage technologies and optimized snapshots to prevent data corruption and reduce maintenance overhead. While ensuring high-level data integrity, it also offers flexible, efficient data protection and recovery tools.

• Category	Specification
  Battery
  Battery Type	UN3091 – Lithium METAL inside equipment
  Lithium Weight (g)	0.064 g
  Certificates
  Certification	EAC, VCCI, CCC, RCM, FCC, CE, BSMI
  RoHS Compliance	Yes
  Design
  Chassis Type	Rack (2U)
  Cooling Type	Active
  Fan Diameter	8 cm
  LED Indicators	HDD/Power
  Number of Fans	4 fan(s)
  Product Colour	Black
  Legal Information
  EU ECCN Code	N/A
  UNSPSC Code (Icecat)	43201835
  US ECCN Code	5A992
  Logistics Data
  Harmonized System (HS) Code	84714100
  Memory
  Internal Memory	8 GB
  Internal Memory Type	DDR4
  Maximum RAM Supported	64 GB
  Memory Clock Speed	2133 MHz
  Memory Slots	4
  Network
  Ethernet LAN	Yes
  Ethernet LAN Data Rates	10/100/1000 Mbit/s
  iSCSI Support	Yes
  Link Aggregation	Yes
  Supported Network Protocols	CIFS, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN)
  Wake-on-LAN Ready	Yes
  Wi-Fi	No
  Operational Conditions
  Operating Altitude	0 – 5000 m
  Operating Humidity	5 – 95 %
  Operating Temperature	5 – 35 °C
  Storage Temperature	-20 – 60 °C
  Other Features
  Certification	EAC, VCCI, CCC, RCM, FCC, CE, BSMI
  Compliance Certificates	RoHS
  Processor ARK ID	91202
  Package Dimensions
  Depth (Package)	86 cm
  Gross Weight (Package)	18.84 kg
  Height (Package)	23 cm
  Width (Package)	62 cm
  Packaging Content
  Cables Included	AC
  Quick Installation Guide	Yes
  Performance
  Access Control List (ACL)	Yes
  Backup Features	Cloud/iSCSI LUN
  Backup Function	Yes
  Browser Supported	Chrome, Firefox, Internet Explorer 10, Safari
  Device Class	Small & Medium Business
  Hot Spare	Yes
  Multilingual Support	Yes
  Noise Level	50.2 dB
  Number of Users	16,000 user(s)
  On/Off Switch	Yes
  Reset Button	Yes
  S.M.A.R.T. Support	Yes
  Security Algorithms	HTTPS/SSH/SSL/TLS
  Share Folder	CIFS/AFP/FTP
  System Log	Yes
  Type	NAS
  Web-Based Management	Yes
  Ports & Interfaces
  Ethernet LAN (RJ-45) Ports	4
  Fiber Ports Quantity	0
  PCI Express x8 (Gen 3.x) Slots	2
  USB 2.0 Ports Quantity	0
  USB 3.2 Gen 1 Type-A Ports	2
  USB Port	Yes
  Power
  AC Input Frequency	50 – 60 Hz
  AC Input Voltage	100 – 240 V
  Number of Power Supply Units	1
  Power Consumption (HDD Standby)	55.05 Watt
  Power Consumption (Typical)	142.76 Watt
  Power Supply Location	Built-in
  PSU Capacity	500 Watt
  Processor
  Conflict-Free Processor	Yes
  CPU Configuration (Max)	1
  ECC Supported by Processor	Yes
  Maximum Internal Memory Supported	128 GB
  PCI Express Configurations	1×16/1×4/1×8
  PCI Express Slots Version	2.0/3.0
  Processor ARK ID	91202
  Processor Boost Frequency	2.7 GHz
  Processor Cache	6 MB
  Processor Code	SR2DF
  Processor Codename	Broadwell
  Processor Cores	4
  Processor Family	Intel® Xeon® D
  Processor Frequency	2.4 GHz
  Processor Lithography	14 nm
  Processor Manufacturer	Intel
  Processor Model	D-1521
  Processor Operating Modes	64-bit
  Processor Package Size	37.5 x 37.5 mm
  Processor Series	Intel Xeon D-1500
  Processor Socket	BGA 1667
  Processor Threads	8
  Scalability	1S
  Stepping	V2
  Thermal Design Power (TDP)	45 Watt
  Processor Special Features
  Embedded Options Available	No
  Enhanced Intel SpeedStep Technology	Yes
  Execute Disable Bit	Yes
  Idle States	Yes
  Intel 64	Yes
  Intel Enhanced Halt State	Yes
  Intel Secure Key Technology Version	1.00
  Intel Trusted Execution Technology	Yes
  Intel TSX-NI	Yes
  Intel TSX-NI Version	1.00
  Intel Virtualization Technology (VT-x)	Yes
  Intel Virtualization Technology for Directed I/O (VT-d)	Yes
  Intel VT-x with Extended Page Tables (EPT)	Yes
  Intel® AES New Instructions (Intel® AES-NI)	Yes
  Intel® Hyper Threading Technology (Intel® HT Technology)	Yes
  Intel® OS Guard	Yes
  Intel® Secure Key	Yes
  Intel® Turbo Boost Technology	2.0
  Maximum Number of PCI Express Lanes	32
  Memory Channels Supported by Processor	Dual
  Memory Types Supported by Processor	DDR3-SDRAM/DDR4-SDRAM
  Thermal Monitoring Technologies	Yes
  UART	Yes
  Product Dimensions
  Net Weight (Product)	14.5 kg
  Depth	69.2 cm
  Height	8.8 cm
  Width	43.05 cm
  Software
  Mac Compatibility	Yes
  Mac Operating Systems Supported	Mac OS X 10.11 El Capitan/Mac OS X 10.12 Sierra
  Operating System Installed	DiskStation Manager
  Server Operating Systems Supported	Windows Server 2012/Windows Server 2012 R2
  Windows Operating Systems Supported	Windows 10/Windows 7
  Storage
  Hot-Swap Drive Bays	Yes
  Installed Storage Drive Type	No
  Maximum Supported Storage Capacity	144 TB
  Number of Drives Installed	0
  Number of Drives Supported	12
  RAID Levels	0/1/10/5/6/F1/JBOD
  RAID Support	Yes
  Storage Drive Capacity	0 GB
  Storage Drive Sizes Supported	2.5/3.5 “
  Storage Drives Installed	No
  Supported File Systems	BTRFS/ext3/ext4/FAT/HFS+/NTFS
  Supported Storage Drive Interfaces	Serial ATA/Serial ATA II/Serial ATA III
  Supported Storage Drive Types	HDD & SSD
  Total Installed Storage Capacity	0 TB
  Technical Details
  Harmonized System (HS) Code	84714100
  Sustainability Certificates	RoHS
  Vendor Information
  Brand Name	Synology
  Warranty
  Duration	3 Year(s)
