Sony SRG-XB25B Compact 4K60P IP BOX-style Remote Camera With 25x Optical Zoom

• Description
• Specifications

• Sony SRG-XB25B Compact 4K60P IP BOX-style Remote Camera With 25x Optical Zoom

  Stream crisp, detail-packed 4K 60p video with this high quality remote camera that features a powerful 25x optical zoom lens for frame-filling close-ups in larger venues.
  The SRG-XB25 high-zoom BOX camera draws on decades of Sony’s professional imaging know-how to suit a wide range of content creation applications. It’s ideal for capturing and streaming impressive 4K pictures in environments including seminar rooms, lecture theatres, virtual production studios, government/parliament buildings and houses of worship.

  The cost-effective SRG-XB25 is particularly appealing for multi-camera shooting set-ups, where high quality images are required without the need for a team of dedicated camera operators. The integrated lens with powerful 25x optical zoom captures frame-filling close-ups of speakers and presenters, even when the camera’s installed at the back or larger auditoriums and public venues.

  The SRG-XB25 fits seamlessly into all-IP production environments, with a single Ethernet cable carrying power, streaming video and camera control signals.

  Ideal for lecture capture applications, the SRG-XB25 partners seamlessly with the REA-C1000 Edge Analytics Appliance. For example, the camera’s powerful 25x zoom captures the speaker’s gestures and handwriting in large classrooms or teaching spaces, allowing REA-C1000 to deliver what the customer requires.

  Robust, stylish and compact
  Measuring just 80.1 × 70.9 × 177.2 mm and weighing 0.87 kg, the SRG-XB25 can be readily integrated into any environment. Upper and lower tripod mounts increase installation flexibility. Rear panel guards assure extra robustness, and the large, easy-to-read tally lamp is useful in multiple camera set-ups.

  High quality 4K 60p images
  The camera’s 1/2.5-type Exmor R CMOS sensor captures smooth, crisply detailed 4K 60p video with excellent low-light sensitivity.　

  Powerful 25x optical zoom
  The integrated autofocus lens with 25x optical zoom plus additional digital zoom assures ultra-clear, powerful close-ups of presenters or audience members.

  Broadcast-style tally light
  The camera-mounted tally light gives visual confirmation to the lecturer or presenter when the camera is active. The horizontal bar-style light is easily visible to both performer/presenter and director.


  Easy IP connectivity, single-cable installation
  Camera control, PoE and streaming video output are carried over a single Ethernet cable, reducing installation costs and simplifying integration in space-restricted or hard-to-reach locations. Full IP integration includes support for Real Time Streaming Protocol (RTSP), Real Time Messaging Protocol (RTMP) and Secure Reliable Transport (SRT). Support for NDI ®|HX is also available via an optional licence.

  Audio input
  Connect an external microphone or line-level source to capture clear pictures plus sound in lecture theatres and meeting rooms or on reality TV shows.

• Category	Specification
  Image Sensor	1/2.5 CMOS
  Effective Pixels	Approx. 8.40 Megapixels
  Signal System	3840×2160/59.94p, 3840×2160/29.97p, 1920×1080/59.94p, 1920×1080/59.94i, 1920×1080/29.97p, 1280×720/59.94p, 1280×720/29.97p, 640×360/59.94p, 640×360/29.97p, 3840×2160/50p, 3840×2160/25p, 1920×1080/50p, 1920×1080/50i, 1920×1080/25p, 1280×720/50p, 1280×720/25p, 640×360/50p, 640×360/25p, 640×480/59.94p *1 (HDMI output only)
  Minimum Illumination (50IRE)	0.8 lux (4K output, 50 IRE, 1/30s)
  Shutter Speed	1/10000s to 1/1s
  Optical Zoom	25x (4K)
  Digital Zoom	up to 3x pixel zoom, 2x digital zoom
  Horizontal Viewing Angle	Approx. 68°
  Focal Length	f = 4.8 mm to 120 mm, F1.6 to F3.4; f = 28 mm to 694 mm (35 mm camera equivalent)
  Minimum Object Distance	1500 mm (WIDE/TELE)
  Number of Preset	256 (CGI/VISCA)
  Camera Features	Day/Night, Image Flip, Tally Lamp
  IP Compression Format	ITU-T H.264/H.265
  Bitrate Compression Mode	CBR/VBR (selectable)
  **NDI®	HX Capability**
  Audio Channel	1 ch
  Audio Codec	AAC LC 256 kbps/ST (IP), AAC LC 128 kbps/ST (IP)
  Interface
  Video Output	HDMI
  HDMI Color Space	YUV, 4:2:2 8-bit; YUV, 4:2:0 8-bit; RGB, 4:4:4 8-bit
  Audio Output	Mini jack ø3.5
  Camera Control Interface	VISCA, VISCA over IP, CGI
  Audio Input	Mini jack ø3.5 (Plug-in-Power supported)
  Power Terminal	IEC60130-10 (JEITA standard RC-5320A) TYPE 4
  General
  Power Requirements	DC 12 V (AC adapter 100 V to 240 V, 50/60 Hz), PoE (IEEE802.3af compatible)
  Power Consumption	DC 12 V:11.0 W; PoE input:12.9 W
  Operating Temperature	0 °C to 40 °C (32 °F to 104 °F)
  Storage Temperature	–20 °C to +60 °C (–4 °F to +140 °F)
  Dimensions (W x H x D)	80.1 × 70.9 × 177.2 mm (3 1/4 × 2 7/8 × 7 inches) (excluding protrusions)
  Mass	Approx. 0.87 kg (1 lb 15 oz)
  Body Color	Black and White
  Size of Screw Hole for Tripod	4.5 mm to 6 mm (3/16 in. to 1/4 in.)
  Mountable Angle	Less than ±45 degrees to the horizontal
  Ceiling Mount	Yes
  Supplied Accessories	Safety Regulations (1), AC adapter (1), Wire rope (1), Mounting screws (M3×8) (1), Mounting screws (M2.6×6 black) (1), HDMI cable fixing plate (1)
