• Planet 16-Port 10/100/1000T 802.3at PoE + 2-Port 100/1000X SFP Managed Switch | GS-4210-16P2S

  Cost-optimized Managed PoE+ Switch with Advanced L2/L4 Switching and Security
  PLANET GS-4210-16P2S is an ideal Gigabit PoE Switch which provides cost-effective advantage to local area network and is widely accepted in the SMB office network. It offers intelligent Layer 2 data packet switching and management functions, friendly web user interface and stable operation. The model complies with IEEE 802.3at Power over Ethernet Plus (PoE+) at an affordable price. The GS-4210-16P2S is equipped with 16 10/100/1000BASE-T Gigabit Ethernet ports and 2 100/1000BASE-X SFP interfaces with inner power system. Its 16 Gigabit Ethernet ports integrated with 802.3at PoE+ injector function on all ports. It offers a rack-mountable, affordable, safe and reliable power solution for SMBs deploying Power over Ethernet networks, or requiring enhanced data security and network traffic management.


  Cybersecurity Network Solution to Minimize Security Risks
  The GS-4210-16P2S supports SSHv2 and TLS protocols to provide strong protection against advanced threats. It includes a range of cybersecurity features such as DHCP Snooping, IP Source Guard, dynamic ARP Inspection Protection, 802.1x port-based network access control, RADIUS and TACACS+ user accounts management, SNMPv3 authentication, and so on to complement it as an all-security solution.


  Redundant Ring, Fast Recovery for Critical Network Applications
  The GS-4210-16P2S supports redundant ring technology and features strong, rapid self-recovery capability to prevent interruptions and external intrusions. It incorporates advanced ITU-T G.8032 ERPS (Ethernet Ring Protection Switching) technology, Spanning Tree Protocol (802.1s MSTP) into customer’s network to enhance system reliability and uptime in various environments.


  Built-in Unique PoE Functions for Powered Devices Management

  As the PoE managed switch for surveillance, wireless and VoIP networks, the GS-4210-16P2S features special PoE management functions:

  PD alive check
  Scheduled power recycling
  PoE schedule
  PoE usage monitoring
  PoE Extension

  Intelligent Powered Device Alive Check
  The GS-4210-16P2S can be configured to monitor connected PD (Powered Device) status in real time via ping action. Once the PD stops working and responding, the GS-4210-16P2S will resume the PoE port power and bring the PD back to work. It will greatly enhance the network reliability through the PoE port resetting the PD’s power source and reducing administrator management burden.


  Scheduled Power Recycling
  The GS-4210-16P2S allows each of the connected PoE IP cameras or PoE wireless access points to reboot at a specific time each week. Therefore, it will reduce the chance of IP camera or AP crash resulting from buffer overflow.


  PoE Schedule for Energy Saving
  Under the trend of energy saving worldwide and contributing to environmental protection, the GS-4210-16P2S can effectively control the power supply besides its capability of giving high watts power. The “PoE schedule” function helps you to enable or disable PoE power feeding for each PoE port during specified time intervals and it is a powerful function to help SMBs or enterprises save power and money. It also increases security by powering off PDs that should not be in use during non-business hours.


  PoE Usage Monitoring
  Via the power usage chart in the web management interface, the GS-4210-16P2S enables the administrator to monitor the status of the power usage of the connected PDs in real time. Thus, it greatly enhances the management efficiency of the facilities.

  802.3at PoE+ Power and Ethernet Data Transmission Distance Extension
  In the “Extend” operation mode, the GS-4210-16P2S operates on a per-port basis at 10Mbps duplex operation but can support 20-watt PoE power output over a distance of up to 250 meters overcoming the 100m limit on Ethernet UTP cable. With this brand-new feature, the GS-4210-16P2S provides an additional solution for 802.3at/af PoE distance extension, thus saving the cost of Ethernet cable installation.


  IPv6/IPv4 Dual Stack Management
  Supporting both IPv6 and IPv4 protocols, the GS-4210-16P2S helps the SMBs to step in the IPv6 era with the lowest investment as its network facilities need not be replaced or overhauled if the IPv6 FTTx edge network is set up.


  Robust Layer 2 Features
  The GS-4210-16P2S  can be programmed for advanced switch management functions such as dynamic port link aggregation, 802.1Q VLAN and Q-in-Q VLAN, Multiple Spanning Tree protocol (MSTP), loop and BPDU guard, IGMP snooping, and MLD snooping. Via the link aggregation, the GS-4210-16P2S allows the operation of a high-speed trunk to combine with multiple ports such as a 4Gbps fat pipe, and supports fail-over as well.  Also, the Link Layer Discovery Protocol (LLDP) is the Layer 2 protocol included to help discover basic information about neighboring devices on the local broadcast domain.

  Efficient Traffic Control
  The GS-4210-16P2S is loaded with robust QoS features and powerful traffic management to enhance services to business-class data, voice, and video solutions. The functionality includes broadcast/multicast/unicast storm control, per port bandwidth control, 802.1p/CoS/IP DSCP QoS priority and remarking. It guarantees the best performance at VoIP and video stream transmission, and empowers the enterprises to take full advantages of the limited network resources.

  Powerful Security
  PLANET GS-4210-16P2S offers comprehensive IPv4/IPv6 Layer 2 to Layer 4 Access Control List (ACL) for enforcing security to the edge. It can be used to restrict network access by denying packets based on source and destination IP address, TCP/UDP ports or defined typical network applications. Its protection mechanism also comprises 802.1X port-based user and device authentication, which can be deployed with RADIUS to ensure the port level security and block illegal users. With the protected port function, communication between edge ports can be prevented to guarantee user privacy. Furthermore, Port security function allows to limit the number of network devices on a given port. The network administrators can now construct highly-secure corporate networks with considerably less time and effort than before.

  Friendly and Secure Management
  For efficient management, the GS-4210-16P2S is equipped with Command line, Web and SNMP management interfaces.

  With the built-in Web-based management interface, the GS-4210-16P2S offers an easy-to-use, platform-independent management and configuration facility.
  For text-based management, it can be accessed via Telnet and the console port.
  By supporting the standard SNMP protocol, the switch can be managed via any SNMP-based management software.
  Moreover, the GS-4210-16P2S offers secure remote management by supporting SSHv2, TLSv1.2 and SNMP v3 connections which encrypt the packet content at each session.


  Flexible Extension Solution
  The two mini-GBIC slots built in the GS-4210-16P2S are compatible with the 100BASE-FX/1000BASE-SX/LX SFP (Small Form-factor Pluggable) fiber transceiver to uplink to backbone switch and monitor center in long distance. The distance can be extended from 550 meters to 2 kilometers (multi-mode fiber) and to 10/20/40/60/80/120 kilometers (single-mode fiber or WDM fiber). They are well suited for applications within the enterprise data centers and distributions.

  Applications

  Perfectly-integrated Solution for PoE IP Surveillance
  The GS-4210-16P2S brings an ideal, secure surveillance system at a lower total cost. The GS-4210-16P2S provides 16 10/100/1000Mbps 802.3at PoE+ ports able to feed sufficient PoE power for 16 IEEE 802.3at/af PoE IP cameras at the same time. It is also able to connect with one 16-channel NVR or two 8-channel NVR systems, uplinked to the core switch and the control center. With such a high-performance switch architecture, the recorded video files from the PoE IP cameras can be saved in the NVR system to enable the administrators to control and monitor the surveillance images both in the local LAN and the remote sites.


  Department/Workgroup PoE Network
  Providing 16 PoE in-line power interfaces, the GS-4210-16P2S can easily build a power that can centrally control IP phone system, IP camera system and wireless AP group for enterprises. The GS-4210-16P2S delivers full ports of 802.3at/af compliant Gigabit Ethernet network connectivity with high-performance and cost-effective advantages for the increasing number of PoE IP telephones, PoE IP cameras, PoE wireless access points and other devices applied at the edge of the small or medium enterprise network. The GS-4210-16P2S improves the network efficiency and protects the network clients with the powerful features:

  Layer 2 to Layer 4 security
  QoS/802.1Q VLAN / static trunk / LACP
  802.1x Port-based and MAC-based network access authentication security
  Multicast IGMP snooping


  Key Features

  Physical Port
  16 10/100/1000BASE-T Gigabit Ethernet RJ45 ports with IEEE 802.3at PoE+ Injector
  2 100/1000BASE-X mini-GBIC/SFP slots
  1 RJ45 console interface for switch basic management and setup
  Reset button for system factory default and reboot

  Switching
  Hardware-based 10/100Mbps, half/full duplex and 1000Mbps full duplex mode, flow control and auto-negotiation, and auto MDI/MDI-X
  Features Store-and-Forward mode with wire-speed filtering and forwarding rates
  IEEE 802.3x flow control for full duplex operation and back pressure for half duplex operation
  9K jumbo frame
  Automatic address learning and address aging
  Supports CSMA/CD protocol

  Power over Ethernet
  Complies with IEEE 802.3at Power over Ethernet Plus, end-span PSE
  Backward compatible with IEEE 802.3af Power over Ethernet
  Up to 16 ports of IEEE 802.3af/802.3at devices powered
  Supports PoE Power up to 30.8 watts for each PoE port
  220-watt PoE budget
  Auto detects powered device (PD)
  Circuit protection prevents power interference between ports
  Remote power feeding up to 100 meters in standard mode and 250m in extend mode
  PoE Management
  Total PoE power budget control
  Per port PoE function enable/disable
  PoE Port Power feeding priority
  Per PoE port power limitation
  PoE delay
  PD classification detection
  Intelligent PoE features
  PoE usage threshold control
  PD alive check
  PoE schedule

  Layer 2 Features
  Prevents packet loss with back pressure (half-duplex) and IEEE 802.3x pause frame flow control (full-duplex)
  High performance Store and Forward architecture, runt/CRC filtering eliminates erroneous packets to optimize the network bandwidth
  Supports VLAN
  IEEE 802.1Q tagged VLAN
  Provider Bridging (VLAN Q-in-Q) support (IEEE 802.1ad)
  Protocol VLAN
  Voice VLAN
  Private VLAN
  Management VLAN
  GVRP
  Supports Spanning Tree Protocol
  STP (Spanning Tree Protocol)
  RSTP (Rapid Spanning Tree Protocol)
  MSTP (Multiple Spanning Tree Protocol)
  STP BPDU Guard, BPDU Filtering and BPDU Forwarding
  Supports Link Aggregation
  IEEE 802.3ad Link Aggregation Control Protocol (LACP)
  1 LACP group, up to 2 ports per LACP group
  Cisco ether-channel (static trunk)
  1  trunk group, up to 2 ports per trunk group
  Provides port mirror (many-to-1)
  Loop protection to avoid broadcast loops
  Supports ERPS (Ethernet Ring Protection Switching)

  Quality of Service
  Ingress/Egress Rate Limit per port bandwidth control
  Storm Control support
  Broadcast, Unknown Unicast, and Unknown Multicast
  Traffic classification
  IEEE 802.1p CoS
  DSCP/IP Precedence of IPv4/IPv6 packets
  Strict priority and Weighted Round Robin (WRR) CoS policies

  Multicast
  Supports IPv4 IGMP snooping v2 and v3
  Supports IPv6 MLD snooping v1, v2
  IGMP querier mode support
  IGMP snooping port filtering
  MLD snooping port filtering

  Security
  Authentication
  IEEE 802.1X port-based network access authentication
  Built-in RADIUS client to co-operate with the RADIUS servers
  DHCP Option 82
  RADIUS/TACACS+ login user access authentication
  Access Control List
  IPv4/IPv6 IP-based ACL
  IPv4/IPv6 IP-based ACE
  MAC-based ACL
  MAC-based ACE
  MAC Security
  Static MAC
  MAC Filtering
  Port security for source MAC address entries filtering
  DHCP snooping to filter distrusted DHCP messages
  Dynamic ARP Inspection discards ARP packets with invalid MAC address to IP address binding
  IP source guard prevents IP spoofing attacks
  DoS attack prevention

  Management
  IPv4 and IPv6 dual stack management
  Switch management interface
  Web switch management
  Console/Telnet Command Line Interface
  SNMP v1 and v2c switch management
  SSHv2, TLSv1.2 and SNMP v3 secure access
  SNMP Management
  Four RMON groups (history, statistics, alarms and events)
  SNMP trap for interface link up and link down notification
  User privilege levels control
  Built-in Trivial File Transfer Protocol (TFTP) client
  BOOTP and DHCP for IP address assignment
  System maintenance
  Firmware upload/download via HTTP/TFTP
  Configuration upload/download through web interface
  Dual images
  Hardware reset button for system reboot or reset to factory default
  SNTP Network Time Protocol
  Network Diagnostic
  ICMPv6/ICMPv4 Remote Ping
  Cable diagnostics
  Link Layer Discovery Protocol (LLDP) and LLDP-MED
  Event message logging to remote Syslog server
  PLANET Smart Discovery Utility for deployment management
  PLANET NMS system and CloudViewer for deployment management

• Category	Specification
  Copper Ports	16 x 10/100/1000BASE-T RJ45 Auto-MDI/MDI-X Ports
  PoE Injector Ports	16 x 802.3af/802.3at PoE Injector Ports
  SFP/mini-GBIC Slots	2 x 100/1000BASE-X SFP interfaces (100/1000Mbps dual mode)
  Console	1 x RS-232-to-RJ45 serial port (115200, 8, N, 1)
  Reset Button	< 5 sec: Reboot / > 5 sec: Factory Reset
  Thermal Fan	2
  Power Requirements	100~240V AC, 50/60Hz, 4A (max.)
  Power Consumption	Max. 281 watts / 964 BTU
  Dimensions (WxDxH)	441.2 x 207.5 x 44 mm (1U)
  Weight	2.8kg
  Enclosure	Metal
  LED Indicators	System: Power (Green); RJ45 Ports: 1000 LNK/ACT (Green), 10/100 LNK/ACT (Orange), PoE (Orange); SFP: 1000 LNK/ACT (Green), 100 LNK/ACT (Orange)
  Switch Architecture	Store-and-Forward
  Switch Fabric	36Gbps / non-blocking
  Throughput	26.78Mpps @ 64 bytes
  MAC Address Table	8K entries
  Shared Data Buffer	4Mbits
  Flow Control	IEEE 802.3x pause frame (Full-Duplex); Back pressure (Half-Duplex)
  Jumbo Frame	9216 bytes
  PoE Standards	IEEE 802.3af & IEEE 802.3at
  PoE Output per Port	52V DC, 300mA/600mA (Max. 15.4W/30W)
  PoE Power Budget	220 watts
  Max PDs Supported	16 units (7W), 14 units (15.4W), 7 units (30W)
  PoE Management	PD Alive Check, Scheduled Power Recycling, PoE Schedule, Usage Monitoring, PoE Extension
  VLAN	802.1Q VLAN, 256 groups, Voice VLAN, Protocol VLAN, Private VLAN, Q-in-Q, GVRP, Management VLAN
  Link Aggregation	802.3ad LACP (1 group of 2 ports), Static Trunk (1 group of 2 ports)
  Spanning Tree	802.1D STP, 802.1w RSTP, 802.1s MSTP
  IGMP Snooping	IGMP v2/v3 (IPv4), MLD v1/v2 (IPv6), up to 256 groups
  QoS	8 Priority Queues, 8 Mapping IDs, Port/802.1p/DSCP Classification, Ingress/Egress Rate Control
  Ring Support	ERPS (ITU-T G.8032)
  Security Features	ACL (IPv4/IPv6/MAC), IEEE 802.1X, RADIUS/TACACS+, IP-MAC Binding, DHCP Snooping, ARP Inspection, IP Source Guard, DoS Prevention
  Management Interfaces	RS232 Console, Web, Telnet, SNMP v1/v2c/v3, SSHv2, TLS v1.2
  System Management	Firmware Upgrade (HTTP/TFTP), LLDP, SNTP, PLANET Smart Discovery, PLANET NMS, CloudViewer
  Event Management	Remote/Local Syslog, System log
  Regulatory Compliance	FCC Part 15 Class A, CE
  Standards Compliance	IEEE 802.3 (10/100/1000BASE), IEEE 802.3x, 802.1D/w/s/p/Q/X/ab/af/at, RFC protocols, ITU G.8032
  Operating Conditions	Temp: 050°C, Humidity: 595% (non-condensing)
  Storage Conditions	Temp: -1070°C, Humidity: 595% (non-condensing)
