StarTech ST10GSPEXNB2 Network Card Internal 10000 Mbit/s

StarTech ST10GSPEXNB2 Network Card Internal 10000 Mbit/s

• Description
• Specifications
• Downloads

• StarTech ST10GSPEXNB2 Network Card Internal 10000 Mbit/s


  NETWORK ADAPTER FOR PC
  This 10 GbE capable PCIe network adapter card provides high-speed data transfer rates for desktops/servers leveraging an existing Cat5e, Cat6, or Cat6a cabling infrastructure

  SPECIFICATIONS
  Multiple Speeds NIC 10/5/2.5/1Gbps and 100/10Mbps – 10GBASE-T and NBASE-T – 1x RJ45 Port – PCIe 3.0 x2 – Marvell AQC113CS – 16K Jumbo Frame – VLAN – PXE Boot – EEE – Full-Height and Low-Profile Brackets Included

  COMPATIBILITY
  The network card for PC is compatible with Windows, Windows Server, and Linux – The variable speed options and included low profile bracket widen the compatibility of the PCIe network card with current and legacy devices

  MULTI-GIGABIT CONNECTIVITY
  The network interface card auto negotiates speed and supports 2.5/5 Gbps network speeds on Cat5e cabling, and 10 Gbps on Cat6/6a – The Ethernet network card supports IP/TCP/UDP checksum offload, secure boot, PTP, and AVB

  THE IT PRO’S CHOICE
  Designed and built for IT Professionals, this 10Gb network card is backed for two years, including free lifetime 24/5 multi-lingual technical assistance

  Six-Speed | AVB | PXE Boot | x2 PCIe 3.0 | Marvell AQC113CSInstall this single-port 10GbE PCI Express (PCIe) Network Interface Card (NIC) into a server or computer to enable faster network speeds and enhanced network functionality. This card supports six speeds: 10/5/2.5/1Gbps and 100/10Mbps. The variable speeds permit access to legacy hardware. Alternatively, the 10GBASE-T and NBASE-T capabilities ensure compatibility with the latest network switches and network access points manufactured by Cisco®; HPE®; and Juniper®.Increased Network SpeedsThis PCIe network card provides access to increased bandwidth. It reduces network slowdown/degradation when running data-intensive applications/processes such as FTPs, online storage/backup, and when streaming online content.NBASE-T technology maximizes the capability of Cat5e copper cabling over at distances of up to 100 meters. The Ethernet network card supports a 10 Gbps connection over copper using existing Cat6 (or better) copper cabling.Enhance Existing HardwareThe Network Interface Card connects via an available PCI Express x2 3.0/4.0 (or higher) expansion slot. The card is shipped with a standard-profile bracket and includes a low-profile bracket for installation in various systems. This card is compatible with Windows, Windows Server, and Linux.Take advantage of advanced features such as Audio-Video Bridging (AVB), VLAN tagging, 16 K jumbo frame, full-duplex, secure boot, and PXE.The PCI Express 10G NIC is backed for 2-years, including free lifetime 24/5 multi-lingual technical assistance.The StarTech.com Advantage

• Feature	Details
  Brand	Startech
  SKU	10371905
  Manu Part #	ST10GSPEXNB2
  EAN	065030897549
  Network Adapter for PC	This PCIe network adapter card offers high-speed data transfer rates for desktops/servers, utilizing existing Cat5e, Cat6, or Cat6a cabling infrastructure.
  Specifications	– Multiple Speeds NIC: 10/5/2.5/1Gbps and 100/10Mbps – 10GBASE-T and NBASE-T – 1x RJ45 Port – PCIe 3.0 x2 – Marvell AQC113CS – 16K Jumbo Frame – VLAN – PXE Boot – EEE – Full-Height and Low-Profile Brackets Included
  Compatibility	Compatible with Windows, Windows Server, and Linux. Variable speed options and included low-profile bracket enhance compatibility with current and legacy devices.
  Multi-Gigabit Connectivity	Auto negotiates speed, supporting 2.5/5 Gbps on Cat5e cabling and 10 Gbps on Cat6/6a. Supports IP/TCP/UDP checksum offload, secure boot, PTP, and AVB.
  Design	Component for PC, internal, LED indicators, black color
  Weight & Dimensions	– Depth: 121 mm – Height: 22 mm – Width: 107 mm – Weight: 70 g
  Packaging Data	– Package Depth: 145 mm – Package Width: 210 mm – Package Height: 35 mm – Package Weight: 120 g
  Network	– Ethernet LAN data rates: 10/100/1000/2500/5000/10000 Mbit/s – Jumbo frames support: Yes – Full duplex: Yes – Ethernet interface type: 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 10 Gigabit Ethernet, Fast Ethernet, Gigabit Ethernet – Jumbo frames: 16000 – Ethernet LAN: Yes – Maximum data transfer rate: 10000 Mbit/s – Auto MDIX IEEE: Yes – Networking standards: IEEE 1588, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.3an, IEEE 802.3az, IEEE 802.3bz, IEEE 802.3i, IEEE 802.3uCabling technology: 10GBase-T
  Ports & Interfaces	– Ethernet LAN (RJ-45) ports: 1 – Interface: Ethernet – PCI version: 3 – PCI Card form factor: Full-height (low-profile) – Connectivity technology: Wired – Host interface: PCIe
  System Requirements	– Linux operating systems supported: Yes – Windows operating systems supported: Windows 10, Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 IOT Core, Windows 10 IoT Enterprise, Windows 10 Pro, Windows 10 Pro x64, Windows 10 x64, Windows 11, Windows 11 x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64
  Logistics Data	– Master (outer) case width: 445 mm – Master (outer) case length: 375 mm – Products per master (outer) case: 40 pc(s) – Master (outer) case height: 320 mm
  Operational Conditions	– Operating temperature (T-T): 0 – 60 °C – Storage temperature (T-T): -10 – 70 °C
  Packaging Content	– Mounting brackets included: Yes – Quick installation guide: Yes

• Description	Downloads
  StarTech ST10GSPEXNB2 Network Card DataSheet	Downloads
  StarTech ST10GSPEXNB2 Network Card Quick Start Guide	Downloads
  StarTech ST10GSPEXNB2 Network Card Instruction Manual	Downloads
