Newline NAOS+ TT-5521IP 55″ 4K Interactive Touch Screen Display
Newline NAOS+ TT-5521IP
55″ 4K Interactive Touch Screen Display
- Description
- Specifications
- Warranty
-
YOUR BEST BET FOR HIGH-END SECURITY
WHEN SECURITY IS YOUR ABSOLUTE PRIORITY
Maximum Viewing Angle
Powered USB Type-C
Diverse Connectivity
Broad Compatibility
Crystal Clear Image Quality
Capacitive Touch
OPTICALLY BONDED 4K DISPLAY TO REDEFINDE CLARITY
Optical bonding gives you an ultra-wide 178° viewing angle. No matter where you sit in the room, the image is robust and clear.
NEWLINE SECURES YOUR INFORMATION
Have more control over your interactive display and your data.
With an operating system powered, the Newline IP+ allows you to keep access to your network out of reach while still making it easy for anyone to walk up and use.
COLLABORATE THE WAY YOU LIKE
IP+ Series lets you add a powerful on-board PC to bring the power of a desktop computer right to your display. Use the familiar Windows system and all its functionalities for unlimited and personalized collaboration.
ULTRA-SMOOTH TOUCH EXPERIENCE
Capacitive touch technology works and feels as natural as writing on a smart phone or tablet. With an instant response from the screen, interactivity and whiteboarding are made more intuitive than ever.
PLUG AND PLAY ALL THE WAY
Streaming your setup with fast and easy USB-C connection. Thanks to plug & play USB-C, your entire setup process requires plugging in one cable – which transports data, audio, video and power. Connect and disconnect immediately or switch devices without any hassle – just plug in and get straight to teaching. No more delays, troubleshooting, or fidgety kids! -
Model Name TT-5521IP Display Specifications Active Screen Size 55″ Display Technology LED Resolution 3840 × 2160 (4K) Display Area 1211 × 682 mm Display Ratio 16:9 Display Color Depth 1.07 Billion (8bit+FRC) Brightness ≧ 400 cd/m2 Contrast Ratio (Dynamic) 4000:1 Response Time 8 ms Viewing Angle 178° Life Time 50,000 hours Power Working Voltage AC 100 – 240V Max 2.5A Max Power Consumption ≤ 250W Eco Power Consumption 188W Standby Power Consumption < 0.5W Speaker Position Downward Rated Impedance 6Ω Frequency Response 100Hz – 20KHz when SPL is -10dB Output S.P.L. 0dB ~ -10dB Max Power Output 20 W × 2 Transportation/Storage Storage Temperature/Humidity -10°C – 45°C / 20 – 90% RH (Non-Condensing) Working Temperature/Humidity 0°C – 40°C / 20 – 80% RH (Non-Condensing) Mounting (Optional) Wall-Mounted / Mobile Stand Outline Dimensions 1290 × 764 × 73 mm Packing Dimensions 1417 × 871 × 221 mm Net Weight 28 kg Gross Weight 36 kg Connectivity USB Data Ports 1 × USB Type-C 3.0 (PD 60W) 1 × USB 3.0 (Public) 3 × USB Type-B (Touch) 1 × USB 2.0 (FW) Digital Audio-Video Inputs 3 × HDMI In (4K@60Hz) (HDMI 1 w/ARC) 1 × Microphone In Digital Audio-Video Outputs 1 × HDMI Out (4K@60Hz) 1 × Audio Line Out 1 × S/PDIF Integrated PC Slot 1 × OPS-PC Slot 1 × SDM-S Slot Control Input 1 × RS-232 Network 1 × Out RJ-45 Connector Touch Touch Sensor Projective Capacitive Touch (P-cap) Touch Surface Technology Anti-Glare Transparency 88% ± 3 Surface Hardness 8H Touch Points 20 Points Touch Screen Writing Tools Passive Pen Embedded Operating System Linux-Based Chipset MSD3683QTA RAM 3 GB DDR3 MCP ROM 64 MB NOR Flash OS Version Linux-Based Multimedia File Formats Support Image Formats JPEG, BMP, PNG Video Formats MPEG2, MPEG4, H264 Audio Formats WMA, MP3, M4A (AAC) -
WARRANTY Newline Interactive warrants your products to be free from defects in material and workmanship for the corresponding period of time (see above table) from the original date of purchase. If a defect is discovered in a product covered by this warranty, Newline Interactive will provide onsite support and/or advanced replacement for the defective unit. Prior to replacing the unit, a troubleshooting process will be followed to confirm the unit is defective and it is possible that an onsite repair can rectify the defect; if that is the case, the onsite repair will be done.
Call (888) 233-0868, email [email protected], or use form at newline-interactive.com/usa/contact-us/
