• Synology FlashStation NAS/Storage Server – Economical, High-Performance Data Management Solution For SMBs | FS3410

  Harness all-flash storage to speed up business workflows
  With 24 all-flash bays in a 2U rackmount enclosure, the Synology FlashStation FS3410 is the ideal solution for SMBs, enterprise offices, and data centers requiring high sustained I/O performance for applications such as video post-production, virtual machines (VMs), enterprise email servers, and online transaction processing.

  Storage
  Supports 24 x 2.5” SATA SSDs

  Throughput
  Over 356,500/129,400 iSCSI 4K random read/write IOPS1

  Memory
  16 GB DDR4 ECC RDIMM, up to 128 GB

  Expandability
  Optional 25/40GbE through PCIe 3.0 expansion

  Powerful flash storage server
  Combine all-flash performance with Synology systems’ ease of use and reliability. The FS3410 is designed to tackle scenarios that require high throughput and low latency.

  Built for high reliability
  The FS3410 is built to keep mission-critical data and services always accessible, enabling businesses to continue to perform even when disaster strikes.

  Out-of-band (OOB) management
  Simplify troubleshooting by managing powered-down devices remotely and accessing critical logs through a dedicated interface.

  Dual power supply
  Redundant PSU units reduce the possibility of power disruptions on a single distribution channel or PDU adversely impacting data and service availability.

  Failover cluster
  Pair two FS3410 units with Synology High Availability to enable automatic minute-level failover in the event of server failure or to minimize downtime when performing system updates or upgrades.

  Powerful networking options
  The FS3410 supports a wide range of networking interfaces, protocols, and configurations, whether you need fast sequential transfer, support for simultaneous connections, or high network redundancy.

  Built-in fast connectivity
  Two 10GbE RJ-45 ports and four Gigabit Ethernet ports allow for rapid transfer speeds right out of the box.

  Support for 10/25/40GbE
  Add up to 2 x 10/25/40GbE network interface cards using the 2 x PCIe 3.0 slots to enable lightning fast networking in minutes.

  Failover and network balancing
  Bond multiple network interfaces with Link Aggregation to enable automatic network failover and load balancing.

  Versatile data storage
  The FS3410 fits perfectly in file server, block storage, or light application server roles that require high availability, reliability, and leading-edge storage technology.

• Category	Specification
  Battery
  Battery Type	UN3091 – Lithium METAL inside equipment
  Lithium Weight (g)	0.064 g
  Design
  Chassis type	Rack (2U)
  Cooling type	Active
  LED indicators	Status
  Number of fans	4 fan(s)
  Product colour	Black
  Legal Information
  UNSPSC Code (Icecat)	43201835
  Memory
  ECC	Yes
  Internal memory	16 GB
  Internal memory type	DDR4
  Maximum RAM supported	128 GB
  Memory form factor	RDIMM
  Network
  Ethernet LAN	Yes
  Ethernet LAN data rate supported (max)	10,000 Mbit/s
  Ethernet LAN data rates	10/100/1000/10,000 Mbit/s
  iSCSI support	Yes
  Supported network protocols	SMB, AFP, NFS, FTP, WebDAV, CalDAV, iSCSI, Telnet, SSH, SNMP, VPN (PPTP, OpenVPN, L2TP)
  Wake-on-LAN ready	Yes
  Operational Conditions
  Operating relative humidity (H-H)	8 – 80 %
  Operating temperature (T-T)	0 – 35 °C
  Storage relative humidity (H-H)	5 – 95 %
  Storage temperature (T-T)	-20 – 60 °C
  Other features
  Compliance certificates	CE/RoHS
  Package dimensions
  Gross Weight (Package, kg)	15 kg
  Packaging content
  Cables included	AC
  Power cables quantity	2
  Quick start guide	Yes
  Performance
  Access Control List (ACL)	Yes
  Backup features	Cloud/USB drive
  Backup function	Yes
  Browser supported	Google Chrome, Firefox, Microsoft Edge, Safari 13
  Device class	Large Enterprise Business
  Multilingual support	Yes
  Number of users	16,000 user(s)
  Security algorithms	AES
  Share folder	Yes
  Snapshot	Yes
  System log	Yes
  Type	Storage server
  Ports & Interfaces
  Ethernet LAN (RJ-45) ports	7
  PCI Express x8 (Gen 3.x) slots	2
  Serial ports quantity	1
  USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	2
  USB port	Yes
  Power
  AC input frequency	50 – 60 Hz
  AC input voltage	100 – 240 V
  Processor
  Conflict-Free processor	Yes
  CPU configuration (max)	1
  Processor boost frequency	2.7 GHz
  Processor cache	12 MB
  Processor cores	8
  Processor family	Intel® Xeon® D
  Processor frequency	2.1 GHz
  Processor manufacturer	Intel
  Processor model	D-1541
  Processor threads	16
  Processor special features	Enhanced Intel SpeedStep Technology, Execute Disable Bit, Intel VT-x, Intel VT-d, Intel TSX-NI
  Product dimensions
  Net Weight (Product, kg)	14.9 kg
  Product Depth	69.2 cm
  Product Height	8.8 cm
  Product Width	43.05 cm
  Software
  Operating system installed	DSM
  Operating system version	7.1
  Storage
  Hot-swap drive bays	Yes
  Installed storage drive type	No
  Number of storage drives installed	0
  Number of storage drives supported	24
  RAID levels	0/1/10/5/6/F1/JBOD
  RAID support	Yes
  Storage drive sizes supported	2.5 “
  Supported file systems	BTRFS/exFAT/ext3/ext4/FAT32/HFS+/NTFS
  Supported storage drive interfaces	Serial ATA III
  Supported storage drive types	SSD
  Total installed storage capacity	0 TB
  Total installed system drives capacity	1000 TB
  Sustainability
  Sustainability compliance	Yes
  Sustainability certificates	CE/RoHS
  Vendor information
  Brand Name	Synology
  Warranty	5 Year(s)
