• NovaStar VX600 All-In-One Video Processor


  The Novastar VX-600 is an all-in-one video processor suitable for small to medium size LED screen installations. It can drive up to 3,900,000 pixels in total, at up to 10,240 pixels wide or up to 8,192 pixels in height, which is ideal for ultra-wide and ultra-high LED screen applications.

  The VX-600 offers a variety of video inputs and it allows you to switch seamlessly between several input sources. Furthermore, it supports up to three layers (1x main / 2x PIP), scaling function, low latency and Gen-Lock function.

  Besides the built-in sending card with 6 Ethernet ports, the VX-600 also offers the option to install an SFP module. With this module you can cover bigger distances than the 100 metre limit of Ethernet cables and drive another VX-600 (fibre mode) or CVT10 fibre connector, which then drives your LED screens. The second fibre output serves as a backup and will automatically take over in case something happens to the main output (“Output 1”).

  For controlling even bigger LED screen installations, Image Mosaic function is available. This enables you to combine up to four VX-600 units.

  Screen configuration can be done by USB and Ethernet connection. The modern 1U box fits nicely in a 19″ rack or case, making it most suitable for rental companies and fixed installations.

• Category	Specifications
  Inputs	HDMI 1.3: 2 ports
  	Single Link DVI: 1 port
  	3G-SDI: 1 port
  Outputs	Main Outputs: 6
  	HDMI 1.3 (Loop): 1 port
  	HDMI (PVW/MVR): 1 port
  	Single Link DVI (Loop): 1 port
  	3G-SDI (Loop): 1 port
  Optical Outputs	SFP Slot Type: 10G
  	SFP Slot Quantity: 2
  Software Specifications	Control Software: NovaStar LCT, Smart LCT, Vcan
  	Scaling Function: Yes
  	Image Mosaic: Yes
  	PIP (Picture in Picture): Yes
  	Layers: 3
  	GenLock: In & Out
  Control and Programming	Display: LCD
  	Maximum Loading Capacity: 3.9 Mpx
  	Max Input Resolution: 1920 x 1200, user-defined
  	Control Options: Ethernet, USB
  Electrical Specifications	Power Supply: 100-240 V AC, 50/60 Hz
  	Power Consumption: 28 W
  	Power Connector: IEC
  Data Connections	Data Connector In: RJ45, USB
  	Data Connector Out: RJ45, USB
  Mechanical Specifications	Width (w/ handles): 484 mm (19.055″)
  	Width (w/o handles): 440 mm (17.323″)
  	Height (w/ handles): 45 mm (1.772″)
  	Depth (w/ handles): 351 mm (13.819″)
  	Depth (w/o handles): 321 mm (12.638″)
  	Weight: 4 kg (8.818 lb)
  	Rack Units: 1U
  	IP Rating: IP20 (Indoor use only)
  	Colour: Black
  Product Properties	Cooling: Active Cooling
  Thermal Specifications	Max Ambient Temperature: 60°C (140°F)
  	Min Ambient Temperature: -10°C (14°F)
  	Operating Humidity: 20-90% rH
  Included Items	CAT-5 Cable, DVI-HDMI Cable, HDMI-HDMI Cable, IEC Cable, USB-A to USB-B Cable
