StarTech 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio | SV431DVIUAHR

• Description
• Specifications
• Downloads

• StarTech 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio | SV431DVIUAHR

  The SV431DVIUAHR 4 Port High Resolution USB DVI Dual Link KVM Switch with Audio provides simple, yet comprehensive KVM control of up to 4 directly connected computers with dual link DVI output and USB keyboard and mouse connections.

  Audio switching capability and support for high resolution dual link DVI applications up to 2560×1600 @ 60Hz (up to 3840×2400 at lower refresh rates), make this KVM a superior switching solution that integrates perfectly into multimedia environments.

  The DVI USB KVM Switch is compatible with all USB supported operating systems with no software or drivers to install, and features a built-in USB 2.0 hub that allows you to share up to 3 high speed USB devices between computers.

  Applications
  Ideal for switching between desktops, workstations and servers requiring Ultra
  High resolution displays

  Sharing computers and USB devices in the home/SOHO/multimedia environment

  Switching USB peripherals between connected PC’s

  Designed for large and high resolution displays such as Multimedia Display, Apple

  Cinema Displays, Stock trading setups, and Medical Displays

• Category	Details
  Warranty Information	Warranty: 3 Years
  Connector(s)	Console Interface(s):
  	2 – USB 2.0 Type-A (4 pin, 480Mbps)
  	1 – DVI-I (29 pin)
  	2 – 3.5 mm Mini-Jack (3 Position)
  	Host Connectors:
  	4 – DVI-I (29 pin)
  	4 – USB B (4 pin)
  	8 – 3.5 mm Mini-Jack (3 Position)
  	Other Interface(s):
  	2 – USB 2.0 Type-A (4 pin, 480Mbps)
  Environmental	Operating Temperature: 0°C to 40°C (32°F to 104°F)
  	Storage Temperature: -20°C to 60°C (-4°F to 140°F)
  	Humidity: 0~80% RH
  Hardware	Audio: Yes
  	KVM Ports: 4
  	PC Interface: USB
  	PC Video Type: DVI
  	Number of Monitors Supported: 1
  	Rack-Mountable: Optional
  	Cables Included: No
  	Daisy-Chain: No
  Packaging Information	Package Quantity: 1
  	Package Length: 41.2 cm [16.2 in]
  	Package Width: 21.2 cm [8.3 in]
  	Package Height: 8.8 cm [3.5 in]
  	Shipping (Package) Weight: 1.7 kg [3.6 lb]
  Performance	On-Screen Display: No
  	DVI Support: Yes – Dual Link
  	IP Control: No
  	Hot-Key Selection: No
  	Maximum Digital Resolutions: 2560×1600 @ 60Hz
  	Wide Screen Supported: Yes
  	Maximum Number of Users: 1
  	Port Selection Support: Push Button
  	MTBF: 64,000 hours
  General Specifications	Note: Only supports digital video signals; no analog VGA support
  Physical Characteristics	Color: Black
  	Material: Steel
  	Product Width: 22.0 cm [8.7 in]
  	Product Height: 4.4 cm [1.7 in]
  	Product Depth: 130 mm [5.1 in]
  	Weight of Product: 1.8 kg [3.9 lb]
  Power	Power Source: AC Adapter Included
  	Input Voltage: 100 – 240 AC
  	Input Current: 0.4A
  	Output Voltage: 5 DC
  	Output Current: 2A
  	Center Tip Polarity: Positive
  	Plug Type: N
  	Power Consumption (In Watts): 10
  Software	OS Compatibility: OS independent; No software or drivers required
  Special Notes / Requirements	Note: Higher resolutions available at lower refresh rates, e.g., 3840×2400 @30Hz
  What’s in the Box	Included in Package:
  	1 – 4 Port Dual Link DVI KVM
  	1 – Rubber Foot Pad
  	1 – Power Adapter
  	1 – User Manual

• Description	Downloads
  Datasheet	Downloads
  User Manual	Downloads
