• Philips P-Line | 43BDL3117P/00 43″ 4K Hi-Bright Digital Signage Display

  Power and flexibility
  Made for 24/7 operation, the robust Philips P-Line digital signage display stands the test of time. Clear UHD picture quality and high brightness make it perfect for demanding environments such as retail, transportation, and food and drink.

  Power and flexibility

  Brighter content with 24/7 performance.

  • 43″
  • UHD Panel
  • 750 cd/m²

  Operate, monitor and maintain with CMND and Control

  Run your display network over a local (LAN) connection. CMND and Control allows you to perform vital functions like controlling inputs and monitoring display status. Whether you’re in charge of one screen or 100.

  D-image: clinically accurate imaging

  This Philips Professional Display is factory-calibrated to meet clinical compliance standards for greyscale performance. The optimal image achieved by the display can be used to review medical images in consultation rooms or lecture theatres.

  FailOver ensures that content is always playing

  From waiting room to meeting room, never show a blank screen. FailOver lets your Philips Professional Display switch automatically between primary and secondary inputs, ensuring that content keeps playing even if the primary source goes down. Simply set a list of alternative inputs to be sure your business is always on.

  Sophistication and intelligence with SDM-L

  An integrated Intel Smart Display Module Large adds scalable sophistication to your display, enabling quick and cost-effective upgrades when you need to add new features and functionality. Its thin design provides the same level of intelligence and interoperability as OPS, whilst keeping the display as sleek as possible.

• Picture/Display
  Diagonal screen size (metric)	108 cm
  Diagonal screen size (inch)	42.5 inch
  Panel resolution	3840 x 2160
  Optimum resolution	3840 x 2160 @ 60 Hz
  Brightness	750 cd/m²
  Dynamic contrast ratio	500,000:1
  Response time (typical)	8 ms
  Aspect ratio	16:9
  Viewing angle (horizontal)	178 degree
  Viewing angle (vertical)	178 degree
  Pixel pitch	0.2451 x 0.2451 mm
  Display colours	1.07 billion
  Panel technology	ADS
  Contrast ratio (typical)	1200:1
  Haze	25%
  Supported Display Resolution
  Computer formats
  1440 x 900, 60 Hz
  1024 x 768, 60, 70, 75 Hz
  1152 x 864, 75 Hz
  1152 x 870, 75 Hz
  1280 x 1024, 60 Hz
  1280 x 720, 60 Hz
  1280 x 800, 60 Hz
  1600 x 1200, 60 Hz
  1680 x 1050, 60 Hz
  1920 x 1080, 60 Hz
  640 x 480, 60, 67, 72, 75 Hz
  720 x 400, 70 Hz
  800 x 600, 56, 60, 72, 75 Hz
  Video formats
  480p, 60 Hz
  576p, 50 Hz
  720p, 50, 60 Hz
  1080i, 50, 60 Hz
  1080p, 50, 60 Hz
  3840 x 2160, 30Hz
  3840 x 2160, 60 Hz
  Connectivity
  Video input
  Display Port1.2 (x 1)
  DVI-I (x 1)
  USB 2.0 (x 1)
  HDMI 2.0 (x 3)
  Audio input
  3.5 mm jack
  Video output
  DisplayPort 1.2 (x 1)
  HDMI 2.0 (x 1)
  Audio output
  3.5 mm jack
  External control
  IR (in/out) 3.5 mm jack
  RJ45
  RS232C (in/out) 2.5 mm jack
  Ambient Light Sensor
  Other connections
  Micro SD (x 1)
  SDM-L
  Thermal sensor
  Convenience
  Placement	Landscape (24/7) or Portrait (24/7)
  Tiled Matrix	Up to 15 x 15
  Screen-saving functions	Pixel Shift, Low Bright
  Signal loop through	DisplayPort, RS232, HDMI
  IR Loop through
  Ease of installation	Carrying Handles
  Energy-saving functions	Smart Power
  Network controllable	RS232, RJ45
  Keyboard control	Hidden
  Lockable
  Operating conditions
  Temperature range (operation)	0 ~ 40 °C
  Temperature range (storage)	-20 ~ 60 °C
  Altitude	0 ~ 3000 m
  MTBF	50,000 hour(s)
  Humidity range (operation)[RH]	20~80% RH (No condensation)
  Humidity range (storage) [RH]
