• StarTech 4-Port Multi-Gigabit PoE++ Injector, 5/2.5/1G Ethernet (NBASE-T), PoE/PoE+/PoE++ (802.3af/802.3at/802.3bt), | AS445C-POE-INJECTOR

  This 4-Port Multi-Gigabit PoE++ Injector Hub serves as Power Sourcing Equipment (PSE) and enables multigigabit speeds of 5Gbps, 2.5Gbps, 1Gbps, 100Mbps, and 10Mbps across four Ethernet ports. This mid/end-span injector is capable of transmitting network data and power up to 328ft (100m) for remote installations. The PoE, PoE+, PoE++ compatibility and selectable power output ensure seamless compatibility with Powered Devices (PD). The TAA-compliant injector includes a Universal Power Adapter for different regions (NA/JP, EU, UK, and ANZ).


  Versatile PoE Injector

  Multiport PoE Injector supports the IEEE 802.3af, 802.3at, and 802.3bt (Type 3 and Type 4) standards for Power Sourcing Equipment (PSE), delivering up to 52V DC and 95Watts. This flexibility eliminates the need for a separate power source for remote networked devices such as IP cameras, access control devices, remote kiosks (POSs), wireless access points, PoE lighting, and digital signage.

  Experience streamlined cable management with all network cables routed from one side of the unit for a clean and organized setup.

  Flexible Power Options

  Tailor the power output to the specific needs of the device using the Power Output Switch. The options include 90W, 95W PoH, or legacy 60W (for UPoE/UPoE+) for all the ports on the PoE Injector Adapter.

  The Level-4 ESD protection (15kV air and 8kV contact) enhances device safety and reduces EMI for stable operation, minimizing the risk of downtime and hardware failures.


  Increased Network Speeds

  The unmanaged PoE Injector with NBASE-T technology provides access to an increased bandwidth up to 5Gbps, significantly reducing network slowdowns during data-intensive applications such as streaming high-definition video feeds, high-speed Internet, access local network resources, online or local network backups, and FTP access.

• Category	Details
  Warranty Information	Warranty: 2 Years
  Connector(s)	Connector A: 4 – RJ-45 (PoE++) Connector B: 4 – RJ-45 External Ports: 1 – M Barrel Power Connector
  Environmental	Operating Temperature: 32°F to 122°F (0°C to 50°C) Storage Temperature: 14°F to 158°F (-10°C to 70°C) Humidity: 5~95% RH (Non-Condensing)
  Hardware	Ports: 4 Industry Standards: Power over HDBaseT / PoH (95 W), IEEE 802.3bt Type 4 / 4PPoE / PoE++ (90 W), IEEE 802.3at Type 2 / PoE+ (30 W), IEEE 802.3af Type 1 / PoE (15.4 W), IEEE 802.3bz (5GBASE-T and 2.5GBASE-T), IEEE 802.3ab (1000BASE-T), IEEE 802.3u (100BASE-TX), IEEE 802.3i (10BASE-T), IEC 61000-4-2 Level-4 ESD protection (8kV contact/15kV air) Chipset ID: Microsemi – PD69208T4, PD69200R
  Indicators	LED Indicators: 3 – PoE Usage LEDs: – Steady Amber: Over power budget – Blinking Amber: Under power budget 3 – PoE-in-Use LEDs: – Steady Green: 802.3bt/PoH/Force power – Steady Amber: 802.3af/at PoE/PoE+ power – Off: No power 1 – Power LED: – Steady Green: Power supplied – Off: No power
  Packaging Information	Package Quantity: 1 Package Height: 9.0 cm [3.5 in] Package Length: 30.0 cm [11.8 in] Package Width: 17.0 cm [6.7 in] Shipping Weight: 1.7 kg [3.7 lb]
  Performance	Maximum Data Transfer Rate: 5000 Mbps Maximum Cable Length: 100 m [328.0 ft] ESD Protection: +/-8kV (Contact), +/-15kV (Air) Compatible Networks: 5G/2.5G/1G/100Mbps/10Mbps Auto MDIX: Yes PXE: No Jumbo Frame Support: 9K max.
  Physical Characteristics	Color: Black Product Height: 3.9 cm [1.5 in] Product Length: 9.4 cm [3.7 in] Weight: 278.0 g [9.8 oz] Product Width: 7.0 cm [2.8 in] Material: Steel
  Power	Power Source: AC Adapter Included Input Voltage: 100 – 240 AC Input Current: 2.5 A Output Voltage: 54 DC Output Current: 3.3 A Center Tip Polarity: Positive Plug Type: M
  Software	OS Compatibility: No drivers or software required
  Special Notes / Requirements	Recommended to attach a grounding wire to Earth Ground for stability. Force Mode: Non-negotiating 4-pair 60W PoE. Ensure PD supports 60W to avoid damage. 802.3bt and ‘PoH + Legacy’ switch position pass power classes 0-8, ‘Force’ switch position passes power class 0-3.
  What’s in the Box	Included: 4-Port PoE Injector, Universal Power Adapter, DIN Rail Mounting Kit, Quick-Start Guide
