StarTech HB30C3A1GEA2 3-Port USB-C Hub with Ethernet – 3x USB-A – Gigabit Ethernet – USB 3.0 5Gbps – Bus-Powered – 1ft/30cm Long USB Type-C Host Cable – GbE – Portable USB-C to USB-A Hub

• Description
• Specifications
• Downloads

• StarTech HB30C3A1GEA2 3-Port USB-C Hub with Ethernet – 3x USB-A – Gigabit Ethernet – USB 3.0 5Gbps – Bus-Powered – 1ft/30cm Long USB Type-C Host Cable – GbE – Portable USB-C to USB-A Hub


  3-Port USB-C Hub with Ethernet – 3x USB-A – Gigabit Ethernet – USB 3.0 5Gbps – Bus-Powered – 1ft/30cm Long USB Type-C Host Cable – GbE – Portable USB-C to USB-A Hub
  10/100/1000Mbps Ethernet | USB Type-C to 3x USB Type-A | USB 3.2 Gen 1 (5Gbps) | 1ft (30cm) Built-In Host Cable

  USB HUB WITH ETHERNET: USB 3.2 Gen 1 (5Gbps) expansion hub features a USB-C host connector, 3x USB-A ports, and GbE – Each USB port can provide up to 4.5W dependent on bus power provided by laptop/computer, with overcurrent protection on downstream ports
  GIGABIT ETHERNET: The USB hub features a built-in GbE adapter to provide the reliability and security of wired Ethernet – The Ethernet controller is fully compatible with IEEE 802.3u/ab standards and supports WoL, Jumbo Frames, and V-LAN Tagging
  COMPATIBILITY: Supports all major operating systems, incl. Windows, macOS, Linux, iPadOS, ChromeOS, Android – Compatible w/ Thunderbolt 3/4 & USB4 host devices such as MacBook (Intel/M1/M2), Lenovo X1 Carbon, Dell XPS, Microsoft Surface – Works w/USB 2.0
  EXTRA LONG CABLE: Bus-powered USB Hub with compact housing and extra long attached 1ft. (30cm) host cable for longer reach, and to reduce connector strain when used with laptops risers or 2-in-1 devices (such as Surface Pro 7, iPad Pro, HP Elite X2)
  CONNECTIVITY TOOLS: Optimize the performance and security of this USB-C hub, using the included MAC Address Changer, USB Event Monitoring and Wi-Fi Auto Switch utilities (available for download)

  This USB-C Hub with Gigabit Ethernet adds three USB-A 3.2 Gen 1 (5Gbps) ports and one Gigabit Ethernet port to a USB-C enabled computer. The bus-powered USB Hub connects to a USB-C port on a laptop computer, using the built-in 1 ft. (30 cm) host cable. This USB hub is compact in size, facilitating portability when travelling.

  Gigabit Ethernet
  The USB hub features a Gigabit Ethernet adapter. The Ethernet controller is compatible with the IEEE 802.3u/ab standards and supports Wake-on-LAN (WoL), Jumbo Frames, and V-LAN Tagging. The network adapter enhances laptop network reliability, security, and performance, by utilizing wired 10/100/1000Mbps Ethernet.

  Connect up to Three USB-A Devices
  The 3-port USB 3.2 Gen 1 (5Gbps) Hub adds three USB-A ports by connecting to a single USB-C port. The USB hub is backward compatible with USB 2.0 (480Mbps) devices, ensuring support for a wide range of modern and legacy USB peripherals (e.g., external storage devices, thumb drives, HDDs/SSDs, HD cameras, mice, keyboards, webcams, and audio headsets).

  The USB Hub is bus-powered. It draws up to 15W of power from the USB-C host computer. Each downstream USB-A port is capable of providing up to 4.5W (5V/0.9A) of power to the connected peripherals. For added protection to connected USB devices, the USB ports feature Overcurrent Protection (OCP). OCP prevents USB peripherals from drawing more power than is safely allocated for the port.

  Plug and Play
  This device is compatible with all major operating systems, including Windows, macOS, ChromeOS, iPadOS, and Android. The Hub is automatically detected and configured upon connection to a host computer. This ensures automatic installation and setting configuration with any USB-C laptop, including Thunderbolt 3, Thunderbolt 4 and USB4 computers such as Apple MacBook (Intel/M1/M2), Lenovo X1 Carbon and Dell XPS. The built-in extra long 1 ft. (30 cm) USB-C host cable ensures easy setup and reduces connector strain on 2-in-1 devices such as the Surface Pro 7, iPad Pro, HP Elite X2 and laptops on riser stands.

  Enhance Productivity and Device Management with the StarTech.com Connectivity Tools Application
  Developed to improve performance and security, StarTech.com Connectivity Tools is the only software suite on the market that is compatible with a wide variety of IT connectivity accessories. The software suite includes:

  MAC Address Pass-Through Utility: Improve network security.

  USB Event Monitoring Utility: Track and log connected USB devices.

  Wi-Fi Auto Switch Utility: Enable users to quickly access faster network speeds via wired LAN.

• Specifications
  Warranty Information	2 Years
  Connector(s)
  External Ports	3 – USB Type-A (5 Gbps)
  	1 – RJ-45
  Host Connectors	1 – USB 3.2 Type-C (5 Gbps)
  Environmental
  Operating Temperature	0°C to 45°C (32°F to 113°F)
  Storage Temperature	-10°C to 70°C (14°F to 158°F)
  Humidity	10% – 85% RH
  Hardware
  USB-C Device Port(s)	No
  USB-C Host Connection	Yes
  Fast-Charge Port(s)	No
  Ports	3
  Interface	USB 3.2 Gen 1 (5 Gbps)
  RJ45 (Gigabit Ethernet)
  Bus Type	USB 3.2 Gen 1 (5 Gbps)
  Industry Standards
  IEEE 802.3u, IEEE 802.3ab
  IEEE 802.3az Energy-Efficient Ethernet
  IEEE 802.3x Flow Control
  802.1q VLAN Tagging
  802.1p Layer 2 Priority Encoding
  USB 3.0 – Backward compatible with USB 2.0 and 1.1
  Chipset ID	VIA/VLI – VL817
  	ASIX – AX88179A
  Indicators
  LED Indicators	1 – Network Link LED (Green)
  	1 – Network Activity LED (Amber)
  Packaging Information
  Package Length	14.2 cm (5.6 in)
  Package Width	17.0 cm (6.7 in)
  Package Height	3.0 cm (1.2 in)
  Shipping (Package) Weight	94.0 g (3.3 oz)
  Package Quantity	1
  Performance
  Maximum Data Transfer Rate	5 Gbps (USB 3.2 Gen 1)
  Ethernet (Full-Duplex)	2 Gbps
  Type and Rate	USB 3.2 Gen 1 – 5 Gbit/s
  UASP Support	Yes
  Flow Control	Full duplex flow control
  Compatible Networks	10/100/1000 Mbps
  Auto MDIX	Yes
  Full Duplex Support	Yes
  Jumbo Frame Support	9K max.
  Physical Characteristics
  Color	Space Gray
  Form Factor	Compact
  Product Length	4.0 cm (1.6 in)
  Product Width	8.0 cm (3.1 in)
  Product Height	1.5 cm (0.6 in)
  Weight of Product	42.0 g (1.5 oz)
  Material	Plastic
  Cable Length	30 cm (11.8 in)
  Power
  Power Source	Bus Powered
  Software
  OS Compatibility	Windows 7, 8, 8.1, 10, 11
  	macOS 10.11, 10.12, 10.13, 10.14, 10.15, 11.0, 12.0, 13.0, 14.0 (VLAN tagging not supported in macOS)
  	Linux Kernel 4.11.x (and up) – LTS versions only
  	iPadOS
  	ChromeOS
  	Android
  Special Notes / Requirements
  Note	USB 3.2 Gen 1 (5 Gbps) is also known as USB 3.1 Gen 1 (5 Gbps) and USB 3.0 (5 Gbps)
  	DisplayPort Alternate Mode and USB Power Delivery are not supported
  	Wake-on-LAN (WoL) functionality can be disabled by the host computer if the host computer USB controller enters power save mode. It’s recommended to disable USB power save modes if WoL functionality is required.
  	To protect connected devices from power surges, this device features Over Current Protection (OCP).
  	If a high-powered USB Peripheral (e.g., SSDs/HDDs) is connected and attempts to draw more power than is safely allocated, the device will prevent continuous connection.
  What’s in the Box
  Included in Package	1 – USB Hub
