Startech Dual-Monitor DisplayPort 1.2 Splitter
This MST hub lets you connect two monitors to your DisplayPort™ (DP) 1.2 equipped Windows® laptop or desktop. It’s USB powered, so the only thing you’ll need to operate the hub is your computer.
Increase productivity with multiple screens
The newest generations of computers are more portable than ever, which often means that you’re left with fewer video outputs and smaller integrated screens. This MST hub solves both of these problems by letting you connect two additional displays to your computer, which makes multitasking much easier.
Connect to any display
With the MST hub, you can use DisplayPort video adapters and cable adapters that enable you to connect HDMI, VGA or DVI displays. This ensures your MST hub will be compatible with virtually any television, monitor or projector. The hub is VESA and DisplayPort certified to support DP 1.2 enabled systems, for seamless integration with your existing video equipment.
Configure your displays for any environment
Using the MST hub, you can extend your desktop onto additional monitors and stream independent content to each display, giving you the freedom to multitask and increase your productivity. You can also mirror the same image onto multiple displays for remote viewing applications such as digital signage.
Enjoy amazing video quality, without draining system resources
MST technology uses your existing video card to minimize the use of system resources while delivering Ultra HD 4K resolutions. This unprecedented performance makes MST perfect for high-resolution applications such as graphic design, gaming and medical imaging
Applications
Use one screen for reference data such as websites, while composing in another screen
Dock your DP 1.2 device and add two high-resolution displays to your workstation
Create a panoramic video wall for DisplayPort digital signage applications
Edit images, video or audio clips across two additional displays in any orientation or resolution
Perfect for spanning a spreadsheet or worksheet across two additional displays, to avoid side-scrolling -
Category Details Warranty 3 Years Connector A 1 – DisplayPort (20 pin) Connector B 2 – DisplayPort (20 pin) Operating Temperature 0°C to 40°C (32°F to 104°F) Storage Temperature -20°C to 60°C (-4°F to 140°F) Humidity 50-90% Active or Passive Adapter Active AV Input DisplayPort – 1.2 Ports 2 AV Output DisplayPort – 1.2 Audio Yes Chipset ID MegaChips – STDP4320 Package Height 3.0 cm [1.2 in] Package Length 17.0 cm [6.7 in] Shipping Weight 164.0 g [5.8 oz] Package Width 14.6 cm [5.7 in] Package Quantity 1 Audio Specifications DisplayPort – 5.1 Channel Audio Max Cable Distance 2 m [6.6 ft] Max Digital Resolutions 3840 x 2160 @30hz Supported Resolutions 1024×768, 1280×720, 1920×1080, 1920×1200, 2560×1440, 2560×1600, 3840×2160 @30hz Wide Screen Supported Yes Weight of Product 52.0 g [1.8 oz] Color Black Material Plastic Cable Length 19 cm [7.5 in] Product Length 25.0 cm [9.8 in] Product Width 5.8 cm [2.3 in] Product Height 1.4 cm [0.5 in] Power Source USB-Powered OS Compatibility Windows 11, Windows 10 (32/64), Windows 8/8.1 (32/64), Windows 7(32/64) Special Notes DisplayPort 1.2 with MST+HBR2 support from the GPU is required for independent display output Included in Package 1 – 2-port DP MST Hub, 1 – Quick install guide -
Description Downloads Startech Dual-Monitor DisplayPort 1.2 Splitter | MSTDP122DP DataSheet Downloads Startech Dual-Monitor DisplayPort 1.2 Splitter | MSTDP122DP Quick-Start Guide Downloads
