StarTech N6PATC150CMBL 1.5m CAT6 Ethernet Cable – Blue CAT 6 Gigabit Ethernet Wire

• Description
• Specifications
• Downloads

• StarTech N6PATC150CMBL 1.5m CAT6 Ethernet Cable – Blue CAT 6 Gigabit Ethernet Wire

  This CAT6 cable meets all Category 6 cable specifications, to deliver a reliable Gigabit network connection.

  Protect Your Equipment 

  This CAT6 patch cable is built using 100% copper wire and are tested to comply with ANSI/TIA 568 C.2 Category 6 requirements. We don’t use copper-clad aluminum (CCA) wire, which is subject to problems like weak power delivery, heat buildup, equipment damage and possibly fire.  

  The 50-micron gold connectors deliver optimum conductivity and eliminate signal loss due to oxidation or corrosion. 

  High-Quality Construction 

  The CAT6 cable is manufactured using high-quality copper conductors and carefully constructed and tested to keep Near-End Crosstalk (NEXT) well within acceptable limits. The patch cable is constructed with 24 AWG copper wire, to ensure peak performance for demanding Ethernet applications such as Power-over-Ethernet and 4K or 1080p video streaming. 

  Easily Install Your Network Cables  

  For trouble-free cable runs, this durable cable feature snagless connectors that protect the RJ45 clips during installation, making them less likely to snag or break.  

  The CAT6 Ethernet cable also features molded boots which offer strain relief by stopping the RJ45 connectors from bending at sharp angles. This reduces the risk of cable damage, which could decrease network connectivity and performance.  

  N6PATC150CMBL is backed by a StarTech.com lifetime warranty for guaranteed reliability. 

• Warranty Information
  Warranty	Lifetime
  Connector(s)
  Connector A	1 – RJ-45
  Connector B	1 – RJ-45
  Hardware
  Number of Conductors	4 pair UTP
  Connector Plating	Gold
  Cable Jacket Material	PVC – Polyvinyl Chloride
  Fire Rating	CMG Rated (General Purpose)
  Cable Type	Snagless
  Wiring Standard	TIA/EIA-568-B.1-2001 T568B
  Packaging Information
  Package Height	2 cm [0.8 in]
  Package Length	20 cm [7.9 in]
  Shipping (Package) Weight	80 g [2.8 oz]
  Package Width	22 cm [8.7 in]
  Package Quantity	1
  Performance
  Cable Rating	CAT6 – 650 MHz
  Physical Characteristics
  Product Height	0.8 cm [0.3 in]
  Product Length	150.0 cm [59.1 in]
  Weight of Product	70 g [2.5 oz]
  Product Width	1.2 cm [0.5 in]
  Color	Blue
  Wire Gauge	24 AWG
  Conductor Type	Stranded Copper
  Cable Length	1.5 m [4.9 ft]
  What’s in the Box
  Included in Package	1 – CAT6 Cable
