Netgear JGS524-200EUS 24-Port Gigabit Ethernet Unmanaged Switch

• Description
• Specifications
• Downloads

• Netgear JGS524-200EUS 24-Port Gigabit Ethernet Unmanaged Switch


  Gigabit Unmanaged Switch Series (JGS524)
  24-Port Gigabit Ethernet Unmanaged Switch
  Easily combine new or existing 10-, 100- and 1000Mbps devices within

  Each port delivers up to 2000Mbps of network speed (full duplex)

  Fast, auto-switching and auto-sensing 10/100/1000Mbps Ethernet connection

  24 switched ports provide bandwidth for PCs, servers or switches

  Auto Uplink™ automatically adjusts for straight-through or crossover cables

  Plug and play—begins working as soon as it is powered on

  Integrates 10-,100- and 1000Mbps devices into your network

  Compact size for desktop or for mounting in a standard 19-inch rack

  The NETGEAR Gigabit Unmanaged Switch series helps businesses cost-effectively expand their network to Gigabit speeds and higher port counts

  Unmanaged Gigabit switches come in a wide range of models including desktop, wall-mount and rackmount form factors and 5 to 24 port configurations

  Energy efficient, built to last, and rigorously tested to provide the reliability businesses need

  802.1p traffic prioritization and jumbo frame support allow for seamless integration with more sophisticated networks

  24 ports deliver up to 2000Mbps of dedicated, non-blocking bandwidth per port

  Instant Plug-N-Play connectivity with Auto-negotiation and Auto MDI/MDI-X

  Easily combine new or existing 10-, 100- and 1000Mbps devices within your network

  802.1p QoS support for prioritizing voice and video in the network

  Jumbo Frame Support up to 9KB

• PHYSICAL SPECIFICATION
  Dimensions (WxDxH) @mm	328 x 169 x 43 mm
  Weight (kg)	1.65

  TECHNICAL SPECS
  Speed	10/100/1000Mbps Gigabit Ethernet
  Number of Ports	24
  PoE ports	n/a
  Total PoE Budget	n/a
  Loop Detection	n/a
  Short cable power saving	n/a
  Energy Efficient Ethernet Support (IEEE 802.3az)	Yes
  Jumbo Frame Support	9KB
  Queue WRR Ratio	1:2:4:8
  MAC Table Size	8K
  Packet buffer size	256KB
  IEEE 802.1p QoS	Yes
  Max Power Consumption	17.9W
  Operating Temperature	0 to 50° C
  MTBF (hours)	238,872
  FCC Class	A

  SUPPORT & WARRANTY
  Warranty	NETGEAR ProSAFE® Limited Lifetime Hardware Warranty
  Hardware Replacement	Lifetime Next Business Day Hardware Replacement
  Warranty Details	[Coverage, availability, and terms and conditions](link here)
  Support	ProSUPPORT 24×7 Advanced Technical Support via phone for 90 days (Remote diagnostics performed by our technical experts for prompt resolution of technical issues). ProSUPPORT coverage can be extended by purchasing one, three, or five-year contracts. ProSUPPORT Lifetime 24×7 Advanced Technical Support via chat.
