Sharp PN-LA652/60005930 65” 4K UHD Smart InGlass™ Touch Display
The Sharp PN-LA652 / 60005930 InGlass M5 interactive touch display bringing advanced professional functionality to Enterprise users. Sharp/NEC LA series safeguards the highest IT security standards whilst supporting maximum choice and flexibility. An Intel™ SDM slot expands the display’s customisable capability allowing safe and seamless integration into corporate IT systems, or benefit from pre-installed functionality including Sharp Meeting Launcher for quick access to your favourite apps and VC platforms, FlatFrog Board collaborative whiteboarding software, and AirServer™ for wireless screen sharing.
Featuring InGlass™ M5 premium touch technology, users benefit from the most natural writing experience and advanced interactive functionality. The high brightness output, high haze panel and premium glass coating delivers best readability in well-lit meeting rooms, without distraction from reflections, glare or fingerprints.
The LA series supports orientation any which way, including face up, allowing table-top, tilted desk or multi-board side-by-side installations for up to three displays. Users can connect their own notebook, safely and securely via a USB-C connection, providing best versatility in hybrid meetings and spontaneous collaborative interactions.
The LA series integrates elegantly and seamlessly into high-end meeting rooms and boardrooms providing trusted long-life performance whilst making minimal energy demands.
Highlights of the Sharp PN-LA652 65” 4K Smart InGlass™ Touch Display
Most natural writing experience – InGlass™ M5 premium touch system supports patented pressure sensitivity using passive pens as well as Windows Ink and palm rejection.
Secure by design – the non-Android platform with additional security features meets the highest IT security standards.
Optional Windows based Intel SDM slot-in PC – driving unlimited versatility with powerful integrated computing. Includes Sharp’s Meeting Launcher for quick and easy access to your apps offering a secure and locked environment.
Increase your productivity – benefit from a free one-year license for FlatFrog Board for Rooms. FlatFrog Board whiteboard software makes hybrid work easy and productive for everyone.
Energy efficiency – built-in functionality including an ambient light sensor, human presence detection and eco modes help to reduce power consumption. -
Category Details Product Name Sharp PN-LA652 Product Group LCD 65″ InGlass™Touch Display Order Code 60005930 Display Panel Technology IPS with Direct LED backlights Screen Size 65″ / 163.9 cm Aspect Ratio 16:9 Brightness 450 cd/m² (LCD panel without glass); 400 cd/m² (product) Contrast Ratio 1200:1 Viewing Angle 178° horizontal / 178° vertical (typ.) Colour Depth 1.073 billion (10bit) Colour Gamut 68% of DCI Response Time 8 ms (typ.) Panel Refresh Rate 60 Hz Supported Orientation Face Up 1; Landscape; Portrait Touch Touch Technology InGlass™ M5 Number of Touches Up to 20 Response Time ≤ 15 ms Touch Method Finger; Gloves; Stylus (≥ 2 mm) Supported OS Native Multi-Touch: Windows 7, 8, 10, Linux, Android Data Interface USB-HID Accuracy < 1 mm Windows Ink Yes Palm Rejection Yes Glass Type Premium toughened glass, anti-glare coating Thickness 3 mm Haze Level 4 ~ 8% Hardness ≥ 8 H Resolution Native Resolution 3840 x 2160 Supported Resolutions Various Synchronisation Rate Horizontal Frequency 15 – 135 kHz Vertical Frequency 23 – 76 Hz Connectivity Input Video 1 x DisplayPort, 1 x USB-C, 2 x HDMI Input Audio 1 x DisplayPort, 2 x HDMI Input Control LAN 100Mbit, RS232 Input Data 1 x USB 2.0 (Powered), 1 x USB 2.0 Type-B, 2 x USB 2.0 Output Video 1 x DisplayPort (loop through), SDM slot-in PC Output Audio 1 x 3.5 mm jack Output Control 1 x LAN 100Mbit Open Modular Intelligence Supported Modules Intel® Smart Display Modules Large and Small up to 66 W Sensors Ambient Light Integrated, programmable actions Temperature Integrated, 3 sensors, programmable actions Presence Integrated, 60° H angle, 3.6 m distance Electrical Power Consumption 190 W (shipping) Power Savings Mode < 0.5 W; < 2 W (Networked Standby) Power Supply 100-240 V AC, 50/60 Hz, internal Environmental Conditions Operating Temperature +0 to +35°C Operating Humidity 20 to 80% Storage Temperature -20 to 60°C Storage Humidity 10 to 80% Mechanical Dimensions (W x H x D) 1,493.5 x 896.1 x 90.7 mm Weight 49 kg Bezel Width 32.3 mm (bottom); 4.8 mm (left, right and top) VESA Mounting 600 x 400 (FDMI); M8 Ingress Protection IP6x (front); IP2x (back) Packaging Dimensions 1,660 x 1,010 x 220 mm Packaging Weight 59 kg Material Metal Pre-installed Applications Included Software FlatFrog Board for Rooms (1 year) – free download Green Features Energy Efficiency LED backlight Ecological Standards EnergyStar 8.0 Additional Features Special Characteristics DICOM Simulation; HDMI ARC; Powered USB Port Safety and Ergonomics Certifications CE, EMC Class B, Energy Star 8, FCC Class B, RoHS, UL Audio Integrated Audio Integrated Audio Amplifier (for optional speakers) Shipping Content Various accessories included Warranty Warranty 3 years incl. backlight; optional extension available Operating Hours Operating Hours 24/7 External Control Remote Control Crestron V2, HDMI CEC, HTTP Browser, SNMP Remote Management Automated Email Alerts, NEC NaViSet Administrator 2 Security Security Features Disable HW Buttons, Disable IR Functionality, IEEE802.1X Resistance to Fire Fire Resistance Metal backcover, plastic material certified UL94-5VB -
