Panasonic PT-FRQ60BEJ DLP Projector – 6000 Lumens
- Description
- Specifications
- Downloads
-
Panasonic PT-FRQ60BEJ DLP Projector – 6000 Lumens
Smooth and Detailed 4K Image Quality
Quad Pixel Drive, Panasonic’s original 2-axis pixel-quadrupling technology, creates crisp, sharp, and smooth 4K images. Frame rates up to 240 Hz/1080p are supported with 8 ms latency or less1 . Rich Color Enhancer produces deep, accurate color for artwork. Together, these technologies deliver insightful visual experiences in museums and STEM classrooms.Flexible, Simple to Use,and Easy to Integrate
Wide-range V/H Lens-Shift and 2.0x zoom enhance installation flexibility while two CEC-compatible HDMI® inputs and DIGITAL LINK simplify operation and integrate the projector into 4K system infrastructure. Preactivated upgrade kits for Geo Pro2 and Remote Preview Lite3 secure an eortless 4K experience.
Highly Reliable Low-Maintenance Projection
Heat-pipe cooling system enables implementation of full hermetic sealing for the airtight optical block, eliminating need of a filter for 20,000 hours4 of maintenance-free projection. Multi Monitoring & Control Software with optional Early Warning5 functions enhances reliability and prevents unexpected
downtime by sending an alert before problems occur.Filmlike 4K with Vivid Color
Quad Pixel Drive provides smooth, gridless 4K resolution for precise reproduction of digital artwork, CAD drawings, architectural designs, and other detailed images. Rich Color Enhancer features a Standard/Graphic Mode that optimizes red-channel output for deep and natural color expression, and
Dynamic Mode to balance brightness and color for clearest visibility in well-lit environments.Smooth Playback of 240 Hz Conten
PT-FRQ60 Series supports frame rates up to 240 Hz/1080p with input-to-output latency of 8 ms or less1 for applications where smooth motion is important. The projector also works with ET-SWR102 , a ready-to-use tracking projection-mapping SDK that enables image projection onto fast-moving objects at up to
240 fps to add lifelike interactivity to your museum exhibit.
Flexible and Adaptable to Your Application
Flexible 2.0x optical zoom, V/H Lens-Shift, and Geometric Adjustment with Free Grid give freedom to correct image position and distortion without a PC. Preactivated upgrade kits for Geometry Manager Pro3 automate edge-blending via camera4 , expand the range of software adjustment, and add
sophisticated creative masking capabilities.Reliable, Cost-Effective Operation
Filterless heat-pipe cooling system draws heat from the hermetically sealed optical block, enabling 20,000 hours5 of maintenance-free projection and reducing operating noise to a comfortable 28 dB6 . Remote Preview Lite7 enables input-video checks on a remote PC before projection. These technologies deliver unbeatable peace of mind in mission-critical situations -
Feature Details Brightness (Normal) 6000 ANSI Lumens Brightness Category 5K-6999 Lumens Laser Yes Native Resolution 3,840 x 2,160 (4K/UHD) Aspect Ratio 16:9 Contrast Ratio (Typical) 20,000:1 Technology DLP Lens Throw Ratio 1.46–2.93:1 Horizontal Keystone +/- 20 Degrees Vertical Keystone +/- 40 Degrees Network Capability Yes Wireless Compliancy Yes USB 2.0 Ports Quantity 1 HDMI Ports Quantity 2 Dimensions (W x D x H) 498 x 492 x 168 mm Weight 16.9 Kg Lens Ratio Standard Throw (1 – 3:1) -
