StarTech MST14DP123DP 3-Port DisplayPort 1.4 Splitter, DisplayPort to 3x DP Multi-Monitor Adapter, Triple 4K Computer MST Hub, USB Bus-Powered – Windows Only

• Description
• Specifications
• Downloads

• StarTech MST14DP123DP 3-Port DisplayPort 1.4 Splitter, DisplayPort to 3x DP Multi-Monitor Adapter, Triple 4K Computer MST Hub, USB Bus-Powered – Windows Only

  This 3-port DisplayPort MST hub lets you create a high-performance workstation by connecting three DisplayPort monitors to your DisplayPort device, helping to increase and maximize your productivity. The multi-monitor splitter supports High Dynamic Range (HDR) and provides sharper images with enhanced video.


  Incredible Picture Quality
  Supporting four times the resolution of 4K, this DP 1.4 MST hub delivers the stunning quality of UHD at resolutions up to 7680×4320 at 30Hz on a single monitor and supports multi-monitor applications at lower resolutions and refresh rates, enabling a dynamic work environment whether you’re in the office, at home or traveling.

  Multi-Tasking Made Easy
  This DisplayPort to 3x DisplayPort MST hub enables you to connect three displays to your DP computer, making multi-tasking much easier. Using this multi-monitor video splitter, you can mirror your display onto multiple monitors, stream independent content to each display or extend your screen to create a video wall effect.

  Hassle-Free Setup
  Multi-stream transport offers an easy setup, by natively working on any Windows device. It offers plug-and-play installation with no drivers or software required. Additionally, the DisplayPort MST hub is bus-powered (with the included micro-USB cable), creating an ultra-portable solution for business and IT professionals.

  MST14DP123DP is backed by a StarTech.com 3-year warranty, and free lifetime technical support.


  Applications
  Stream or extend your desktop onto three additional UHD monitors, TVs or projectors
  Display crisp digital signage with a panoramic video wall
  Create eye-catching visuals for photography and videography
  Stream high-resolution, life-like content on multiple monitors

• Category	Specification
  Warranty Information	3 Years
  Connector(s)	1 – DisplayPort (20 pin)
  	3 – DisplayPort (20 pin) Female
  Environmental	Operating Temperature: -20°C to 60°C (-4°F to 140°F)
  	Storage Temperature: -20°C to 80°C (-4°F to 176°F)
  	Humidity: 5% to 90% RH (no condensation)
  Hardware	Active or Passive Adapter: Active
  	AV Input: DisplayPort – 1.4
  	Ports: 3
  	AV Output: DisplayPort – 1.4
  	Audio: Yes
  	Chipset ID: Synaptics VMM5330
  Packaging Information	Package Height: 2.0 cm [0.8 in]
  	Package Length: 23.0 cm [9.1 in]
  	Shipping (Package) Weight: 80.0 g [2.8 oz]
  	Package Width: 12.5 cm [4.9 in]
  	Package Quantity: 1
  Performance	Audio Specifications: DisplayPort – 7.1 Channel Audio
  	Video Revision: DisplayPort 1.4
  	Maximum Cable Distance To Display: 2 m [6.6 ft]
  	Supported Resolutions: DisplayPort: 7680×4320 (8K) / 30Hz
  	Wide Screen Supported: Yes
  Physical Characteristics	Product Height: 1.4 cm [0.6 in]
  	Product Length: 25.0 cm [9.8 in]
  	Weight of Product: 55.0 g [1.9 oz]
  	Product Width: 4.3 cm [1.7 in]
  	Color: Black
  	Material: Plastic
  Power	Power Source: USB-Powered
  	Input Voltage: 5V DC
  	Output Voltage: 5 DC
  Software	OS Compatibility: Windows 11, 10 (32/64), 8/8.1 (32/64), 7 (32/64)
  What’s in the Box	1 – DisplayPort MST Hub
  	1 – Micro-USB Power Cable
