Sapphire Projector Lift for Small Ceiling Voids | SAPPL04

• Description
• Specifications

• Sapphire Projector Lift for Small Ceiling Voids | SAPPL04


  The Sapphire SAPPL04 projector lift is our entry level lift with a drop of up to one metre when fully extended. You can use the motor stops to adjust this and make it stop short if you do not require the full drop.

  It comes with
  A full cable management system.
  A 595 x 595 decor panel to fit to the ceiling.
  Threaded rods for the bottom decor panel
  Bolts to fit most projectors and secure to the grid.
  Very small projectors can be fitted inside the mechanism to fit very small spaces.
  Ships with a plug and RFRpack which gives you an up and down switch, Radio remote control, RS232 and contact closure.
  Comes with a three year warranty.

  Product Dimensions





• Feature	Details
  Model SKU	SAPPL04
  Max Drop from Ceiling	1000 mm
  Max Height in Ceiling	190 mm
  Projector Inside Lift	300(W) x 340(L) x 130(H) mm
  Projector Under Lift Mesh	500(W) x 500(L) x 200(H) mm
  Maximum Weight	25 kg
