StarTech 15″ – 24″ Dual Monitor Arm Wall Mount | ARMDUALWALL

• Description
• Specifications
• Downloads

• StarTech 15″ – 24″ Dual Monitor Arm Wall Mount

  This dual-monitor wall mount frees up space and creates a professional looking multi-monitor setup. Your two monitors move together to stay aligned. Simply extend the arm to place your monitors in the ideal position, or tuck them close to the wall when not in use. Plus, you can tilt, swivel and rotate your screens for optimal viewing.

  Wall-mount two monitors, in perfect unison
  The dual-monitor wall mount makes it easy to set-up two monitors in a business, commercial or office environment such as a health care or financial center. Both monitors are mounted on a single arm, so they move together in perfect unison, staying aligned at all times.

  Using the mounting arm, you can extend your monitors up to 23″ (585 mm) from the wall, so you can place your monitors for comfortable viewing. The arm also folds back in, so your monitors can be tucked just 6.5″ (165 mm) from the wall when not in use, for a professional low-profile look.


  Adjust your screens for optimal viewing
  Change the position and angle of your screens for ideal viewing. You can swivel your monitors up to 180°, and rotate up to 360° for landscape or portrait viewing. You can also tilt your monitors -15° to +15° to reduce glare and ensure a comfortable viewing position.

  Heavy-duty steel construction
  Made of steel, the dual-monitor wall mount securely supports two monitors, with a weight capacity of 11 lb. (5 kg) per monitor. It provides a stable setup for monitors up to 24″.

  The ARMDUALWALL is backed by a StarTech.com 5-year warranty and free lifetime technical support.

• Category	Details
  Warranty Information
  Warranty	5 Years
  Hardware
  # of Displays Supported	2
  Orientation	Horizontal
  Articulating	Yes
  Mounting Options	Wall-Mount
  VESA Hole Pattern(s)	75×75 mm, 100×100 mm
  Packaging Information
  Shipping (Package) Weight	9.6 lb [4.4 kg]
  Package Quantity	1
  Package Length	28.5 in [72.3 cm]
  Package Width	7.3 in [18.6 cm]
  Package Height	4.9 in [12.4 cm]
  Performance
  Weight Capacity (Per Display)	11.0 lb [5 kg]
  Minimum Display Size	15″
  Maximum Display Size	24″
  Maximum Arm Extension	23.0 in [585 mm]
  Display Tilt	+ 15° / – 15°
  Swivel / Pivot	180°
  Display Rotation	360°
  Physical Characteristics
  Product Length	26.8 in [68.0 cm]
  Product Width	3.0 in [7.5 cm]
  Product Height	7.6 in [19.3 cm]
  Weight of Product	7.1 lb [3.2 kg]
  What’s in the Box
  Included in Package
  	1 – wall plate
  	1 – mounting arms
  	1 – VESA monitor mounts
  	1 – crossbar
  	1 – crossbar cap
  	1 – M4x12 mm screws
  	1 – M4x30 mm screws
  	1 – spacers
  	2 – hex key
  	2 – cable-management clips
  	2 – mounting-arm retainer
  	2 – wall-plate retainer
  	2 – M8x16 mm screws
  	3 – mounting-arm washers
  	3 – mounting-arm caps
  	4 – level
  	4 – M8x60 mm screws
  	4 – concrete anchors
  	8 – washers
  	8 – plastic covers
  	8 – crossbar retainer
  	1 – instruction manual
