• Philips D-Line 55BDL4650D/00 55″ 4K Ultra HD Signage Solutions Display

  Save and play content with internal memory
  Save and play content with internal memory. Upload your media into the display and playback content immediately. Working in conjunction with the internal browser, it also serves as a memory cache when streaming online content. If the network ever fails, the internal memory keeps content running by playing a cached version of the content, ensuring that your media stays up even if the network goes down.


  4G/LTE optional module for reliable connection
  Select our optional 4G/LTE module for more predictable bandwidth and faster download speeds, providing you with a reliable backup connection in case of 24/4 work requirements or where local network connections are not possible.

  FailOver. Ensure your display never goes blank
  Critical for demanding commercial applications, FailOver is a revolutionary technology that automatically plays back-up content on screen in the unlikely event of a media player failure. Simply select a primary input connection and a FailOver connection, and you’re ready for instant content protection.

  Modularity – longer product lifetime
  Extend your display into the future with our modular approach. Bringing opportunities for longer product lifetime with easily detached and replaced components, plus a firm focus on sustainability, with reduced WEEE disposal.


  Android SoC processor. Native and web apps
  Powered by Android 11 and with integrated Wi-Fi, your Philips D-Line delivers the ultimate, most secure and connected display experience. Optimised for native Android apps, it enables you to install web apps and software directly onto the display, eliminating the need for an external media player.

  Connect and control your content via the cloud
  Connect and control your content via the cloud with our integrated HTML5, Chromium-based browser. Design your content online and connect a single display, or your entire network, either landscape or portrait, in 4K UHD resolution. Simply connect to the Internet via Wi-Fi or with an RJ45 cable.

  Catch the Wave for revolutionary results
  Unlock the power, versatility and intelligence inside your Philips D-Line displays remotely with Wave. This evolutionary cloud platform puts you fully in control, with simplified installation and setup, monitoring and controlling displays, upgrading firmware, managing playlists and setting power schedules. Saves you time, energy and environmental impact.

• Category	Details
  Picture/Display
  Diagonal screen size (metric)	138.7 cm
  Diagonal screen size (inch)	54.6 inch
  Aspect ratio	16:9
  Panel resolution	3840 x 2160
  Pixel pitch	0.315 × 0.315 mm
  Optimum resolution	3840 x 2160 @ 60 Hz
  Brightness	500 cd/m²
  Display colours	1.07 Billion
  Contrast ratio (typical)	5000:1
  Dynamic contrast ratio	500,000:1
  Response time (typical)	8 ms
  Viewing angle (horizontal)	178 degree
  Viewing angle (vertical)	178 degree
  Picture enhancement	3/2 – 2/2 motion pull down, Dynamic contrast enhancement, Motion compens. deinterlacing, Progressive scan
  Panel technology	VA
  Operating system	Android 11
  Haze	25%
  Connectivity
  Audio output	3.5 mm jack
  Video input	DVI-I (x 1), DisplayPort 1.4 (x 1), HDMI 2.0 (x 2), USB 3.0 (x 2), VGA (via DVI)
  Audio input	3.5 mm jack
  Other connections	4G/LTE antenna connectors, Micro USB (x 1) (OTG), USB 2.0 (x 1)
  Video output	DisplayPort 1.4 (x 1)
  External control	RJ45, RS232C (in/out) 2.5 mm jack, IR (in/out) 3.5 mm jack
  Wi-Fi	Wi-Fi 6 + Bluetooth 5.2 (slide-in module)
  Convenience
  Placement	Landscape (24/7), Portrait (24/7), Tiled Matrix (Up to 10 x 15)
  Screen-saving functions	Pixel Shift
  Keyboard control	Hidden, Lockable
  Signal loop through	IR Loop through, DisplayPort, RS232
  Energy-saving functions	Smart Power
  Network controllable	RS232, External 4G mPCIe slot, RJ45, Wi-Fi
  Wi-Fi protocol	a b g n, 802.11 ax, 802.11 ac
  Sound
  Built-in speakers	2 x 10 W RMS
  Power
  Mains power	100 ~ 240 VAC, 50 ~ 60 Hz
  Consumption (Typical)	112 W
  Standby power consumption	0.5 W
  Energy Label Class	G
  Supported Display Resolution
  Computer formats	1920 x 1080, 60 Hz, 1680 x 1050, 60 Hz, 1600 x 900, 60 Hz, 3840 x 2160, 30, 60 Hz, 640 x 480, 60 Hz, etc.
  Video formats	1080i, 50, 60 Hz, 1080p, 50, 60 Hz, 720p, 50, 60 Hz, 2160p, 50, 60 Hz
  Dimensions
  Set Width	1241.8 mm
  Product weight	16.6 kg
  Set Height	712.6 mm
  Set Depth	63.6 mm
  Set Width (inch)	48.89 inch
  Set Height (inch)	28.20 inch
  Set Depth (inch)	2.50 inch
  Bezel width	13.9 mm (Even bezel)
  Product weight (lb)	36.60 lb
  Wall Mount	400 (H) x 400(V) mm, M6
  Operating conditions
  Altitude	0 ~ 3000 m
  Temperature range (operation)	0 ~ 40 °C
  MTBF	50,000 hour(s)
  Temperature range (storage)	-20 ~ 60 °C
  Humidity range (operation)[RH]	20–80% RH (No condensation)
  Humidity range (storage) [RH]	5–95% RH (No condensation)
  Multimedia Applications
  USB Playback Video	MPEG, H.264, AVI, MP4, etc.
  USB Playback Picture	BMP, JPEG, PNG
  USB Playback Audio	AAC, HEAAC, MPEG
  Internal Player
  CPU	2 x A72 + 4 x A53
  GPU	ARM Mali-T860 MP4
  Memory	4 GB RAM
  Storage	32 GB eMMC
  Accessories
  Included Accessories	RS232 daisy-chain cable, Philips logo, AC Switch Cover, USB Cover, Screws, AC Power Cord, etc.
  Miscellaneous
  On-Screen Display Languages	English, French, German, Spanish, Polish, Turkish, Arabic, Japanese, etc.
  Warranty	3 year warranty
  Regulatory approvals	CE, RoHS, CB, FCC, Class A, EMF, EnergyStar 8.0, UL
