• Panasonic TH-98CQE2W 98″ 4K Ultra HD Entry-Level Digital Signage Display


  The Panasonic Connect TH-98CQE2W 4K Professional display is designed for 24-hours/day continuous operation and crystal-clear viewing clarity. The display provides a brightness of 500cd/m² with an anti-glare panel, and minimum haze treatment, reducing the reflection of ambient light and vastly improving visibility. For ultimate flexibility and a clean look without set-top-boxes or cables, the TH-98CQE2W is also equipped with a built-in TV tuner for access to broadcast, cable, and subscription TV services, making them an ideal solution for corporate, education, and even sports bar applications.

  KEY FEATURES
  High image quality
  Reliability and ease of installation
  System scalability

• Category	Description
  Panel Size	98-inch (97.51-inch/2476.9 mm)
  Brightness (typ.)	500 cd/m²
  Panel Surface Treatment	Anti-glare (Haze 25%)
  USB	Type A: DC 5 V/max. 0.9 A, USB 3.0 supported<br>Type A: DC 5 V/max. 0.5 A, USB 2.0 supported<br>Type A: DC 5 V/max. 0.5 A, USB 2.0 supported (Internal)<br>Type C: DC 5 V/max. 3.0 A, USB 3.0 supported, DisplayPort Alternate mode compatible
  microSD	microSD/SDHC/SDXC / MAX 1 TB
  SERIAL IN	Stereo mini jack (φ3.5 mm) x 1, RS-232C Compatible
  LAN	RJ45 x 1, compatible with PJLink™ 10BASE-T/100BASE-TX/1000BASE-T
  IR In	Stereo mini jack (φ3.5 mm) x 1
  Slot	No
  Wi-Fi	Yes (Dongle)
  AUDIO OUT	Stereo mini jack (φ3.5 mm) x 1, SPDIF x 1
  Built-in Speaker	24 W
  Power Consumption	595 W
  Dimensions (WxHxD)	2216 x 1271 x 91 mm (87.25″ x 50.02″ x 3.55″)
  Dimensions (WxHxD)	2216 x 1288 x 91 mm (87.25″ x 50.67″ x 3.55″)
  Weight	99.4 kg/219.2 lbs
  Wall-hanging Pitch	800 x 400 mm, M8
  HTML Browser	HTML5 (Viewed)
  Effective Display Area (W x H)	2158.8 x 1214.3 mm (84.99″ x 47.80″)
  Resolution	3840 x 2160
  Contrast	1200:1
  Viewing Angle	178°/178° (T/B)/(L/R) (CR>10)
  HDMI™ IN	HDMI™ x 4 (compatible with HDCP2.2)
  Bluetooth®	Yes (Dongle)
  Android™-OS	Yes
  Operating Time	24 h/day
  Orientation	Landscape/Portrait
  Tilt Angle	0-20 degrees forward and backward with landscape/portrait setting
  Power Requirements	AC 220 – 240 V 50 Hz / 60 Hz
  Power Off Condition	0 W
  Stand-by Conditions	Approx. 0.5 W
  Energy Efficiency Class	–
  Bezel Width	28.2 mm (1.11″) (T/R/L/B)
  Operating Environment	Temperature: 0°C to 40°C (32°F to 104°F), Humidity: 20-80% (Non-condensation) for up to 0-1400 m (4593 ft) altitude. Temperature: 0°C to 35°C (32°F to 95°F), Altitude 1400 – 2800 m (4593 ft to 7874 ft)
  Note	*1: In case of long time, the moving image is recommended to be displayed. If you display a still picture for an extended period, the image retention might remain on the screen. However, image retention can gradually disappear by displaying moving images. *2: Please contact your sales representative with regard to the tilt angle before installation.

• PANASONIC PROFESSIONAL DISPLAY
  Limited Warranty
  3-year Warranty

  On-site Swap Out (Collect, repair, return as standard)
  A 3-year parts, labor, and logistics warranty for product failure.

• Description	Downloads
  Spec Files	Downloads
  CAD Data	Downloads
